  • Page 1 ® R&S SMCVB-K156 T-DMB/DAB User Manual (;Ý:M2) 1179102902...
  • Page 2 This document describes the following software options: ● R&S ® SMCVB-K156 1434.3731.02 This manual describes firmware version FW 4.70.176.xx and later of the R&S ® SMCV100B. © 2020 Rohde & Schwarz GmbH & Co. KG Mühldorfstr. 15, 81671 München, Germany...

  • Page 3: Table Of Contents

    ® Contents R&S SMCVB-K156 Contents 1 Preface....................7 About this Manual......................7 Documentation Overview..................... 8 1.2.1 Getting Started Manual....................8 1.2.2 User Manuals and Help....................8 1.2.3 Service Manual....................... 8 1.2.4 Instrument Security Procedures..................9 1.2.5 Printed Safety Instructions....................9 1.2.6 Data Sheets and Brochures.................... 9 1.2.7...
  • Page 4 ® Contents R&S SMCVB-K156 4.2.2 Info..........................21 4.2.3 IP Channnel x Settings....................22 Network Settings......................26 SFN Settings........................28 Special Settings......................30 Global Connector Settings..................31 TS Player........................31 4.7.1 TS Player Settings......................32 4.7.2 Player Output........................ 35 4.7.2.1 General......................... 36 4.7.2.2 Stuffing.......................... 37 4.7.3 Seamless Loop Settings....................
  • Page 5 ® Contents R&S SMCVB-K156 Glossary: Specifications..............75 List of Commands................76 Index......................78 User Manual 1179.1029.02 ─ 02...
  • Page 6 ® Contents R&S SMCVB-K156 User Manual 1179.1029.02 ─ 02...

  • Page 7: Preface

    1.1 About this Manual This user manual provides all the information specific to the T-DMB/DAB option R&S SMCVB-K156. All general instrument functions and settings common to all appli- cations and operating modes are described in the main R&S SMCV100B user manual.

  • Page 8: Documentation Overview

    ® Preface R&S SMCVB-K156 Documentation Overview The screenshots usually show a fully equipped product, that is: with all options instal- led. Thus, some functions shown in the screenshots may not be available in your par- ticular product configuration. 1.2 Documentation Overview This section provides an overview of the R&S SMCV100B user documentation.

  • Page 9: Instrument Security Procedures

    ® Preface R&S SMCVB-K156 Documentation Overview https://gloris.rohde-schwarz.com 1.2.4 Instrument Security Procedures Deals with security issues when working with the R&S SMCV100B in secure areas. It is available for download on the Internet. 1.2.5 Printed Safety Instructions Provides safety information in many languages. The printed document is delivered with the product.

  • Page 10: Welcome To The T-Dmb/Dab Option

    R&S SMCVB-K156 Accessing the T-DMB/DAB Dialog 2 Welcome to the T-DMB/DAB Option The R&S SMCVB-K156 is a firmware application that adds functionality to generate signals in accordance with the T-DMB/DAB digital standard. The R&S SMCVB-K156 option features: ● T-DMB/DAB signal generation This user manual contains a description of the functionality that the application pro- vides, including remote control operation.

  • Page 11: Scope

    ® Welcome to the T-DMB/DAB Option R&S SMCVB-K156 Notes on Screenshots 2.2 Scope Tasks (in manual or remote operation) that are also performed in the base unit in the same way are not described here. In particular, it includes: ●...

  • Page 12: About The T-Dmb/Dab Option

    ● Base unit ● Option Enable Broadcast Standard (R&S SMCVB-K519) ● Option T-DMB/DAB (R&S SMCVB-K156) 3.2 About DAB/T-DMB The R&S SMCV100B enables you to generate signals in accordance with the Digital Audio Broadcasting (DAB)/Terrestrial Digital Multimedia Broadcasting (T-DMB) stan- dard.

  • Page 13: Dab Network

    ® About the T-DMB/DAB Option R&S SMCVB-K156 About DAB/T-DMB 3.2.1 DAB Network The figure bellow illustrates the outline of a DAB network. Figure 3-1: DAB network The DAB network has three main parts: the service or service component provider, the multiplex or ensemble provision and the transmission network provision.

  • Page 14: Transport Mechanisms

    ® About the T-DMB/DAB Option R&S SMCVB-K156 About DAB/T-DMB 3.2.3 Transport Mechanisms The DAB system is designed to carry several digital audio signals together with data signals. Audio and data signals are considered to be service components which can be grouped together to form services.

  • Page 15: Transport Modes

    ® About the T-DMB/DAB Option R&S SMCVB-K156 About DAB/T-DMB The data, carried in the MSC, is divided at source into regular 24 ms bursts corre- sponding to the sub-channel data capacity of each CIF. The CIF contains 55 296 bits, divided at 864 capacity units, 64 bits each.

  • Page 16: Time Interleaving

    ® About the T-DMB/DAB Option R&S SMCVB-K156 About DAB/T-DMB for audio services, equal error protection (EEP) for audio and data services. The sam- pling frequency is respectively 48 kHz and 24 kHz. The convolutional coder is a punctured convolution code, based on a mother convolu- tional code with constraint length 7 and rate 1/4.

  • Page 17: Dmb/Dab Configuration And Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 General Settings 4 T-DMB/DAB Configuration and Settings Access: ► Select "Baseband > T-DMB/DAB". The remote commands required to define these settings are described in Chapter 6, "Remote-Control Commands", on page 48. Settings: ●...

  • Page 18: Input Signal Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings Set To Default Calls the default settings. The values of the main parameters are listed in the following table. Parameter Value State Not affected by the "Set to Default" Remote command: on page 49 [:SOURce<hw>]:BB:TDMB:PRESet...

  • Page 19: General Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings Common input signal settings The setting of the following parameters is used for all broadcast standards. ● "Source" ● "Input" Settings: ● General Settings..................... 19 ● Info.......................... 21 ● IP Channnel x Settings....................22...
  • Page 20 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings "External" Uses the external ETI signal present at the input connector. Signal requirements: ● ETI (NI), ETI (NA 5592) or ETI (NA 5376) signal ● HDB3-coded ● Nominal voltage level: ±2.37 V ●...

  • Page 21: Info

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings "ETI (NA 5592)" 5592 signal. "ETI (NA 5376)" ETI NA 5376 signal. Remote command: on page 51 [:SOURce<hw>]:BB:TDMB:ETIinput? Number of Streams Displays the number of streams contained in the ETI signal.

  • Page 22: Ip Channnel X Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings Subchannel Id (Hex) ← Info Displays the subchannel identifiers. Remote command: on page 53 [:SOURce<hw>]:BB:TDMB:SCID<ch> Protection Profile ← Info Displays the protection profile. "UEP" Unequal error protection "EEP" Equal error protection...
  • Page 23 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings 4. Select "Input Signal > IP Channel x" The tab provides settings necessary to configure IP channel x. You can configure settings for 2 IP channels x = 1 to 2 individually, see also "Input Signal >...
  • Page 24 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings Requirements At your IP source, set the "transport stream packets per internet protocol packet" (TP per IP) parameter as follows: ● If TP packet length = 188 bytes: Set TP per IP to 7 or 6.
  • Page 25 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Input Signal Settings Remote command: on page 56 [:SOURce<hw>]:BB:INPut:IP<ch>:MULticast:ADDRess Port Sets the destination UDP port. Due to UDP/RTP autosensing, we recommend that you set a port offset of at least 6 between neighboring IP TS channels.

  • Page 26: Network Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Network Settings 4.3 Network Settings Access: ► Select "Baseband > T-DMB/DAB > Network". The tab provides network mode and settings. Settings: Network Mode ......................26 ..........................27 TII Main ID ........................27 TII Sub ID ........................
  • Page 27 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Network Settings "SFN" In an SFN, all transmitters in a network are tuned to the same fre- quency and have frequency coupling (based on the 10 MHz refer- ence output of a GPS receiver). In addition, it is necessary in an SFN network to compensate any signal delays that occur in the program data supply.

  • Page 28: Sfn Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 SFN Settings 4.4 SFN Settings Access: 1. Select "Baseband > T-DMB/DAB > Network > Network Mode > SFN". 2. Select "T-DMB/DAB > SFN". The tab provides settings necessary to configure operation. Settings Network Compensation....................28...
  • Page 29 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 SFN Settings Remote command: on page 60 [:SOURce<hw>]:BB:TDMB:DELay:PROCess? Tx Compensation Delay Displays the time span by which signal processing is artificially delayed to achieve a constant "Tx Delay". "Tx Compensation Delay" = "Tx Delay" - "Tx Processing Delay"...

  • Page 30: Special Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Special Settings 4.5 Special Settings Access: ► Select "Baseband > T-DMB/DAB > Special". The tab provides settings, that differ from the specification of the broadcast stan- dard. Settings different from the broadcast standard can be useful for research and develop- ment.

  • Page 31: Global Connector Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player Select Transmission Mode Requires "Transmission Mode > Manual". Selects the transmission mode. Table 4-2 illustrates, how the selected transmission mode affects OFDM and framing parameters. Table 4-2: Transmission mode settings Transmission mode...

  • Page 32: Ts Player Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player Required options ● Enable Broadcast Standards option (R&S SMCVB-K519) ● Optional Stream library option (R&S SMCVB-KS10 to R&S SMCVB-KS20) Support in broadcast standard configuration Baseband standard "Source > TS Player" Baseband standard "Source >...
  • Page 33 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player The tab provides settings necessary to configure the general settings of the TS player application. Settings: Running/Position Player [hh:mm:ss:fff]................. 33 Select File........................33 Start [hh:mm:ss.fff]......................34 Position Player [hh:mm:ss.fff]..................34 Stop [hh:mm:ss.fff]......................34 Reset Window.......................
  • Page 34 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player File extension Stream libraries Remark Option *.trp Unencrypted *.trp_c Encrypted R&S SMCVB-KS12 Included in various stream R&S SMCVB-KS17 libraries R&S SMCVB-KS18 R&S SMCVB-KS19 R&S SMCVB-KS20 *.bin Unencrypted *.ts Unencrypted *.mpg Unencrypted *.t10...

  • Page 35: Player Output

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player Reset Window Resets "Start/Stop/Position Player" parameters. Remote command: on page 67 :TSGen:CONFigure:SEEK:RESet Play Plays the selected file. For supported file types, see Table 4-3. Remote command: on page 64 :TSGen:CONFigure:COMMand<ch> Pause Pauses the player.

  • Page 36: General

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player Settings: 4.7.2.1 General The tab provides settings necessary to configure general player output properties. Data Rate........................36 Orig. Data Rate......................36 Packet Length....................... 36 Nullpacket Stuffing......................37 Stop Data........................37 Data Rate Sets the output data rate of the player.

  • Page 37: Stuffing

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player Nullpacket Stuffing Requires a *.trp, *.trp_c, *.emc or *.emc_c file loaded into the "TS Player" dia- log. *.trp files are previously recorded files. Enables or disables nullpacket stuffing. The output data rate of the TS player equals the original data rate. The equality ensures that the time references in the tables of the played TS stream are correct dur- ing replay.
  • Page 38 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player Settings Test TS Packet......................38 PID Test Packet......................38 (Hex)........................38 Payload Test/Stuff......................38 PRBS..........................39 Test TS Packet Specifies the structure of the test transport stream packet that is fed to the modulator.

  • Page 39: Seamless Loop Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 TS Player "PRBS" PRBS data in accordance with ITU-T O.151 See also chapter "Internal Modulation Data" in the R&S SMCV100B User Manual. "0x00" Exclusively 00 (hex) data "0xFF" Exclusively FF (hex) data Remote command:...

  • Page 40: Local Ip Data Network Settings

    ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Local IP Data Network Settings PCR, DTS/PTS Activates the correction of time stamps in the replayed TS data stream. The correction allows you to decode the stream without interruption when the play file is looping.
  • Page 41 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Local IP Data Network Settings Settings: Network Status......................41 Restart Network......................41 Hostname........................41 Address Mode....................... 41 Address........................42 Protocol......................... 42 Subnet Mask......................... 42 Show Connector......................42 Address........................ 42 Network Status Indicates that the instrument is connected to the network.
  • Page 42 ® T-DMB/DAB Configuration and Settings R&S SMCVB-K156 Local IP Data Network Settings Remote command: on page 71 :SYSTem:COMMunicate:BCIP<hw>:NETWork:IPADdress:MODE IP Address Displays the IP address of the instrument in the local IP data network. By default, the R&S SMCV100B is configured to use dynamic TCP/IP configuration and to obtain the whole address information automatically.

  • Page 43: Performing T-Dmb/Dab Signal Generation Tasks

    ® Performing T-DMB/DAB Signal Generation Tasks R&S SMCVB-K156 Configuring the Input Signal 5 Performing T-DMB/DAB Signal Generation Tasks This chapter tells you how to configure the R&S SMCV100B to generate signals for simple receiver tests. ● Configuring the Input Signal..................43 5.1 Configuring the Input Signal...
  • Page 44 ® Performing T-DMB/DAB Signal Generation Tasks R&S SMCVB-K156 Configuring the Input Signal The R&S SMCV100B is connected to the local IP data network. 6. If DHCP does not assign an IP address, assign the IP address manually. See chapter "How to Assign the IP Address" in the R&S SMCV100B user manual.

  • Page 45: How To Apply An External Ts Input Signal

    ® Performing T-DMB/DAB Signal Generation Tasks R&S SMCVB-K156 Configuring the Input Signal 2. Optionally, activate "Stuffing" to adjust the TS data rate. 3. Specify IP TS channel properties, e.g. for "IP TS Channel > 1": a) Define the input type, e.g. "Type > Multicast".
  • Page 46 ® Performing T-DMB/DAB Signal Generation Tasks R&S SMCVB-K156 Configuring the Input Signal 2. At the R&S SMCV100B, connect the cable to the "User 1" connector. The connector is on the rear panel of the R&S SMCV100B. How to: Section "To connect to non-screwable connectors (BNC)" in the R&S SMCV100B Getting Started user manual.

  • Page 47: How To Generate An Internal Ts Signal

    ® Performing T-DMB/DAB Signal Generation Tasks R&S SMCVB-K156 Configuring the Input Signal You can further specify the payload of the stuffing data, see "Test Signal > Payload Test/Stuff." The R&S SMCV100B is prepared for receiving TS data, that is input at the "User 1"...

  • Page 48: Remote-Control Commands

    ® Remote-Control Commands R&S SMCVB-K156 6 Remote-Control Commands The following commands are required to generate signals with the T-DMB/DAB option in a remote environment. We assume that the R&S SMCV100B has already been set up for remote operation in a network as described in the R&S SMCV100B documenta- tion.

  • Page 49: General Commands

    ® Remote-Control Commands R&S SMCVB-K156 General Commands 6.1 General Commands Example: Storing current configuration :SOURce1:BB:TDMB:SETTing:STORe "/var/user/my_TDMB" // Stores the file "my_TDMB.tdmb" in the directory as above. *RST :SOURce1:BB:TDMB:SETTing:CATalog? // Response: "my_TDMB" :SOURce1:BB:TDMB:SETTing:LOAD "/var/user/my_TDMB" :SOURce1:BB:TDMB:STATe 1 :SOURce1:BB:TDMB:SETTing:DELete "/var/user/my_TDMB" Commands ................... 49 [:SOURce<hw>]:BB:TDMB:PRESet...
  • Page 50 ® Remote-Control Commands R&S SMCVB-K156 General Commands Return values: <FileNames> <filename1>,<filename2>,... Returns a string of filenames separated by commas. Example: Example "Storing current configuration" on page 49. Usage: Query only Manual operation: "Save/Recall" on page 18 [:SOURce<hw>]:BB:TDMB:SETTing:DELete <Delete> Deletes the selected file from the default or the specified directory. Deleated are files with extension *.tdmb.

  • Page 51: Input Commands

    ® Remote-Control Commands R&S SMCVB-K156 Input Commands 6.2 Input Commands ● General Commands....................51 ● Info Commands.......................52 ● Subsystem......................54 6.2.1 General Commands .................51 [:SOURce<hw>]:BB:TDMB:ETIinput? ..................51 [:SOURce<hw>]:BB:TDMB:INPut ................. 51 [:SOURce<hw>]:BB:TDMB:INPut:FORMat ..............51 [:SOURce<hw>]:BB:TDMB:INPut:ETIChannel ..................52 [:SOURce<hw>]:BB:TDMB:MID? ..................52 [:SOURce<hw>]:BB:TDMB:NST? ..................52 [:SOURce<hw>]:BB:TDMB:SOURce [:SOURce<hw>]:BB:TDMB:ETIinput?

  • Page 52: Info Commands

    ® Remote-Control Commands R&S SMCVB-K156 Input Commands Parameters: <ETIChannel> 1 | 2 *RST: Manual operation: "IP ETI Channel" on page 20 [:SOURce<hw>]:BB:TDMB:MID? Displays the DAB mode identity. A mode identity of 0 corresponds to an invalid ETI signal. Return values: <ModeIdentity>...
  • Page 53 ® Remote-Control Commands R&S SMCVB-K156 Input Commands [:SOURce<hw>]:BB:TDMB:DATarate<ch>? Return values: <DataRAte> integer Range: 0 to 1824 *RST: Usage: Query only Manual operation: "Data Rate / kbit/s" on page 22 [:SOURce<hw>]:BB:TDMB:PROTection:LEVel<ch>? Queries the protection level. The level depends on the protection profile.

  • Page 54: Ip Subsystem

    ® Remote-Control Commands R&S SMCVB-K156 Input Commands Parameters: <SubChannelId> integer Range: 0 to 63 *RST: Example: Manual operation: "Subchannel Id (Hex)" on page 22 6.2.3 IP Subsystem The SOURce:BB:INPut:IP subsystem contains the commands for configuring input IP data from a local IP data network.
  • Page 55 ® Remote-Control Commands R&S SMCVB-K156 Input Commands Example: Configure IP channel 2 properties // Use the data from IP channel 2 as input for modulation data. SOURce1:BB:INPut:IP2:STATe ON // Specify alias as "Alias 2". SOURce1:BB:INPut:IP2:ALIas "Alias 2" //****************************************************************************** // Define Unicast properties.
  • Page 56 ® Remote-Control Commands R&S SMCVB-K156 Input Commands [:SOURce<hw>]:BB:INPut:IP<ch>:ALIas <Alias> Specifies an alias, i.e. name for the IP connection. Parameters: <Alias> string Example: Example "Configure IP channel 2 properties" on page 55. Manual operation: "Alias" on page 24 [:SOURce<hw>]:BB:INPut:IP<ch>:PORT <Port> Sets the port of the input IP data at the "IP Data" connector.
  • Page 57 ® Remote-Control Commands R&S SMCVB-K156 Input Commands Parameters: <Address> string Range: 224.0.0.0 to 239.255.255.255 Example: Example "Configure IP channel 2 properties" on page 55. Manual operation: "Multicast Address" on page 24 [:SOURce<hw>]:BB:INPut:IP<ch>:IGMP[:SOURce]:ADDRess Specifies the IGMP source address of the network.

  • Page 58: Network Commands

    ® Remote-Control Commands R&S SMCVB-K156 Network Commands 6.3 Network Commands ..................58 [:SOURce<hw>]:BB:TDMB:NET ..................58 [:SOURce<hw>]:BB:TDMB:TII:MAIN .................58 [:SOURce<hw>]:BB:TDMB:TII:STATe ................... 58 [:SOURce<hw>]:BB:TDMB:TII:SUB [:SOURce<hw>]:BB:TDMB:NET <NetwMode> Sets the network mode. Parameters: <NetwMode> MFN | SFN Manual operation: " Network Mode " on page 26 [:SOURce<hw>]:BB:TDMB:TII:MAIN <TiiMain>...

  • Page 59: Sfn Delay Commands

    ® Remote-Control Commands R&S SMCVB-K156 SFN Delay Commands 6.4 SFN Delay Commands ............59 [:SOURce<hw>]:BB:TDMB:DELay:COMPensation? ................59 [:SOURce<hw>]:BB:TDMB:DELay:DELay ..............59 [:SOURce<hw>]:BB:TDMB:DELay:DEViation ..............60 [:SOURce<hw>]:BB:TDMB:DELay:NETWork? ..............60 [:SOURce<hw>]:BB:TDMB:DELay:PROCess? ................60 [:SOURce<hw>]:BB:TDMB:DELay:STATic ................60 [:SOURce<hw>]:BB:TDMB:DELay:TOTal? [:SOURce<hw>]:BB:TDMB:DELay:COMPensation? Displays the time span by which signal processing is artificially delayed in order to ach- ieve a constant "TX Delay".
  • Page 60 ® Remote-Control Commands R&S SMCVB-K156 SFN Delay Commands Manual operation: "Max. Deviation Time" on page 29 [:SOURce<hw>]:BB:TDMB:DELay:NETWork? Queries the compensating delay. If the delay is added to the network path delay, the overall delay is constant and of known value.

  • Page 61: Special Commands

    ® Remote-Control Commands R&S SMCVB-K156 Special Commands Return values: <DelayTotal> float Range: -1.0000000 to 3.0000000 Increment: 0.0000001 *RST: Default unit: s Usage: Query only Manual operation: "Total Delay" on page 29 6.5 Special Commands ............61 [:SOURce<hw>]:BB:TDMB[:SPECial]:SETTings[:STATe] ..........61 [:SOURce<hw>]:BB:TDMB[:SPECial]:TRANsmission:MODE ........61 [:SOURce<hw>]:BB:TDMB[:SPECial]:TRANsmission:MODE:SELECT...

  • Page 62: Tsgen Subsystem

    ® Remote-Control Commands R&S SMCVB-K156 TSGen Subsystem 6.6 TSGen Subsystem The TSGen subsystem contains the commands for configuring the TS player. Example: Play a TS player file //****************************************************************************** // Select a file, e.g. a user-defined setting. //****************************************************************************** :TSGen:CONFigure:PLAYfile "/var/user/my_test_player_test.trp" // Selects the file "my_test_player_test" with extension *.trp.
  • Page 63 ® Remote-Control Commands R&S SMCVB-K156 TSGen Subsystem Example: Configure and monitor TS player output //****************************************************************************** // Configure general and stuffing parameters of the TS player output. //****************************************************************************** :TSGen:CONFigure:STUFfing ON :TSGen:CONFigure:STOPdata TTSP :TSGen:CONFigure:TSPacket H184 //:TSGen:CONFigure:PIDTestpacket VAR :TSGen:CONFigure:PIDTestpack VAR :TSGen:CONFigure:PID 8100 // Corresponds to a PID = 1FA4 in hexadecimal format.

  • Page 64: Tsgen:configure:command

    ® Remote-Control Commands R&S SMCVB-K156 TSGen Subsystem ...................68 :TSGen:CONFigure:TSPacket ....................68 :TSGen:CONFigure:TSRate ....................68 :TSGen:READ:FMEMory ....................69 :TSGen:READ:ORIGtsrate ..................69 :TSGen:READ:PLAYfile:LENGth? :TSGen:CONFigure:COMMand<ch> Triggers playing, pausing and stopping of the TS player file selected with :TSGen: CONFigure:PLAYfile. Setting parameters: <PlayerStatus> STOP | PLAY | PAUSe...

  • Page 65: Tsgen:configure:pidtestpack

    ® Remote-Control Commands R&S SMCVB-K156 TSGen Subsystem :TSGen:CONFigure:PIDTestpack <PIDTestpack> Sets the PID, if is H184|H200|H204. :TSGen:CONFigure:TSPacket Parameters: <PIDTestpack> VARiable | NULL *RST: NULL Example: Example "Configure and monitor TS player output" on page 63. Manual operation: "PID Test Packet" on page 38 :TSGen:CONFigure:PLAYfile <PlayFile>...

  • Page 66: Tsgen:configure:seamless:pcr

    ® Remote-Control Commands R&S SMCVB-K156 TSGen Subsystem Parameters: <CC> 0 | 1 | OFF | ON *RST: Example: Example "Configure seamless loop parameters" on page 63. Manual operation: "Continuity Counter" on page 39 :TSGen:CONFigure:SEAMless:PCR <PCR> Activates the correction of time stamps in the replayed TS data stream. The correction allows you to decode the stream without interruption when the play file is looping.

  • Page 67: Tsgen:configure:seek:reset

    ® Remote-Control Commands R&S SMCVB-K156 TSGen Subsystem :TSGen:CONFigure:SEEK:RESet Resets the following parametets to their default state: ● on page 67 :TSGen:CONFigure:SEEK:STARt ● on page 67 :TSGen:CONFigure:SEEK:STOP Example: Example "Play a TS player file" on page 62. Manual operation: "Reset Window"...

  • Page 68: Tsgen:configure:stuffing

    ® Remote-Control Commands R&S SMCVB-K156 TSGen Subsystem Manual operation: "Stop Data" on page 37 :TSGen:CONFigure:STUFfing <Stuffing> Enables or disables nullpacket stuffing. Parameters: <Stuffing> 0 | 1 | OFF | ON *RST: Example: Example "Configure and monitor TS player output" on page 63.

  • Page 69: Bcip Subsystem

    ® Remote-Control Commands R&S SMCVB-K156 BCIP Subsystem Parameters: <FMemory> integer Range: 0 to 10 *RST: Example: Example "Configure and monitor TS player output" on page 63. Manual operation: "Select File" on page 33 :TSGen:READ:ORIGtsrate <ORIGtsrate> Displays the calculated original TS data rate.
  • Page 70 ® Remote-Control Commands R&S SMCVB-K156 BCIP Subsystem Suffix Value range Description BCIP<hw> Available local IP LAN interfaces Example: Retrieving information on local network-related settings //****************************************************************************** // Monitor IP interface 1 local network status. //****************************************************************************** SYSTem:COMMunicate:BCIP1:NETWork:STATus? // Response: "0" // The instrument is diconnected from the local IP network.
  • Page 71 ® Remote-Control Commands R&S SMCVB-K156 BCIP Subsystem :SYSTem:COMMunicate:BCIP<hw>:NETWork:IPADdress Sets the IP address. Parameters: <IpAddress> string Range: 0.0.0.0 to 255.255.255.255 *RST: 0.0.0.0 Example: Example "Retrieving information on local network-related settings" on page 70. Manual operation: "IP Address" on page 42 :SYSTem:COMMunicate:BCIP<hw>:NETWork:IPADdress:MODE <IPMode>...
  • Page 72 ® Remote-Control Commands R&S SMCVB-K156 BCIP Subsystem :SYSTem:COMMunicate:BCIP<hw>:NETWork:PROTocol <Protocol> Specifies the network protocol. Parameters: <Protocol> *RST: Example: Example "Retrieving information on local network-related settings" on page 70. Manual operation: "Protocol" on page 42 :SYSTem:COMMunicate:BCIP<hw>:NETWork:RESTart Triggers a restart of the network.

  • Page 73: Glossary: Abbreviations

    ® Glossary: Abbreviations R&S SMCVB-K156 Glossary: Abbreviations ASI: Asynchronous Serial Interface COFDM: Coded Orthogonal Frequency Division Multiplex DAB: DIgital Audio Broadcasting DHCP: Dynamic Host Configuration Protocol EEP: Equal Error Protection ETI: Ensemble Transport Interface HDB3: High Density Bipolar code of order 3...
  • Page 74 ® Glossary: Abbreviations R&S SMCVB-K156 OFDM: Orthogonal Frequency Division Multiplex PID: Packet Identifier PRBS: Pseudo-Random Bit Sequence RTP: Real-time Transport Protocol SFN: Single-frequency Network SMPTE: Society of Motion Picture and Television Engineers https://www.smpte.org/ SSTC: Sub-channel Stream Characteristics STC: Stream Characteristics...
  • Page 75 ® Glossary: Specifications R&S SMCVB-K156 Glossary: Specifications ETS 300 799: Digital Audio Broadcasting (DAB); Distribution interfaces; Ensemble Transport Interface (ETI) https://www.etsi.org/deliver/etsi_i_ets/300700_300799/300799/ ETSI EN 300 401: Radio Broadcasting Systems; Digital Audio Broadcasting (DAB) to mobile, portable and fixed receivers https://www.etsi.org/deliver/etsi_en/300400_300499/300401/ ITU-T G.703: ITU-T Recommendation G.703 Physical/electrical characteristics of hierarchical digital interfaces https://www.itu.int/rec/T-REC-G.703/en...
  • Page 76 ® List of Commands R&S SMCVB-K156 List of Commands :SYSTem:COMMunicate:BCIP<hw>:NETWork:COMMon:HOSTname............70 :SYSTem:COMMunicate:BCIP<hw>:NETWork:IPADdress................71 :SYSTem:COMMunicate:BCIP<hw>:NETWork:IPADdress:MODE..............71 :SYSTem:COMMunicate:BCIP<hw>:NETWork:IPADdress:SUBNet:MASK............ 71 :SYSTem:COMMunicate:BCIP<hw>:NETWork:MACaddress................. 71 :SYSTem:COMMunicate:BCIP<hw>:NETWork:PROTocol................72 :SYSTem:COMMunicate:BCIP<hw>:NETWork:RESTart.................72 :SYSTem:COMMunicate:BCIP<hw>:NETWork:STATus..................72 :TSGen:CONFigure:COMMand<ch>....................... 64 :TSGen:CONFigure:PAYLoad..........................64 :TSGen:CONFigure:PID..........................64 :TSGen:CONFigure:PIDTestpack........................65 :TSGen:CONFigure:PLAYfile...........................65 :TSGen:CONFigure:PLENgth.......................... 65 :TSGen:CONFigure:PRBS[:SEQuence]......................65 :TSGen:CONFigure:SEAMless:CC........................65 :TSGen:CONFigure:SEAMless:PCR....................... 66 :TSGen:CONFigure:SEAMless:TT........................66 :TSGen:CONFigure:SEEK:POSition........................66 :TSGen:CONFigure:SEEK:RESet........................
  • Page 77 ® List of Commands R&S SMCVB-K156 [:SOURce<hw>]:BB:TDMB:INPut:ETIChannel....................51 [:SOURce<hw>]:BB:TDMB:INPut:FORMat..................... 51 [:SOURce<hw>]:BB:TDMB:MID?........................52 [:SOURce<hw>]:BB:TDMB:NET........................58 [:SOURce<hw>]:BB:TDMB:NST?........................52 [:SOURce<hw>]:BB:TDMB:PRESet........................ 49 [:SOURce<hw>]:BB:TDMB:PROTection:LEVel<ch>?..................53 [:SOURce<hw>]:BB:TDMB:PROTection:PROFile<ch>?................. 53 [:SOURce<hw>]:BB:TDMB:SCID<ch>......................53 [:SOURce<hw>]:BB:TDMB:SETTing:CATalog?....................49 [:SOURce<hw>]:BB:TDMB:SETTing:DELete....................50 [:SOURce<hw>]:BB:TDMB:SETTing:LOAD....................50 [:SOURce<hw>]:BB:TDMB:SETTing:STORe....................50 [:SOURce<hw>]:BB:TDMB:SOURce.......................52 [:SOURce<hw>]:BB:TDMB:STATe........................49 [:SOURce<hw>]:BB:TDMB:TII:MAIN.......................58 [:SOURce<hw>]:BB:TDMB:TII:STATe......................58 [:SOURce<hw>]:BB:TDMB:TII:SUB........................ 58 [:SOURce<hw>]:BB:TDMB[:SPECial]:SETTings[:STATe]................61 [:SOURce<hw>]:BB:TDMB[:SPECial]:TRANsmission:MODE................. 61 [:SOURce<hw>]:BB:TDMB[:SPECial]:TRANsmission:MODE:SELECT............61...
  • Page 78 ® Index R&S SMCVB-K156 Index Application cards ..............9 Local IP data Application notes ..............9 Remote control commands ......... 69 Local IP data network Address mode ............. 41 Hostname ..............41 Brochures ................9 IP address ..............42 MAC address .............. 42 Network status ............
  • Page 79 ® Index R&S SMCVB-K156 Nullpacket stuffing ............37 Orig. data rate ............. 36 Packet length .............. 36 Pause ................35 Payload test/stuff ............38 PCR, DTS/PTS ............40 PID ................38 PID test packet ............38 Play ................35 Player output settings ..........35 Position player ............
