EverFocus EDSR-400 Instruction Manual

EverFocus EDSR-400 Instruction Manual

4 channel duplex digital video recorder

Advertisement

Quick Links

INSTRUCTION MANUAL
EDSR-400
4 Channel Duplex Digital Video Recorder
EDSR-600
6 Channel Duplex Digital Video Recorder
V1.05 2004/3/25

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EDSR-400 and is the answer not in the manual?

Questions and answers

Summary of Contents for EverFocus EDSR-400

  • Page 1 INSTRUCTION MANUAL EDSR-400 4 Channel Duplex Digital Video Recorder EDSR-600 6 Channel Duplex Digital Video Recorder V1.05 2004/3/25...
  • Page 2: Safety Precautions

    CAUTION DO NOT REMOVE COVER. NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING TO REDUCE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE Safety Precautions ? Refer all work related to the installation of this product to qualified service personnel or system installers.
  • Page 3 Safety Precautions The lightning flash with an arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated ”dangerous voltage”within the product’ s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons The exclamation point within an equilateral triangle is intended to alert the user to presence of important operating and maintenance(servicing)instructions in the...
  • Page 4: Important Safeguards

    Important Safeguards Read Instruction---All the safety and operating instructions should be read before the init is operated Retain Instructions---The safety and operating instructions should be retained for future reference. Heed Warnings— All warnings on the unit and in the operating instructions should be adhered to. Follow Instructions—...
  • Page 5: Table Of Contents

    Product Overview … … … … … … … … … … … … … … .… … … … … … ..… ..… ..Page 1 1.1 Main features… … … … … … … … … … … … … … … … … … … … … … … … … ...… ..… .1 1.2 Specifications…...
  • Page 6: Product Overview

    The EDSR400/EDSR600 Duplex Digital Video Recorder (DVR) a full-featured DVR designed specifically for use in security industry. The DVR incorporates all the benefits of digital video recording, is simple to install, and operates just like a VCR. Highly efficient compression technology and superior resolution of recorded images make the DVR stand out from the competition as the best choice for security surveillance.
  • Page 7: Specifications

    1.2 Specifications Video Format NTSC/PAL Video Input 4 (EDSR400) / 6 (EDSR600) camera inputs (BNC),1Vp-p/75ohm Video Output 1 BNC video out (1Vp-p/75 ohm) for Main Monitor 1 S-Video out Mini DIN for Main Monitor 1 BNC video out (1Vp-p/75 ohm) for CALL Monitor output 4 (EDSR400)/6 (EDSR600) video out (1Vp-p/ 75 Ohm)for looping Video Compression M-JPEG...
  • Page 8: Back Panel Connections

    2. Back Panel Connections EDSR-600 EDSR-400 ON/OFF: Main on/off switch. AC100~240V power socket. VIDEO IN: BNC-sockets for composite signal video inputs, automatic 75 Ohm termination. (EDSR400:1~4, EDSR600: 1~6) VIDEO OUT: Loop through video outputs for each input channel. (EDSR400:1~4, EDSR600: 1~6) CALL MONITOR: BNC-socket Call (Spot) Monitor, composite signal.
  • Page 9: Back Panel Connections

    RS485 connector : 2 x RJ-45 connectors for RS-485 remote control, high impedance Supported are keyboards KS-KBK, KS-KBJ (Optional). Maximum units in RS-485 network are 32. Following EverFocus products are compatible in RS-485 network: - DVR’ s - Keyboards KS-KBJ (with 3 - axis Joystick, DVR and telemetry control) LAN Connector : RJ-45 LAN connector for internal 10MBit LAN interface.
  • Page 10: System Connection

    System Connection 3. System Connection The installations described below should be made by qualified service personnel or system installers. Before Installation Please refer to the following diagram for the system connections. EDSR 400: Camera 1~4 / EDSR-600: Camera 1 ~ 6 Alarm In/Out Audio Input RS232...
  • Page 11: Front Panel Keypads

    In Pause mode, turn the shuttle dial to slow forward/rewind the picture (1/32 maximum). In Pause mode, turn the jog dial to step forward/rewind the Picture. In Menu mode turn the jog dial to select options. DISPLAY SETTING MENU CHANNEL 01 Front Panel Keypads EDSR-400...
  • Page 12 In Full screen mode this menu allows color adjustment for each v ideo channel, all channels are separately adjustable. The selected item will show in red color bar. Use JOG to increase or decrease the value. Press ENTER to confirm and move to next item. After finished setting, press SELECT key to discard change or press MENU key to save and exit the dialog.
  • Page 13: Operation

    5. Operation (1) Insert a HDD (IDE) for Video Storage Insert one or two HDD (3.5” IDE) for Video Storage. The HDD should be set as Master. (Set Cable Select is also available) (Normally the default setting of HDD is Master) Note: After hard disk case is inserted into the hard disk tray, be sure to turn the tray key in lock position.Otherwise, HDD will not be detected.
  • Page 14: Menu Flow

    6. MENU FLOW CLOCK ( See page 11 ) CLOCK SETTING MENU : 2004/2/27 FRI DATE : 13:01:02 TIME MENU LANGUAGE: ENGLISH VIDEO SYSTEM: NTSC VERSION: 1.05 TIMER ( See page 12 ) TIMER SETTING MENU WEEK START STOP SPEED SET 00:00 23:59 60 IPS OFF...
  • Page 15 BUZZER ( See page 22 ) BUZZER SETTING MENU BUZZER ENABLE RECORD-IN : ON ALARM-IN : ON MOTION-IN : ON DISK FULL : ON VIDEO LOSS: ON TIMER : ON ARCHIVE ( See page 23 ) ARCHIVE SETTING MENU : 720 X 480 PICTURE SIZE TIME STAMP : ON...
  • Page 16: Clock Setting Menu

    6.1 CLOCK SETTING MENU CLOCK SETTING MENU : 2004/02/27 FRI DATE : 13:01:02 TIME MENU LANGUAGE VIDEO SYSTEM VERSION: 1.05 In CLOCK/LANGUAGE SETTING MENU , we define: (1) DATE : Current date, format: YYYY/MM/DD Year: 2000 ~ 2099, Month: 01~ 12, Date: 01~31, Week: Sunday~Saturday (2) TIME : Current time, format: HH:MM:SS Hour: 00 ~ 23, Minute : 00 ~ 59, Second: 00 ~ 59 (3) MENU LANGUAGE: ENGLISH or Others...
  • Page 17: Timer Setting Menu

    6.2 TIMER SETTING MENU TIMER SETTING MENU WEEK START In TIMER SETTING MENU we define automatic timer controlled records. Timer records can be defined for 12 individual start and end times. (1) WEEK: This select the week day for the timer to record on schedule. DLY means daily record.
  • Page 18: Sequence Setting Menu

    6.3 SEQUENCE SETTING MENU SEQUENCE SETTING MENU CH OP Columns in brackets () only valid for EDSR-600 In the SEQUENCE SETTING MENU, we define for MAIN Monitor (1) CH (Channel): Input channels 1~4 for EDSR400, 1~6 for EDSR600. (2) OP (Operation): ON includes the camera in the sequence, OFF skips the camera in the sequence.
  • Page 19: Title Setting Menu

    6.4 TITLE SETTING MENU TITLE SETTING MENU CH TITLE Columns in brackets () only valid for EDSR-600 In TITLE SETTING MENU , we define: The Title Setting Menu allows you to assign a title to each camera input. Title with up to 12 characters is supported in each channel. The available alphanumeric characters are: 0,1,2,3,4,5,6,7,8,9, A,B,C,D,…...
  • Page 20: Covert Setting Menu

    6.5 COVERT SETTING MENU COVERT SETTING MENU CH OP OFF) OFF) Columns in brackets () only valid for EDSR-600 In COVERT SETTING MENU , we define: The covert setting menu allows you hide the desired camera on the display in a blue background. Change setting to ON for covering camera. Camera is not visible in Live and Playback mode, unless this function is deactivated in COVERT menu.
  • Page 21: Alarm Record Setting Menu

    6.6 ALARM RECORD SETTING MENU ALARM SETTING MENU CH OP RST ON Columns in brackets () only valid for EDSR-600 In ALARM RECORDING MENU, we define (1) CH (Alarm input) : Select alarm input or RST for alarm reset input. (2) OP (OPERATION) : ON : Records when alarm occurs.
  • Page 22: Motion Setting Menu

    6.7 MOTION SETTING MENU MOTION SETTING MENU CH OP Press 1~6 TO MANUAL EDIT Columns in brackets () only valid for EDSR-600 In the MOTION RECORD SETTING MENU, we define (1) CH (Channel) : Video input channel (2) OP (Operation) : Default: OFF ON: The device will respond recording when motion occurs.
  • Page 23 (5) Press 1-4/6 TO MANUAL EDIT: Use the numeric keys (1~4 for EDSR-400 / 1~6 for EDSR-600) to select a camera for setting the detection areas. The selected camera appears with a 16 x 12 grid (detection zones): Follow the Dialog for further operation.
  • Page 24: Record Setting Menu

    6.8 RECORD SETTING MENU RECORD SETTING MENU NORMAL RECORD SPEED QUALITY DISK FULL ALARM RECORD OPERATION SPEED QUALITY PRE-ALARM RECORD OPERATION In NORMAL RECORDING MENU, we define NORMAL RECORD: SPEED : To set the normal recording speed. Maximum 60 (NTSC) / 50 (PAL). QUALITY: Video recording quality setup for setting the quality of the vi deo picture by selecting a compression rate.
  • Page 25: Network Setting Menu

    6.9 NETWORK SETTING MENU NETWORK SETTING MENU IP ADDRESS NET MASK ADDRESS GATEWAY ADDRESS MAC ADDRESS USER-NAME GUEST--- GENERAL- ADMIN--- In the NETWORK SETTING MENU, we define IP ADDRESS : Assign an fixed IP address for this unit, for example:192.168.010.005 NET MASK ADDRESS: Assign a subnet mask of the network for this unit, for example:255.255.255.000 GATEWAY ADDRESS: Assign a default gateway for this unit, for...
  • Page 26: Control Setting Menu

    (7) RS485 PARITY: Select parity lever: NONE/ODE/EVEN (8) RS485 DATA BIT: Select data bit : 8 or 7 (9) RS232/RS485 ID: RS232/RS485 address.The address range for the DVR: 001~200. NOTE: Settings for remote keyboards KS -KBK and KS-KBJ: RS-485 Baud rate: 9600, 1 Stop bit, Parity NONE, ID (device number) range: 1~32 Turn the JOG dial clockwise or counter-clockwise to select the options.
  • Page 27: Buzzer Setting Menu

    6.11 BUZZER SETTING MENU BUZZER SETTING MENU BUZZER RECORD-IN ALARM-IN MOTION-IN DISK FULL VIDEO LOSS TIMER In BUZZER SETTING MENU, we define the buzzer ON/OFF for following event: RECORD-IN, ALARM-IN, MOTION-IN, DISK FULL, VIDEO LOSS AND TIMER Turn the JOG dial clockwise or counter-clockwise to select the options. Press ENTER key to confirm the option and move to next column.
  • Page 28: Archive Setting Menu

    6.12 ARCHIVE SETTING MENU ARCHIVE SETTING MENU PICTURE SIZE TIME STAMP TIME STAMP POS WATER MARK WATER MARK POS In the ARCHIVE SETTING MENU, we define for picture and movie export to CF-card: (1) PICTURE SIZE : Selects picture size for copying image to CF card: Big size:720x480 / 720x576 for NTSC / PAL.
  • Page 29: Call Monitor Setting Menu

    6.13 CALL MONITOR SETTING MENU CALL MONITOR SETTING MENU Columns in brackets () only valid for EDSR-600 In the CALL MONITOR SETTING MENU, we define the sequences of each CH for call monitor . CH, DWELL, EVENT: (1) CH (Channel): Select the camera to be shown in the standard sequence of this call monitor.
  • Page 30: Disk Setting Menu

    6.14 DISK SETTING MENU DISK SETTING MENU DISK USAGE SIZE (GB) RECORD POS PLAY POS DISK RENEW: In the DISK SETTING MENU, we define DISK USAGE: HDD-1, HDD-2 SIZE: Applied HDD size. RECORD POS: HDD usage rate, record position, “*” shows the active HDD PLAY POS: current playback position, “*”...
  • Page 31: System Setting Menu

    YES: Download the update S/W into C.F card through your PC and insert the CF card into the slot on the front panel of DVR. Press ENTER key to start. Notice: After the system is successfully updated, please reboot the system.
  • Page 32: Recording

    DISPLAY key to show camera title and date/time. Press STOP key to stop recording. Since the DVR had Duplex feature, STOP key can be activated both in Playing back and STOP Recording. In Duplex mode first STOP will stop playback, second STOP will stop recording.
  • Page 33: Playing Back

    8.1 NORMAL PLAYBACK (1) Playback Press the PLAY key to start playing back the stored image/audio from the last SEGMENT. PLAY NOTE: In Duplex mode (simultaneous record and playback) the playback speed is limited to 25 IPS. For real time display of 50 IPS records stop recording before starting playback.
  • Page 34: Search Playback

    8.2 SEARCH PLAYBACK (1) Segment List search playback Press SEARCH key to enter the SEARCH MENU dialog. SEARCH SEARCH MENU BY SEGMENT LIST BY ALARM LIST BY DATA TIME Turn the JOG dial to select BY SEGMENT LIST and press ENTER key.
  • Page 35 (2) Alarm List search playback Press SEARCH key to enter the SEARCH MENU dialog. SEARCH SEARCH MENU BY SEGMENT LIST BY ALARM LIST BY DATA TIME Turn the JOG dial to select BY ALARM LIST and press ENTER key. The submenu will display as follows: ALARM SEARCH 00001 00002...
  • Page 36: Search Playback

    (3) Date/Time Search Playback Press SEARCH key to enter the SEARCH MENU dialog. SEARCH SEARCH MENU BY SEGMENT LIST BY ALARM LIST BY DATA TIME Turn the JOG dial to select BY DATA TIME and press ENTER key. The submenu and instruction will display as follows: DATE/TIME SEARCH YEAR/MM/DD HH:MM:SS HDD 2003 /01 /01...
  • Page 37: Copy

    The still image copy function is possible in all playback view modes. Press the PLAY key to start playing back. Press the PAUSE key to pause playback. The Monitor OSD shows “PAUSE ON” (1~4 for EDSR-400, 1~6 for PAUSE EDSR-600)” . The displayed number shows the active channel for the COPY function.
  • Page 38: Copy To Movie File

    9.2 COPY TO MOVIE FILE NOTE: COPY function is not possible during RECORD. Stop recording to enable COPY function! Press the PLAY key to start playing back. PLAY Press COPY key and then the copy menu and instruction appears. The main monitor switches to full screen display with following OSD: COPY COPY TO MOVIE FILE USE JOG TO SELECT PICTURE...
  • Page 39: Export Event Log List

    9.3 EXPORT EVENT LOG LIST This function allows to export the event log list to CompactFlash – Card. The generated text file is in *.txt format. Press „DISPLAY“ key and hold key for about 2 seconds. DISPLAY TYPE MOTION USE JOG TO SWITCH PAGE HIT CALL TO TURN OFF BUZZER HIT COPY TO SAVE EVENT TO CF CARD HIT MENU TO EXIT...
  • Page 40: Monitor Views / Operation

    10. MONITOR VIEWS / OPERATION The EDSR400/EDSR600 digital recorders provide 1 main monitor and 1call monitors. These monitors have different functionalities: Main monitor: CALL monitor: 10.1. MAIN MONITOR The MODE key switches the different multi-screen modes. MODE The numeric keys switch to full screen mode with the selected camera. DISPLAY switches the OSD for camera titles and status messages ON/OFF.
  • Page 41: Call Monitor

    10.2. CALL MONITORS Press CALL to change settings for CALL monitor. The Main monitor shows following dialogue: CALL SETTING CALL MONITOR... SPOT HIT 1~4 (1~6) TO SELECT SPOT CAMERA PRESS SEQ FOR SEQUENTIAL CAMERA PREE DISPLAY TO TURN OSD ON/OFF PRESS MENU TO EXIT Please follow the instruction on the display for further operation: SPOT: Hit numeric keys 1~4 for EDSR400, 1~6 for EDSR600 to select spot camera.
  • Page 42: Remote Control

    11. REMOTE CONTROL 11.1 RS-485 REMOTE CONTROL The new standard EverFocus EDSR remote protocol allows challenging installations with DVR remote control at different installation sites. EDSR remote control is supported by the optional keyboards KS-KBJ (with 3-axis joystick and 2 additional RS-485 –...
  • Page 43: Ir - Remote Control

    The remote controller (RC-200, Figure 1) is an accessory to enhance the handy operations of the DVR. You can perform all the settings and operations by the remote controller. The effective distance is up to 10 meters without any obstacle. The keypad functions are same as the front panel key button of the DVR.
  • Page 44: View From Internet/Intranet

    12. View From Internet/Intranet Basic Operations and Login Display: Go to the Internet Explorer, key in the network IP address, for example, http://192.168.10.5 (must be the same IP address as the one assigned to the unit from the Network Setting Menu. You need a FIXED IP Address, please contact your ISP for the IP) The LOGIN dialog will show on the screen.
  • Page 45: Main Screen

    Main Screen The picture is sampling from EDSR900 9 CH DVR 1 2 3 4 5 6 Above diagram is the main screen display. The icons on the lower corner of the screen are mainly for control and Configuration, those on the right corner are for status indication.
  • Page 46 10. The system allows up to 3 ways playback video, by SEGMENT, ALARM LIST and DATE TIME. (Playback by SEGMENT LIST, click Refresh to show list) (Playback by ALARM LIST, click Refresh to show list) (Playback by Date time) Above pictures are sampling from EDSR900 9 CH DVR for reference.
  • Page 47 15. Full screen view. 16. Quad screen view. 17. Nine split screen view. (only for 9 CH DVR). 18. Sixteen split screen view (only for 16 CH DVR). 19. A pop-up menu to select camera to view will be shown by pressing right mouse button.
  • Page 48: Appendix-A Lan Functional Specification

    LAN Functional Specification Specifications: Network Interface: 10Mbits/s Ethernet (10Base T) LAN controller Chip: RealTek 8019 LAN Connector: RJ-45 Protocol: HTTP,TCP/IP.ICMP,ARP Remote Access: Standard browser such as internet Explorer / Netscape with JAVA support Image Compression: JPEG Used Ports: 80, 1111, 2222, 3333, 4444, 6666 Max.
  • Page 49: Appendix-B Time Lapse Recording Time Table

    Time Lapse Mode Recording Time Table ? When Recording with 160GB HDD (Estimated with typical image-low noise level) NTSC Unit: Hour Recording Speed LOWER (fps) 49.4 98.8 148.1 197.5 155.9 296.3 233.9 592.6 467.8 2963 2339.2 5925.9 4678.4 9876.5 7797.3 14814.8 11695.9 Unit: Hour...
  • Page 50 ? When Recording with 320GB HDD (Estimated with typical image-low noise level) NTSC Unit: Hour Recording Speed LOWER (fps) 98.8 197.5 155.9 296.3 233.9 395.1 311.9 592.6 467.8 1185.2 935.7 5925.9 4678.4 11851.9 9356.7 19753.1 15594.5 29629.6 23391.8 Unit: Hour Recording Speed LOWER...
  • Page 51: Appendix-C Serial Interface Specifications

    Serial Interface Specifications 1. RS-232 pin assignment The DVR may be controlled by a computer or a terminal via the standard D-SUB 9-pin RS-232 connector. The pin assignment of the D-SUB 9-pin connector PIN # NAME NOT CONNECTED NOT CONNECTED...
  • Page 52: Remote Control Protocol

    0x5D Example2 : A packet that send "PAUSE" key to DVR (ID=4999) 0x85 0x27 0x07 0x4B 0x0C 0x0A Example3 : A packet that send "PLAY" key to all DVR (broadcast) 0x85 0x7f 0x7f 0x4B 0x0B 0x59 (length) (Receiver ID high byte)
  • Page 53 2-1. The format of message packet is as follows: Length Byte (Prefix: 0x86, 0x87, or 0x88 ... ) Receiver ID high byte Receiver ID low byte Opcode Byte Data Byte1 Data Byte2 Data Byte3 Checksum Byte 2-2. Length Byte This Length Byte is also a prefix. Bit7 must be 1. 0x87 ==>...
  • Page 54 2-3. Receiver ID 2-3. Receiver ID 1). Individual receiver ID Decimal 14bit binary value 0000000 0000000 0000000 0000001 0000000 0000010 0000000 1111110 0000000 1111111 0000001 0000000 0000001 0000001 0000001 1111111 0000010 0000000 0000011 1111111 16382 1111111 1111110 2). Broadcast ID Decimal 14bit binary value 16383...
  • Page 55 2-4. Opcode Byte & Data bytes 2-4-1. OPcode OPcode 0x4B 0x4D 2-4-2. Remote keys (OPcode=0x4B) ---------------------------------------------------------------------------------------------------- Data1 0x00 0x01 0x02 0x03 0x04 MODE 0x05 ZOOM 0x06 0x07 MENU 0x08 0x09 REV.PLAY 0x0A STOP 0x0B PLAY 0x0C PAUSE 0x0D SEARCH 0x0E COPY 0x0F DISPALY...
  • Page 56: Appendix-D Alarm I/O Pin Assignment

    Each alarm input requires two wires, one wire connects to the desired alarm input pin, the second wire connects to the ground.The alarm signal assignment is shown at the following. <Figure 1> D-SUB 25 pin female connector (DVR) PIN # NAME / Function...
  • Page 57 EverFocus Electronics Corp. Head Office: 12F, No.79 Sec. 1 Shin-Tai Wu Road, Hsi-Chi, Taipei, Taiwan TEL: +886-2-26982334 FAX: +886-2-26982380 www.everfocus.com.tw USA Office: 2445 Huntington Drive, San Marino, CA 91108, U.S.A. TEL: +1-626-844-8888 FAX: +1-626-844-8838 www.everfocus.com Japan Office: 1809 WBG Maribu East 18F, 2-6 Nakase.Mihama-ku.

This manual is also suitable for:

Edsr-600
