CURIOSIS FACSCOPE B Quick Start Manual

Hide thumbs Also See for FACSCOPE B:

Advertisement

Quick Links

Download this manual
Automatic Bright-field Cell Counter
Quick Start Manual, Version 3.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the FACSCOPE B and is the answer not in the manual?

Questions and answers

Related Manuals for CURIOSIS FACSCOPE B

Summary of Contents for CURIOSIS FACSCOPE B

  • Page 1 Automatic Bright-field Cell Counter Quick Start Manual, Version 3.0...

  • Page 2: Device Layout

    Device Layout...
  • Page 3 Front Layout Slide Holder Door Touch LCD Display Button 1(Insert/Eject slide holder) Button 2(Home screen) Button 3(Setting screen)
  • Page 4 Back Layout USB Port - Keypad Power Switch - Barcode Scanner - Thermal Printer - USB Memory Power Cable Socket Ethernet Port - PC Interface...

  • Page 5: Basic Operation

    Basic Operation...

  • Page 6: Installation

    1. Installation Step 1. Remove the product from the box. Step 2. Connect the power cable. Step 3. Turn on the device.
  • Page 7 2. Power up Initializing Home screen (Slide holder is automatically ejected.)
  • Page 8 3. Sample preparation Step 1. Prepare cell suspension, trypan blue, micro tube and C-slide. Step 2. Place at least 20 μL of trypan blue in the micro tube and add an equal volume of the cell suspension. Step 3. Mix the sample in the micro tube by pipetting the vial 3~5 times gently. Step 4.
  • Page 9 4. Start Counting _ Quick start Home screen Load a slide. Press Start button. Home Completion Counting...

  • Page 10: Additional Operation

    Additional Operation...
  • Page 11 •Preview prior to counting In the screen where you can see the cells, when tap the screen twice, some icons disappear. To get icons again, tap the screen twice. Select a channel to preview. Load a slide and press Preview button. Positioning and Autofocusing See the cell image of the selected channel.
  • Page 12 • Making a stop while counting Press STOP button. Press Continue button. Counting has been stopped.
  • Page 13 •Counting with setting option Load a slide. Press the User button. Select the User 1/2/3. Press the Normal(Count mode) and Preset button. Press the Channel button. Select Count mode and Preset. Continue to the next page →...
  • Page 14 •Counting with setting option Press the Channels to be disabled/enabled. Counting Press the Start button to count immediately. Setting options for counting Preset User : 1/2/3 User-changeable parameters for cell recognition Auto-saved data and presets can be managed as user number. 3 kinds of fixed presets Channel Count mode : Quick/Normal/Precise...
  • Page 15 •Preset _ Create To create your own preset, Select one of 3 fixed presets(Universal, Small, Angular), Press Plus button. press Preset button. and press blank beside Index. primary T primary T Adjust 3 kinds of parameters Type the names of Index and Preset ID. Ready to counting with a customized preset.
  • Page 16 •Preset _ Edit Users can manage Preset items. 3 fixed presets cannot be removed or edited. To edit your own preset, Press the preset button Adjust the parameters of your own preset. press Preset button. which you created by yourself. primaryT To delete your own preset, Press Save button...
  • Page 17 •Enter Channel ID _ Basically JurkatT Channel ID Press Channel ID button. Press a blank. Type the names of each Channel ID. Channel ID JurkatT Hela U937 Ready to counting. Press Back button.
  • Page 18 •Enter Channel ID _ Typing at once or Using extra devices Typing 4 IDs at once JurkatT Channel ID Channel ID JurkatT_1 JurkatT_2 JurkatT_3 JurkatT_4 Check if 4 channel IDs are written, Enter the name of cell type Press All button. then press Back button.
  • Page 19 •Result_Analysis(Histogram) toggle between histogram and result image once select a channel. 12 - 26 12 - 34 Home Press a channel which you want to check, Press All to check the average data of all channels. Move both columns and adjust the cell size. and switch to the histogram icon.
  • Page 20 •Result_Analysis(Result Image) Home Press a channel which you want to check, Press Data icon. Adjust Live / Dead cell definition. and switch to the Image icon. ▪ Once press button, see the result images of selected channel at once. ▪ Return to default : The changed value returns to default.
  • Page 21 USB memory from USB port. Print Result Connect USB Thermal Printer (Optional) to the USB port at the back side of the device. Check if icon appears on status bar. FACSCOPE B Results Exp. Date : 2019-04-01 09:00:00...
  • Page 22 •Review and Export record(CSV file) FACSCOPE B automatically saves data up to 1000 volume. Select User. Connect USB memory Press Review. (check if icon appears on status bar), and press Export CSV. CSV data is now exporting... Once “ Export success” message appears, This means the number of current auto-saved remove the USB memory from USB port.
  • Page 23 •Result_ Show ID Channel ID JurkatT Hela U937 Home Home To go back, press Back. To see each of Channel IDs, press Channel ID.
  • Page 24 •Setting screen Press FN button to get into the Setting screen.
  • Page 25 •F/W info & Update Current version : 1.0 New version : 1.01 Choose the category to update(Main or Display). Press F/W info & Update, Press Update button. If USB memory is disconnected or it doesn’t have and connect USB memory. updated program, the message will notice it.
  • Page 26 •Bead QC Check the image STOP Load a standard slide Press Bead QC button. Counting and press START button. Check the image Check the image Check the image Check the image Home 12 - 34 Return to Home screen. Check the result amount. Check the Histogram and Bead image.
  • Page 27 •Time Adjust date and time. Press Set button. Press Time button. 12 12 Return to Home screen.
  • Page 28 Copyright ©2019, by CURIOSIS, Inc. All rights reserved. Published in Korea. Revision History: V.0.0 Date: 2019/03/05 V.1.0 Date: 2019/03/20 V.2.0 Date: 2019/05/24 V.3.0 Date: 2019/10/18...
  • Page 29 Curiosis Inc. 10 Teheran-ro 38-gil, Gangnam-gu, Seoul, Republic of Korea T: 82 2 508 5236 F: 82 2 508 5246 www.curiosis.co.kr...
