EQUIPMENT MANUAL FOR RF-9122 GSM900-GSM1800 FSR

4.6.1 DESCRIPTION OF PARAMETERS

The parameters being described are applicable for this system.
4.6.1.1 NETWORK PARAMETERS
The following parameters are located on the left of the main screen, these include: Site ID, SMS and
data link parameters, all enables communication with the OMC located in a Network Operation
Centre.
SITE ID
SMS REPORT ALARM
DATALINK REPORT
ALARM
MODEM RECEIVED
SIGNAL
Note 1: Only one communication mode is available at one time. Green indicates active and red
indicates disable.
Note 2: If the alarm message has been acknowledged using OMT, then it would not be reported
again.
RF-9122T18 QE
ENU Status : 1-0-0
The identification of each site to the OMC (see section 'Remote
Monitoring using OMC')
Specifies the SMS centre the system dial when alarms are to be
sent as SMS.
The 'OMC report number' specifies a number the MCU to dial for
alarm reporting.
In the datalink mode, alarms can be sent over the PSTN to a
maximum of four numbers.
A 'Read' button located on the right upper part of Net parameter
page, this displays the signal strength of Modem antenna. Signal
level at <-90dBm will be too weak.
Table 8: Management - Network Parameters
