Summary of Contents for Sune Technology NTG6
- Page 1 SUNE TECH Installation Manual NTG6 Manual Date 2019, 04, 24 Main 2019, 04, 23 2019, 04, 23 Firmware Date 2019, 04, 23 Tw8823...
- Page 2 SUNE TECH HD-NTG6 NTG6 Default-Power NTG6 LVDS-Cable Key-Pad NTG6 Universal NTG6 AV-Cable IR - Cable USB Cable option NTG55 Power 1on1 NTG6 Power Touch NTG6 Power 1on1 option option option...
- Page 3 SUNE TECH AV IN/OUT Navi Audio In R Ground Navi Audio In L Ground POWER / CAN AV IN Audio Out R Ground ACC IN Ground 1, 2 DVB-T Video Audio Out L Ground 3, 4 DVB-T Audio R 12V output 5, 6 DVB-T Audio L Reverse input...
- Page 4 SUNE TECH Switch Model Inch Used HDMI Input A-Class W177 / V177 10.25 Used LVDS Input A-Class W177 / V177 Used Rear Camera Input C-Class C200 10.25 Used Front Camera Input E-Class W213 12.25 Used DVB-T (CVBS) Input E-Class W213 Used DVD (CVBS) Input S-Class W222 12.25...
- Page 5 SUNE TECH Press three places using some tools. Remove #1 plastic and unscrew 2 screws. And remove the plastic cover. Take off #2 cover and unscrew 3 screws. Please cut red rectangle of connector Connect cable behind the TouchPad to supplied power cable. In order to make easy to connect OEM-connector and supplied connector.
-
Page 6: Hdmi Device
SUNE TECH HDMI DEVICE NAVIGATION REAR / FRONT NTG6-PAD 2 DVB-T Please connect 4 wires to OEM cable OMNI KEY PAS CAN L behind of the headunit. OUT 12V PAS CAN H REVERSE IN GROUND REAR 12V ACC IN A-Class 10.25inch HEADUNIT... - Page 7 SUNE TECH HDMI DEVICE NAVIGATION REAR / FRONT NTG6-PAD 2 DVB-T Please connect 4 wires to OEM cable OMNI KEY PAS CAN L behind of the headunit. OUT 12V PAS CAN H REVERSE IN GROUND REAR 12V ACC IN A-Class 7inch HEADUNIT...
- Page 8 SUNE TECH HDMI DEVICE NAVIGATION REAR / FRONT DVB-T REAR 12V REVERSE IN OUT 12V Please take off Optical Audio Line for External AMP. And OMNI KEY then connect to Connector provided. C-Class 10.25inch HEADUNIT...
- Page 9 SUNE TECH Steer Remote How to press Description of operation Return back to OEM Screen form Front 1, Back Press button for short time Screen Press button for 1 second screen is switched to Front Screen Return back to OEM Screen form Interface 2, Hang Up Press button for short time Screen...
- Page 10 SUNE TECH Steer Remote How to press Description of operation Return back to OEM Screen form Front 1, Back Press button for short time Screen Press button for 1 second screen is switched to Front Screen Return back to OEM Screen form Interface 2, Hang Up Press button for short time Screen...
- Page 11 SUNE TECH How to use ROiK10 as navigation mode If SUNE10 hardware version is v1.6. Do not have to use USB-A cable for communication. ROiK10 is controlled by touch on monitor and TouchPad.
- Page 12 SUNE TECH How to use SE-CP as navigation mode SE-CP is controlled by touch on monitor.
- Page 13 SUNE TECH HDMI How to use Asuka DTV as HDMI mode. CVBS In CVBS mode, be able to use Asuka DTV too. DVB-T IR Asuka DTV is controlled by touch on monitor.
- Page 14 SUNE TECH REAR CAMERA / OEM / 360 AVM HDMI AVM FRONT CAMERA / OEM A-Class 7inch A-Class 10.25inch...
- Page 15 SUNE TECH 1920 x 720 HDMI INPUT SOURCE DEFAULT NAVIGATION BRIGHT REAR VIEW CONSTRAST RED FRONT VIEW CONSTRAST GREEN CONSTRAST BLUE CUSTOM EXIT DIP SWITCH INFO : FIRMWARE DATE : MAIN : 2019, 02, 03 SUB : 2019, 02, 03 TW23 : 2019, 02, 03 How to press In not settings menu.
- Page 16 SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99 Copyright ⓒ 2019 by SUNE TECHNOLOGY...
