NOTICE
Components
1. Crossbar
2. RH Bracket
3. LH Bracket
TJ Windshield LED Light Bar
5
6
LED lights not included.
This TJ lightbar is compatible with many 13.5 inch LED designs, however,
we recommend using Rugged Ridge® LED SKU: 15209.11 for best results
(1)
(1)
(1)
Copyright © 2013 Omix-Ada
1
7
9
8
Hardware
4. M10 Button Head Bolt
5. M10 Flat Washer
6. M10 Nylock Nut
7. M8 Hex Bolt
8. M8 Flat Washer
9. 5/16" Button Head Bolt
10. 5/16" Flat Washer
, Inc.
®
10
Page 1/3
11232.08
3
(2)
(4)
(2)
(6)
(6)
(8)
(8)
