Keysight Y1217A Rack Mount Rail Kit
Installation Note
This installation note contains procedures for installing the Y1217A Rack Mount
Rail Kit for the Keysight M9018A 18-slot PXIe Chassis in a Keysight rack.

Parts List

The parts included with each rack mount adapter option and the support rail are
shown in the following table (note that not all parts listed are available as
field-replaceable parts):
Part Number
M9018-00110
0590-0804
2680-0278

General Rack Mounting Guidelines

In rack mounting the chassis, follow these guidelines:
1 Always begin installing the chassis and heavy instruments at the bottom of
the rack and work up. This maintains a lower center of gravity and reduces the
possibility of the rack tipping.
2 Anti-tipping feet, if available with the rack, should always be extended.
3 The heaviest instrument or chassis should always be mounted at the bottom
of the rack.
4 For maximum cooling and optimum rack thermal efficiency, place the
instrument or chassis with the greatest power consumption towards the top of
the rack. This promotes efficient cooling since heat rises when placed nearer
to the top of the rack, high power instruments will not unnecessarily heat
other instruments. However, in doing this, do not violate the guideline that
the heaviest instruments should be placed at the bottom of the rack.
5 If instruments or modules in the chassis are consuming maximum power, 1U
of rack space is required for ventilation below the M9018A chassis.
All manuals and user guides at all-guides.com
This kit is optional to the Y1215B and Y1216A Rack Mount Kits. This kit is
designed for Keysight racks and may not fit non-Keysight racks.
Description
Support Rails
Channel Nuts (4 for support rail-to-rack)
Support Rail-to-Rack Screws - 10-32 x 0.5 Pan Head Torx T25
Quantity
2
4
4
