- Page 1 ELLIPTICAL TRAINER E160 MODEL: Owner's Operating Manual...
-
Page 2: Important Safety Notice
Dear Customer, Please read this instruction very carefully before using the item. IMPORTANT SAFETY NOTICE: Note the following precaution before assembling or operating the machine Assemble the machine exactly as the descriptions in the instruction manual. Check all the screws, nuts and other connections before using the machine for the first time and ensure that the trainer is in the safe condition. -
Page 3: Exploded Diagram
EXPLODED DIAGRAM - 2 -... - Page 4 ESPLODED DIAGRAM - 3 -...
- Page 5 Parts List DESCRIPTION DESCRIPTION Main frame End cap Handlebar post Hexagonal bolt 3L/R Flat Washer Pedal tube 4L/R Handle tube Nylon nut 5L/R Handlebar Hexagonal bolt Flat Washer Fixed handlebar Front stabilizer Nylon nut Rear stabilizer End cap 9L/R Pedal Extension wire Sensor wire Computer...
-
Page 6: Assembly Instruction
ASSEMBLY INSTRUCTION 1.PREPARATION: A. Before assembling make sure that you will have enough space around the item. B. Use the present tooling for assembling. C. Before assembling please check whether all needed parts are available (at the above of this instruction sheet you will find an explosion drawing with all single parts (marked with numbers) which this item consists of 2.ASSEMBLY INSTRUCTION:... - Page 7 STEP 2: Connect the Extension wire (30) with the Sensor wire (31), then connect the Tension control cable (32) with the Tension control cable (41) like the picture. And then lock the Handlebar post (2) into the Main Frame (1) with the (12) and the Inner hexagonal bolt (15).
- Page 8 STEP 4: Attach the Handle Tube (4L/R) to the Upside Handle tube (40L/R), and fix them with Inner hexagonal bolt (15), Arc washer (12).Then Attach the Pedal Tube (3L/R) to the crank of Main frame (1), fix them with Flat washer (27), Nylon nut(28), Bushing(2) 37 ,then cover the Nylon nut with End caps (29) STEP 5: Fix the Fixed handlebar (6) to the Handlebar post (2) with the Inner hexagonal bolt (14), Arc...
- Page 9 STEP 6: 1.Connect the Extension Wire (30) with the wire of Computer (10). Then fix the Computer (10) on the computer bracket of Handlebar Post (2) with Cross pan head screw (34) and Washers (35).At last, insert the pin of the Pulse sensor wire (33) to the hole which in the back of the Computer(10) 2.Fix Handlebar (5L/R) to the Handle Tubes (4L/R) with Carriage bolt (16), Arc Washers (12) and Acorn Nuts (13).
-
Page 10: Battery Replacement
EXERCISE MONITOR INSTRUCTION MANUAL KEY GUIDES MODE: Select the function to be preset. SET : Press to increase the preset value of TIME, DISTANCE or CALORIES. RESET: Reset all display to zero except ACCUMULATED DISTANCE. Hold the button for 3 seconds to display ACCUMULATED DISTANCE. RECOVERY : Press this button going into pulse recovery detecting. -
Page 11: Specifications
DISTANCE The distance of each workout will be displayed by the third left square of the lower screen. CALORIES The calories burned will be displayed by the second right square of the lower screen. REMARKS It is suggested to preset only one item. If more than one item is set, the first to reach the preset value will sound the alarm.
