Contents:

A - Latch
B - Latch Joint
C - Pivot Base Joint
D - Pivot Base
E - Catch
F - Pivot Base Gasket
G - Catch Gasket
H - Flat Head Bolts
I - Lock Nuts
J - Binding Posts
K - Jam Nuts
L - Adjustment Rod
M - Safety Snap
CAUTION
!
Hood catch is intended only as supplemental to Jeep® supplied latch at front of hood.
To avoid risk of property damage or injury: Always;
Assure hood is fully secure by undamaged Jeep® front latch & supplemental side
catches.
Do not modify hood or catches to defeat intended safety of Jeep® primary latch &
supplemental catch system.
PHONE: M-F 8am - 5pm EST 1-800-449-6649 | EMAIL: techsupport@omix-ada.com
FOR WARRANTY INFORMATION VISIT: www.Omix-Ada.com
460 Horizon Drive #400 | Suwanee, GA 30024 USA | www.omix-ada.com | Copyright © 2013 Omix-Ada
