  • Page 1 ® R&S AREG800A Automotive Radar Echo Generator Getting Started (;ÝT92) 1179360902 Version 02...
  • Page 2 ® 1179.3609.02 | Version 02 | R&S AREG800A Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol, e.g. ® ® R&S AREG800A is indicated as R&S AREG800A and R&S QAT100 is indicated as R&S QAT100.

  • Page 3: Table Of Contents

    4 Preparing for use..............15 4.1 Lifting and carrying................15 4.2 Unpacking and checking..............15 4.3 Choosing the operating site.............. 16 4.4 Setting up the R&S AREG800A............16 4.5 Considerations for test setup............18 4.6 Connecting to power................20 4.7 Connecting to LAN................20 4.8 Connecting USB devices..............
  • Page 4 ® Contents R&S AREG800A 4.13 Switching on or off................27 5 Instrument tour..............31 5.1 Front panel tour.................. 31 5.2 Rear panel tour..................37 6 Trying out the instrument........... 45 6.1 Configuring static operation setups..........45 6.2 Saving and recalling settings............47 7 Instrument control...............

  • Page 5: Safety And Regulatory Information

    ® Safety and regulatory information R&S AREG800A Safety Instructions Safety and regulatory information The product documentation helps you use the product safely and efficiently. Fol- low the instructions provided here and in the following chapters. Intended use The product is intended for the development, production and verification of elec- tronic components and devices in industrial, administrative, and laboratory envi- ronments.
  • Page 6 ® Safety and regulatory information R&S AREG800A Safety Instructions Never open the casing of the product. Only service personnel authorized by Rohde & Schwarz are allowed to repair the product. If any part of the product is damaged or broken, stop using the product. Contact Rohde & Schwarz customer service at http://www.customersupport.rohde-schwarz.com.
  • Page 7 ® Safety and regulatory information R&S AREG800A Safety Instructions If you mount products in a rack, ensure that the rack has sufficient load capacity and stability. Observe the specifications of the rack manufacturer. Always install the products from the bottom shelf to the top shelf so that the rack stands securely.

  • Page 8: Labels On R&S Areg800A

    Table 1-1: Labels regarding R&S AREG800A and environment safety Labeling in line with EN 50419 for disposal of electrical and electronic equipment after the product has come to the end of its service life. For more information, see the prod- uct user manual, chapter "Disposal".
  • Page 9 ® Safety and regulatory information R&S AREG800A Warning messages in the documentation WARNING Potentially hazardous situation. Could result in death or serious injury if not avoi- ded. CAUTION Potentially hazardous situation. Could result in minor or moderate injury if not avoided.
  • Page 10 ® Safety and regulatory information R&S AREG800A Warning messages in the documentation Getting Started 1179.3609.02 ─ 02...

  • Page 11: Documentation Overview

    Includes the contents of the getting started manual. The contents of the user manual are available as help in the R&S AREG800A. The help offers quick, context-sensitive access to the complete information for the instrument and its firmware.

  • Page 12: Data Sheet

    R&S AREG800A Release notes and open-source acknowledgment (OSA) Data sheet The data sheet contains the technical specifications of the R&S AREG800A. It also lists the firmware applications and their order numbers, and optional acces- sories. Release notes and open-source acknowledg-...

  • Page 13: Key Features

    R&S AREG800A Key features The R&S AREG800A is a new high performance Automotive Radar Echo Gener- ator developed to meet demanding customer requirements. Offering excellent radar signal characteristics, wide radar signal bandwidth and straightforward and intuitive operation, the R&S AREG800A makes radar signal generation fast and easy.
  • Page 14 ® Key features R&S AREG800A Getting Started 1179.3609.02 ─ 02...

  • Page 15: Preparing For Use

    Here, you can find basic information about setting up the product for the first time. Lifting and carrying ► WARNING! The R&S AREG800A can be heavy, e.g., if fully equipped. Use a lifting equipment, see also "Lifting and carrying the product"...

  • Page 16: Choosing The Operating Site

    "Intended use" on page 5 4.4.1 Placing the R&S AREG800A on a bench top To place the product on a bench top 1. Place the product on a stable, flat and level surface. Ensure that the surface can support the weight of the product. For information on the weight, see the data sheet.
  • Page 17 ● Do not place the product next to heat-generating equipment such as radia- tors or other products. 4.4.2 Mounting the R&S AREG800A in a rack To prepare the rack 1. Observe the requirements and instructions in "Setting up the product"...

  • Page 18: Considerations For Test Setup

    Considerations for test setup To mount the R&S AREG800A in a rack 1. Use an adapter kit that fits the dimensions of the R&S AREG800A to prepare the instrument for rack mounting. a) Order the rack adapter kit designed for the R&S AREG800A. For the order number, see data sheet.
  • Page 19 23 Signal input and output levels Information on signal levels is provided in the data sheet. Keep the signal levels within the specified ranges to avoid damage to the R&S AREG800A and connec- ted devices. To block DC components ►...

  • Page 20: Connecting To Power

    1. Plug the AC power cable into the AC power connector on the rear panel of the instrument. Only use the AC power cable delivered with the R&S AREG800A. 2. Plug the AC power cable into a power outlet with ground contact.

  • Page 21: Connecting Usb Devices

    ► Connect the LAN socket via an RJ-45 cable to the LAN. By default, the R&S AREG800A is configured to use DHCP (dynamic host config- uration protocol) and no static IP address is configured. If switched on and connected to the LAN, the R&S AREG800A displays the address information on the screen.

  • Page 22: Connecting The R&S Qat100

    R&S AREG800A and the R&S QAT100. To prepare for connecting For the IF connection, the R&S AREG800A and the R&S QAT100 provide female SMA connectors. 1. NOTICE! Damaged or not clean connections can lead to RF insertion loss and mismatch, and even premature wear of the connectors.
  • Page 23 "To block DC com- ponents" on page 19. 3. If the R&S AREG800A is switched on, deactivate the RF output, before con- necting the RF cable to the SMA connectors. On the front panel, press the key [RF On/Off]. 4. For connection, use the RF cable within the delivery of the R&S QAT100.

  • Page 24: Connecting To Ref In/Ref Out

    See also Chapter 4.7, "Connecting to LAN", on page 20. Table 4-2 provides an overview on relevant connections. Table 4-2: Example: Connections between R&S AREG800A and R&S QAT100 Signal (direction) R&S AREG800A connector R&S QAT100 connector "Tx Ʃ" IF out (Tx) "Tx IF Out 1"...

  • Page 25: Connecting To Aux If In/Aux If Out

    (TRX CRTL Cable). These cables are calibrated and dedicated to the particular TRX frontend. Each cable has its own serial number, printed on it. To connect the R&S AREG800A and the TRX frontend with the "IF TX CBL"/"IF RX CBL" cables 1.
  • Page 26 ● Do not cover the TRX frontend module with thermally insulating material while the R&S AREG800A is switched on. ● See also Chapter 4.4.1, "Placing the R&S AREG800A on a bench top", on page 16. Getting Started 1179.3609.02 ─ 02...

  • Page 27: Switching On Or Off

    Switching on or off To disconnect the TRX frontend 1. NOTICE! If you connect or disconnect the control cable while the base unit is powered on, you can damage the R&S AREG800A. Switch off the base unit. "To shut down the product"...
  • Page 28 The LED changes to green. The R&S AREG800A boots. When starting for the first time, the R&S AREG800A starts with the default settings. When restarting the instrument, the settings depend on the instru- ment configuration before shut-down. See the chapter "Saving and Recalling Instrument Settings" in the user man- ual.
  • Page 29 Shut it down first. Set the toggle switch on the power supply to position [0]. The LED of the [On/Standby] key is switched off. 2. Disconnect the R&S AREG800A from the power source. Getting Started 1179.3609.02 ─ 02...
  • Page 30 ® Preparing for use R&S AREG800A Switching on or off Getting Started 1179.3609.02 ─ 02...

  • Page 31: Instrument Tour

    This chapter explains the control elements and the connectors of the R&S AREG800A. The views of the front panel and the rear panel help you to get familiar with the instrument and to perform first steps. For specifications of the interfaces, see the data sheet.
  • Page 32 ® Instrument tour R&S AREG800A Front panel tour Navigation controls, page 35 Display keys, page 36 SD card slot, page 37 USB, page 37 Sensor, page 37 On/Standby, page 33 5.1.1 Touchscreen The most important settings are displayed on the screen on the front panel. The screen display also provides status and setting information and allows you to quickly reconfigure the signal flow.
  • Page 33 ● Chapter "Cleaning" in the user manual, for cleaning the touchscreen. 5.1.2 Keys 5.1.2.1 Utility keys The utility keys cause the R&S AREG800A to return to a defined instrument state and provide information on the instrument and assistance. Table 5-1: Utility keys Utility key Assigned functions...
  • Page 34 ® Instrument tour R&S AREG800A Front panel tour 5.1.2.3 Function keys Function keys provide access to the most common generator settings and func- tions. You can find a detailed description of the corresponding functions in the user manual. Table 5-2: Function keys...
  • Page 35 ® Instrument tour R&S AREG800A Front panel tour 5.1.2.5 Navigation controls The navigation controls include a rotary knob, navigation keys, and the display keys. They allow you to navigate within the display or within dialog boxes. Rotary knob The rotary knob has several functions: ●...
  • Page 36 At the end of a list, the cursor is set on the first entry again. [Undo] Reverts the last operation. [User] Adds a parameter to the user menu for quick access. 5.1.3 Connectors Various interface connectors are on the front panel of the R&S AREG800A. Getting Started 1179.3609.02 ─ 02...

  • Page 37: Rear Panel Tour

    The connector is a six-pole ODU Mini-Snap series B connector. A power sensor is connected to the R&S AREG800A by inserting the male con- nector. To disconnect, pull the connector by its sleeve. You cannot disconnect the sensor simply by pulling at the cable or the rear part of the connector.
  • Page 38 R&S AREG800A Rear panel tour Figure 5-3: R&S AREG800A rear panel Connectors for control, synchronization and multi-purpose signals, page 39 Power switch, power supply, monitor, LAN and USB connectors, page 41 Digital IO DD connectors and instrument boards, page 42...
  • Page 39 ® Instrument tour R&S AREG800A Rear panel tour 5.2.1 Control, synchronization and multi-purpose connectors Figure 5-4: Connectors for control, synchronization and multi-purpose signals Control, page 39 Real Time Control, page 39 System Control, page 40 Sync In, Sync Out, page 40...
  • Page 40 The interface is in compliance with the standards IEC 625, IEEE 488 and SCPI. Use this interface to connect a computer for remote control of the R&S AREG800A. To set up the connection, use high-quality shielded cables. See "Cable selection and electromagnetic interference (EMI)" on page 18.
  • Page 41 AC power supply connector and switch, page 41 DP, HDMI Display port (DP) and HDMI port for connecting external monitor. RJ-45 connector to connect the R&S AREG800A to a LAN for remote control, remote operation, and data transfer. How to: Chapter 4.7, "Connecting to...
  • Page 42 ® Instrument tour R&S AREG800A Rear panel tour 5.2.3 DIG I/Q and RF connectors Figure 5-6: Digital IO DD connectors and instrument boards Digital IO DD, page 42 2, 10 = Aux IF In, page 42 3, 9 = Aux IF Out, page 42...
  • Page 43 Rx IF Out SMA female connectors "Rx IF Out 1" and "Rx IF Out 2" for input of the intermedi- ate frequency (IF) signal from the external frontend to the R&S AREG800A (Rx); two connectors per instrument board (R&S AREG8-B9).
  • Page 44 ® Instrument tour R&S AREG800A Rear panel tour Getting Started 1179.3609.02 ─ 02...

  • Page 45: Trying Out The Instrument

    Configuring static operation setups Trying out the instrument This chapter introduces the first steps with the R&S AREG800A. It shows how to operate and configure the instrument using simple examples. The complete description of the functionality and its usage is given in the R&S AREG800A user manual.
  • Page 46 ® Trying out the instrument R&S AREG800A Configuring static operation setups 4. Click "Apply". The settings are applied. To specify the radar channel bandwidth 1. In the tile diagram, select "Operation Setup > Bandwidth Config". 2. Set the bandwidths of the radar channels, e.g. "Bandwidth A > 1 GHz".

  • Page 47: Saving And Recalling Settings

    ® Trying out the instrument R&S AREG800A Saving and recalling settings The bandwidth settings for an external frontend connected to board "A" are applied. Saving and recalling settings To restore the results of our measurements later, we save the instrument settings in a file.
  • Page 48 ® Trying out the instrument R&S AREG800A Saving and recalling settings 5. Click "Save". The file MyTestSignal.savrcltxt is stored in the default direc- tory /var/user/. To load saved instrument settings You can restore the settings to the instrument at any time using the settings file.
  • Page 49 ® Trying out the instrument R&S AREG800A Saving and recalling settings How to display all parameters with values different to their preset val- When you load a file to your instrument, you do not have enough informa- tion on the changed settings. In such case, it is useful to visualize all param- eters that have been changed from their default state.
  • Page 50 ® Trying out the instrument R&S AREG800A Saving and recalling settings Getting Started 1179.3609.02 ─ 02...

  • Page 51: Instrument Control

    ® Instrument control R&S AREG800A Possible ways to operate the instrument Instrument control This chapter provides an overview on how to work with the R&S AREG800A. It covers the following topics: ● Possible ways to operate the instrument............51 ●...

  • Page 52: Means Of Manual Interaction

    Understanding the display information The home screen of the R&S AREG800A displays all main settings and generator states, divided into three main operation areas. ●...
  • Page 53 ● Info line The "Info line" shows brief status information and error messages. It appears when an event generates a message. If selected, the R&S AREG800A shows information on static errors and the error history. ● Key parameters indicated in tab labels Most dialogs are divided into tabs with logically grouped parameters.

  • Page 54: Accessing The Functionality

    ® Instrument control R&S AREG800A Accessing the functionality Accessing the functionality All functionalities are provided in dialog boxes as known from computer pro- grams. You can control the instrument intuitively with the touchscreen. This sec- tion provides an overview of the accessing methods.

  • Page 55: Entering Data

    ® Instrument control R&S AREG800A Entering data ● Tap the required tile, and then the menu entry. ● Tap the minimized view (button) on the taskbar. Some of the utility keys access a dedicated dialog, too. To minimize a dialog box ►...
  • Page 56 Tip: For quick unit change, you can enter shortcuts, e.g. for a frequency value 1e8h for 100 MHz. For an overview of shortcuts supported by the R&S AREG800A, see chapter "Unit Shortcuts" in the appendix of the user manual. 3. If the parameter does not require a unit, confirm the entered value by pressing "Enter".

  • Page 57: Getting Information And Help

    ® Instrument control R&S AREG800A Getting information and help 7.5.2 Entering alphanumeric parameters If a field requires alphanumeric input, you can use the on-screen keyboard to enter letters and (special) characters. 7.5.3 Undo and redo actions Accessed via the context-sensitive menus, "Undo" allows you to restore one or more actions on the instrument.
  • Page 58 ® Instrument control R&S AREG800A Getting information and help Contents of the help dialog box The help dialog box covers two main areas: ● "Contents" - contains a table of help contents ● "Topic" - contains a specific help topic The help system also provides an "Index"...

  • Page 59: Remote Control

    The corresponding help topic is displayed. Remote control In addition to working with the R&S AREG800A interactively, located directly at the instrument, it is also possible to operate and control it from a remote PC. The R&S AREG800A supports various methods for remote control: ●...

  • Page 60: Remote Operation Over Vnc

    Thus, remote operation of the instrument is possible. Instrument control from a remote computer To access the basic utility functions of the R&S AREG800A, perform a right mouse click the block diagram and select "Key Emulation". A key panel to the right of the block diagram gives access to the utility func- tions provided by the front panel keys.

  • Page 61: Contacting Customer Support

    ® Contacting customer support R&S AREG800A Contacting customer support Technical support – where and when you need it For quick, expert help with any Rohde & Schwarz product, contact our customer support center. A team of highly qualified engineers provides support and works with you to find a solution to your query on any aspect of the operation, program- ming or applications of Rohde &...
  • Page 62 ® Contacting customer support R&S AREG800A Getting Started 1179.3609.02 ─ 02...

  • Page 63: Index

    ® Index R&S AREG800A Index Active elements ........53 Help ........... 11, 57 Alphanumeric parameters ....... 57 Info line ............ 53 Bench top, placing ........16 Input connector ........40 Instrument Carrying ..........15 Checking ..........15 Carrying the instrument ......15 Lifting ..........
  • Page 64 ® Index R&S AREG800A Remote access see Remote operation from a computer ............51 Connecting ..........20 Remote control ........59 Environment ........20 Remote operation ........60 Lifting the instrument ....... 15 Rotary knob ..........35 Loading Trying out ..........48 Safety instructions .......
