Summary of Contents for Sportop E-860P
- Page 4 STEP 1.CONNECT THE SENSOR WIRE(A14) AND THE COMPUTER CABLE(B4) STEP 2 .ASSEMBLE SUPPORT TUBE(B) WITH THE BASE FRAME(A) BY BOLTS(B7), SPRING WASHERS(B6) AND M8 WASHERS(B5). STEP 3 .EQUIP HANDLE BAR SUPPORT(E1) WITH CENTRAL SUPPORT(B) AND USE WASHER(M7), END CAP(M8) AND SCREW(M9) TO FIX IT. THE SAME WAY TO EQUIP E2.
- Page 6 ASSEMPLE HANDLE BAR(F1 & F2) WITH HANDLE BAR SUPPORT(E1 & E2) BY SCREW(M6 & M3) AND WASHER (M12) &WASHER(M11). STEP 1.EQUIP THE CONNECTION TUBE(A12) WITH THE HANDLE BAR SUPPORT (E2) .ASSEMBLE THE HANDLE BAR SUPPORT WITH THE DECORATION (K1 & K2) WITH THE SCREWS (M2) AND THEN FIX BY POP-PIN (M3). STEP 2.THE SAME PROCEDURE AS LEFT SIDE.
