PRx Performance Build Limitless Wall-Mount Rack Assembly Instructions Manual page 4

Wall-Mount Rack Assembly Instructions
1. Lay the uprights and crossmembers on the floor with the logo facing out and attach the
crossmembers (Figure 1).
1. Attach the crossmembers to the uprights as shown in Figure 1. It may be easiest to lay the uprights
and crossmembers on the floor with the logo side facing out. NOTE: Make sure the crossmembers
NOTE: Make sure the widest portion of the crossmember is at the top of the upright
are attached with the tubes closer to the bottom side of the end plates, as shown in Figure 3.
(Figure 2).
2. Make sure all hardware is snug.
2. Secure all hardware, but do not fully tighten.
Max.
Min.
Figure 2
Figure 2
4
Wall-Mount Rack Assembly Instructions
(701) 566-0452
5
Figure 1
Figure 1
3
6,7
