Recommended transmission distances at 60 Hz
Video MTP SW6 Pre-Peak
format
Off
Component,
S-video, <300' (90 m)
composite
640 x 480 <300' (90 m)
800 x 600 <300' (90 m)
1024 x 768* <300' (90 m)
1280 x 960* <300' (90 m)
1280 x 1024* <250' (75 m)
1360 x 765 <250' (75 m)
1365 x 768 <250' (75 m)
1366 x 768 <250' (75 m)
1440 x 900 <250' (75 m)
1400 x 1050 <250' (75 m)
1600 x 1200* <250' (75 m)
1920 x 1200 <250' (75 m)
HDTV 720p <250' (75 m)
HDTV 1080i <250' (75 m)
HDTV 1080p <250' (75 m)
High quality
a
On Input
>350' (105 m) 700' (215 m)
>350' (105 m) 550' (170 m)
>350' (105 m) 500' (150 m)
>350' (105 m) 450' (135 m)
>350' (105 m) 350' (105 m)
>300' (90 m) 350' (105 m)
>300' (90 m) 350' (105 m)
>300' (90 m) 350' (105 m)
>300' (90 m) 350' (105 m)
>300' (90 m) 350' (105 m)
>300' (90 m) 350' (105 m)
>300' (90 m) 300' (90 m)
>300' (90 m) 300' (90 m)
>300' (90 m) 400' (120 m)
>300' (90 m) 300' (90 m)
>300' (90 m) 300' (90 m)
Variable quality
b a
Output Input
700 (215 m) 700' (215 m)
600' (185 m) 550' (170 m)
500' (150 m) 600' (185 m)
450' (135 m) 550' (170 m)
350' (105 m) 450' (135 m)
350' (105 m) 450' (135 m)
350' (105 m) 500' (150 m)
350' (105 m) 450' (135 m)
350' (105 m) 450' (135 m)
300' (90 m) 400' (120 m)
300' (90 m) 400' (120 m)
300' (90 m) 450' (135 m)
250' (75 m) 400' (120 m)
400' (120 m) 500' (150 m)
250' (75 m) 400' (120 m)
250' (75 m) 400' (120 m)
b
Output
800 (245 m)
700' (215 m)
600' (185 m)
550' (170 m)
450' (135 m)
450' (135 m)
500' (150 m)
450' (135 m)
450' (135 m)
400' (120 m)
400' (120 m)
450' (135 m)
400' (120 m)
500' (150 m)
400' (120 m)
400' (120 m)
