- Page 1 OPERATOR MANUAL Operator & Parts Manual Battery Automatic Floor Scrubber Model: i20NBV 8130054 REV.04(10-2021)
- Page 2 Please dispose of packaging materials, old machine components such as batteries, hazardous fluids, including antifreeze and oil, in an environmentally safe way according to local waste disposal regulations. Always remember to recycle. Specifications and parts are subject to change without notice. i20NBV...
-
Page 3: Table Of Contents
SAFETY PRECAUTIONS......................4 MACHINE COMPONENTS....................5 PANEL COMPONENTS......................6 MACHINE SETUP & INSTALLATION..................7 MACHINE OPERATION....................8 WHILE OPERATING MACHINE..................8 TANK DRAINING........................9 BATTERY CHARGING......................9 PREVENTATIVE MAINTENANCE...................9-10 ADJUSTMENT OF SQUEEGEE ASSEMBLY ..............11 BASIC TROUBLESHOOTING.....................12 TECHNICAL SPECIFICATIONS.................13 PARTS LIST......................14-33 WEAR AND TEAR PARTS....................34 WIRING DIAGRAM .......................35 i20NBV... -
Page 4: Safety Precautions
- Secure machine with wheel blocks prior to jacking the machine up. - Use approved jack or hoist to safely elevate the machine. - Disconnect batteries prior to working on machine. - Wear gloves when handling batteries or battery cables. i20NBV... -
Page 5: Machine Components
11. Wheels, 8 Inch 29. Recovery Tank 12. Caster, 3.15 Inch 30. Cover 13. Caster, 2 Inch, Squeegee Blade Adjustment 14. Hose Fill-Port 15. Squeegee Storage Bracket 16. Control panel (see Panel components) 17. Overload protector 18. On-board battery charger / Window i20NBV... -
Page 6: Panel Components
OPERATOR MANUAL PANEL COMPONENTS 1. Battery capacity indicator 2. Bush motor switch 3. Vacuum motor switch i20NBV... -
Page 7: Machine Setup & Installation
RED to POSITIVE and BLACK to NEGATIVE. completely seated into the slots before securing knobs. 3. Connect the vacuum hose to the squeegee assembly. Loop the hose by using the hose clip provided. 4. Check the squeegee blades for proper adjustment. i20NBV... -
Page 8: Machine Operation
6. Turn on the vacuum motor switch (see Panel components, item #3). 7. i20NBV: Pull the control handle bail (see machine components, item #2) backwards to start scrubbing by moving the machine forward. NOTE: 45-60 meters (150-200 ft) per minute is the recommended scrubbing speed. -
Page 9: Tank Draining
WARNING: Repairs are to be completed or floor drain. by Dealer only. Any repairs completed by 2. Remove the cover of the filter assembly (see unauthorized persons will avoid the warrenty. machine components, item #24) to drain the i20NBV... - Page 10 Do not let them sit in a discharged condition. 1. Always follow the battery charging directions as outlined in the BATTERY CHARGING section of this manual. 2. Keep battery tops and terminals free from corrosion. A strong solution of baking soda i20NBV...
-
Page 11: Adjustment Of Squeegee Assembly
OPERATOR MANUAL ADJUSTMENT OF SQUEEGEE ASSEMBLY Model: i20NBV Tools: Offset spanner (17mm) Gauge block (2mm) For optimum squeegee blade performance, the squeegee assembly casters might need to be adjusted to the floor type and squeegee blade wear. Adjustment Process: 1. Turn off the machine after you lower the squeegee assembly down. -
Page 12: Basic Troubleshooting
Properly position cover Damaged recovery tank cover seal Replace seal Faulty vacuum motor Contact Dealer Low battery charge Recharge batteries Low battery charge Fully recharge batteries Short run time Defective batteries Replace batteries Faulty battery charger Repair or replace battery charger i20NBV... -
Page 13: Technical Specifications
OPERATOR MANUAL TECHNICAL SPECIFICATIONS i20NBV MODEL Brush Assist DIMENSIONS L 55.7 in / 1,415 mm DIMENSIONS W 22 in / 560 mm DIMENSIONS H 44.9 in / 1,140 mm WEIGHT 210 lbs / 95 Kg WEIGHT WITH BATTERIES 410 lbs /185 Kg RECOVERY TANK 17.2 Gal / 65 L... -
Page 14: Parts List
OPERATOR MANUAL RECOVERY TANK GROUP i20NBV... - Page 15 SLEEVE, P/M 1021830 HEX BOLT M8×30 8111015 FLOAT, SHUT-OFF 2320220 BEND 1321210 SCREW, SELF-TAPPING, ST4×10 2320216 COVER, CLEAR 2320218 GASKET, CLEAR WINDOW 1221410 SCREW M4×10 1421409 FLAT WASHER M4.3×DIA9×0.8 2320217 RUBBER HINGE 8111022 WARNING LABEL 2320216A CLEAR COVER, KIT i20NBV...
- Page 16 OPERATOR MANUAL VACUUM FAN GROUP i20NBV...
- Page 17 8112005 GASKET, VACUUM MOTOR 1121605 HEX NUT M6 8112006 STUD M6×92 8116500 VACUUM MOTOR , 24VDC, 2-STAGE, KIT 1421612 FLAT WASHER M6×DIA12×1.6 1123608 LOCK NUT M6 1914300 TIE, NYLON, 5×300 8132007 MUFFLER, VACUUM MOTOR 1221512 SCREW M5×12 8133012 BRACKET i20NBV...
- Page 18 OPERATOR MANUAL SOLUTION TANK GROUP i20NBV...
- Page 19 BALL VALVE, G1/2 8050152 SEAL 1421412 WASHER, ID4XOD12XW1 1321210 SCREW, SELF-TAPPING, ST4×10 8050153 CHAIN 8050156 LID, SOLUTION TANK FILL PORT 8050150-BK LID, KIT 8133002 CAP, SOLUTION FILL 1421409 FLAT WASHER M4×DIA9×0.8 1321110 SELF-TAPPING SCREW ST3.5×10 8133027 LABEL,BALL VALVE 8113009 NYLON, CLAMP i20NBV...
- Page 20 OPERATOR MANUAL CONTROL CONSOLE GROUP i20NBV...
- Page 21 OPERATOR MANUAL CONTROL CONSOLE GROUP PART DESCRIPTION NUMBER REQ'D 8014063 BATTERY CAPACITY INDICATOR 8134741 CONTROL PANEL DECAL, I20NBV 1221512 SCREW M5×12 1422513 LOCK WASHER M5 1421510 FLAT WASHER M5×DIA10×1.0 8134811 CONTROL PANEL, I20NBV 8134015 GASKET 8014006 WATERPROOF SWITCH 1221306 SCREW M3×6...
- Page 22 SCREW M6×16, HEX SCOKET 1534608 SET SCREW M6×8 8134301 LEVER, BAIL 8114300 ACTUATOR 8114306 SPRING 1535630 SET SCREW M6×30 8114101 SHAFT 1021512 HEX HEAD BOLT M5×12, SS 8132071-US CHARGER BRACKET,KIT 8112030A BATTERY CHARGER POWER CORD, KIT 8132020-PC ON BOARD BATTERY CHARGER i20NBV...
- Page 23 OPERATOR MANUAL FRAME & WHEEL GROUP i20NBV...
- Page 24 FLAT WASHER M8×DIA28×3 8115200 WHEEL, 8 INCH 1612607 BALL BEARING, 6004LU 1421816 FLAT WASHER M8×DIA16×1.6 8135405 SHAFT 1123810 LOCK NUT M8 8117007 NYLON WASHER DIA12.9×DIA24×2.5 8115404 BEARING, JOURNAL 8145001 BUSHING 1021840 HEX BOLT M8×40 8115500 CASTER, SWIVEL, 80MM 8115405 SLEEVE, P/M i20NBV...
- Page 25 OPERATOR MANUAL SCRUB HEAD GROUP i20NBV...
- Page 26 LOCK WASHER M10 1421030 FLAT WASHER M10×DIA30×2.5 8116202 8116205 SCREW M14×20 8111023 WARNING LABEL 1121913 HEX NUT M14 8116204 SPRING 8116210 KNOB M6 8116078 PROTECTIVE WHEEL 8115404 SLEEVE, P/M 1421824 FLAT WASHER M8×DIA24×2.0 1021825 HEX BOLT M8×25 8210803 SPACER,RUBBER i20NBV...
- Page 27 OPERATOR MANUAL SCRUB HEAD LIFT GROUP i20NBV...
- Page 28 LEFT BRACKET 8117005 SPACER 8117003 RIGHT BRACKET 1022860 HEX BOLT M8×60 8117008 SPRING 8113109 BEARING, THRUST 1022845 HEX BOLT M8×45 8117004 ROLLER 1421612 FLAT WASHER M6×DIA12×1.6 1422616 LOCK WASHER M6 1021616 HEX BOLT M6×16 8133150 SPRING 8117001 BRACKET, GUIDE i20NBV...
- Page 29 OPERATOR MANUAL SQUEEGEE GROUP i20NBV...
- Page 30 SQUEEGEE BLADE, FRONT, PU(OPTION) 8118610 SHORT CLAMP ASSEBLY 1221575 SCREW M5×75 8118200 LEFT BRACKET 1121008 HEX NUT M10 8118600A CLAMP ASSEMBLY 8118624 SHAFT 8118623 SPACER 1123507 LOCK NUT M5 8118109 HOLDER VACUUM HOSE 8118018 VACUUM HOSE 8118000-BK SQUEEGEE ASSEMBLY, LINATEX i20NBV...
- Page 31 OPERATOR MANUAL SOLUTION GROUP i20NBV...
- Page 32 FLAT WASHER M5×DIA10×1 1221512 SCREW M5×12 8119202 TUBING ID=12MM L=100MM 1221412 SCREW M4×12 1422411 LOCK WASHER M4 1421409 FLAT WASHER M4×DIA9×0.8 8119003 SOLENOID VALVE, 24VDC 1962016 CLAMP, 10-16mm 8119203 TUBING ID=12MM L=135MM 8119204 TUBING ID=10MM L=360MM 8116100 WATER SUPPLY TUBE i20NBV...
-
Page 33: Wear And Tear Parts
1612607 BEARING, BALL, 6004, 8" WHEEL 8116078 PROTECTIVE WHEEL 8118021 SQUEEGEE BLADE, FRONT, LINATEX 8118022 SQUEEGEE BLADE, REAR, LINATEX 9050020 20" BRUSH, 0.7MM PP BRISTLE, BLACK. (OPTIONAL) 9050020E 20" BRUSH, 0.5MM PP BRISTLE, BLUE. (OPTIONAL) 9040019 19" PAD HOLDER i20NBV... -
Page 34: Wiring Diagram
OPERATOR MANUAL WIRING DIAGRAM(i20NBV) BAT1: 12V battery ES1: Brush motor solenoid switch BAT2: 12V battery ES2: Vacuum motor relay CHR: Charger BR: Circuit breaker SW: Main switch EW: Solution solenoid value SW1: Vacuum motor switch M1: Brush motor SW2: Brush motor safety switch...
