Summary of Contents for Sune Technology NTG5.5
- Page 1 Installation Manual Interface for Mercedes Benz NTG5.5 & NTG6.0...
- Page 2 Compatibility: Mercedes Benz NTG5.5 Components: Interface Main *1 Interface Input / Output specification: Input: LVDS IN (Car System) *1 Analog RGB *1 CVBS(Front Camera) *1 CVBS(Rear Camera) *1 Output: LVDS OUT (Car System) *1 Power Spec: Input Power: 8VDC ~ 18VDC...
- Page 3 UART Cable Remote Control Button Cable IR Cable Rear Cable REMOTE0001 HTOUCH0031 HARETC0001 HIRCAB0002 HARETC0002 * Power/CAN/LVDS for NTG5.5 Single Fakra Cable Power Cable CAN J BY J T/S Out Cable HAGPSC0003 HPOWER0177 HARETC0091 HTOUCH0009 * Power/CAN/LVDS for NTG6.0 [OPTION]...
-
Page 4: Rear Camera
* ON : DOWN / OFF : UP Please make sure to disconnect the power cable of the interface and reconnect the power cable again to apply the dip switch changes. FUNCTION Dip S/W SELECT OFF : RGB MODE ON : RGB MODE SKIP No Use No Use No Use... - Page 5 FUNCTION POWER & PIP MENU Activating OSD menu Making a selection, changing image display ▲ Moving upward ▼ Moving downward Moving leftward ◀ (If you press this button 2 seconds long, you can access the factory mode) Moving rightward ▶ (If you press this button 2 seconds long, you can reset all the data about user environment)
- Page 6 Menu of FACTORY IMAGE IMAGE H-POSITION PARK V-POSITION H-POSITION: Move the screen left and right. UTIL H-SIZE(NAVI) INFO V-POSITION: Move the screen up and down. H-SIZE (NAVI): Adjust the left and right size of MENU to Return SEL to Select/Save navigation.
- Page 7 Menu of FACTORY UTIL1 IMAGE AVOUT SELECT AVOUT SELECT: PARK AUTO FCAM TIME UTIL1 FCAM FUNC Select audio channel transmitted through AUX (HDMI, UTIL2 NAVI MODEL INFO HDMI MODEL FACTORY RESET AUTO FCAM TIME: MENU to Return SEL to Select/Save Front camera operation time adjustment FCAM FUNC: Select front camera display (ORI.
- Page 8 * Press high lighted OEM button for 3 seconds long to mode switch...
- Page 9 1. Rear Camera Mode Switch Pushing Monitor shuttle Mode Mode Joy shuttle Direction Rear, Front Ext. Camera <-> OEM 12.3inch Camera Short Screen mode Rear, Front Ext. Camera <-> OEM 8inch Camera Short Screen mode 2. DVD, DTV OSD control ( OSD control remote will appear if the joy shuttle is moved to the left for a short time in DVD, DTV mode) Pushing Monitor...
- Page 10 * Press high lighted OEM button for 3 seconds long to mode switch • Rear Camera Mode Switch : Short press below high lighted button in Ext. rear camera mode to switch OEM screen...
- Page 11 * Side View for QLI-W213...
- Page 12 * Please refer next page for LVDS in/out UART Touch Cable connection Pin assignment Supplied Res. touch Cable * Side View External Res. touch screen * Side View * Please refer next Rear camera input *1 page for power/CAN Front camera input *1 connection NAVIGATION Supplied Cap.
- Page 13 QDIS doesn’t supply this cable...
- Page 14 LCD cable 1: Remove the original green LCD cable. 2: Connect the original LVDS cable with the interface “LVDS IN” cable. Connect the other side of the “LVDS IN” cable with the interface input “ LVDS IN ”. 3: Connect the interface “LVDS OUT” cable with the video interface input “VIDEO OUT” and the other side with Command screen.
- Page 15 Find the beige color connector behind the command 10.25 inch monitor command QDIS adapter Remove the right wire from the beige color connector and connect it to QDIS adapter Then, connect QDIS adapter to LVDS out of the interface Connect the supplied LVDS IN wire to the right side of beige color connector.
- Page 16 Find the red color double Fakra connector behind the command 10.25inch monitor command OEM Angle type double Fakra connector OEM Cable Please use A Class LCD J by J cable OEM HU...
- Page 17 * CAN IN/OUT connection for NTG5.5 - Find a bunch of wires from the command behind the monitor as shown below Find a bunch of Take away the black Remove the black cables from the connector cover connector marked command behind...
-
Page 18: Power Cable
* CAN IN/OUT Connection for NTG6.0: Pleas find a bunch of wires from the command behind the monitor as shown below (Black Connector) -> Now we have Power/CAN Jack by Jack cable, so no just connect with plug and play, no need to wire, please follow below steps: 1. - Page 19 Q. I cannot change mode A. Check connection of Ground cable and IR Cable. Check LED lamp is on, if not check connection of POWER cable. Q. All I got on the screen is black. A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well.
- Page 20 SUNE TECHNOLOGY CO.,LTD No.9,Lane 606,Anping Rd,Tainan City 70849,TAIWAN TEL:+88662292246 FAX: +88662288104 Http://www.sune-tech.com Shop http://www.carnavi-tech.com SKYPE:sune_tech or hsin_han99 Copyright ⓒ 2019 by SUNE TECHNOLOGY...
