Summary of Contents for Sune Technology SUNE10 PLUS-NTG5
- Page 1 Installation Manual SUNE10 PLUS-NTG5 2019, 10, 21 Manual Date 2019, 10, 21 Main 2019, 10, 18 Firmware Date 2019, 10, 18 Tw8823...
- Page 2 SUNE10-NTG5 SUNE10-NTG5 Default-Power SUNE10-NTG5 LVDS-Cable Key-Pad SUNE10-NTG5 AV-Cable IR - Cable Capacitive Touch Cable SUNE10-NTG5 Universal Cable SUNE10-NTG50 Power 1on1...
- Page 3 Speaker GLONASS GPS WIFI/BT Antenna x 2...
- Page 4 AV IN/OUT Speaker P Speaker N Audio Out R Ground POWER / CAN AV IN Audio Out L Ground ACC IN Ground 1, 2 DVB-T Video Mic P Mic N IR – DVD-T 3, 4 DVB-T Audio R CapTouch-I2C-SCL CapTouch-Ground 12V output 5, 6 DVB-T Audio L...
- Page 5 Switch Model Inch GLE (C292), E (W212), CLS (W218), Used HDMI Input B (W246), CLA (C117) Used Rear Camera Input C (W205), GLC (x253), V (W447) Used Front Camera Input S (W222) 12.25 Used DVB-T (CVBS) Input C (W205), GLC (X253), V (W447) Used DVD (CVBS) Input List of Car Model SW10...
-
Page 6: Hdmi Device
HDMI DEVICE REAR / FRONT DVB-T Please connect ‘C’ housing of OEM with supplied housing. Battery Ground From Headunit... - Page 7 COMAND How to press Description of operation Controller Return back to OEM Screen form Interface 1, Back Press button for short time Screen Screen is switched in that order switches are Press button for 1 second activated. Press button for 10 second System would be reset.
- Page 8 How to make calibration for touch: Enter settings mode. Press up button of k-pad for 3 sec. Press the 5 cross in order to make calibration for touch. SELECT TOUCH PANEL When need to set touch panel settings. Select touch panel which you want to use. * Most panel types do not need to be selected.
- Page 9 REAR CAMERA / OEM / 360 AVM HDMI AVM FRONT CAMERA / OEM Monitor resolution : 960 x 540 Monitor resolution : 800 x 480...
- Page 10 1920 x 720 HDMI INPUT SOURCE DEFAULT NAVIGATION BRIGHT REAR VIEW CONSTRAST RED FRONT VIEW CONSTRAST GREEN CONSTRAST BLUE CUSTOM EXIT DIP SWITCH INFO : FIRMWARE DATE : MAIN : 2019, 02, 03 SUB : 2019, 02, 03 TW23 : 2019, 02, 03 How to press In not settings menu.
- Page 11 SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX:+88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99 Copyright ⓒ 2019 by SUNE TECHNOLOGY...
