Summary of Contents for Acme Furniture 90314
- Page 1 ITEM NO.90314 ASSEMBLY INSTRUCTIONS BOLT 1/4” x 1-1/2” FOOT CAP BOLT CAP GLASS PAD 22PCS 8PCS 18PCS 12PCS BOLT 1/4” x 1-3/4” BOLT ALLEN WRENCH 2PCS 2PCS 4PCS...
- Page 2 ASSEMBLY INSTRUCTIONS ① ② ③ ④ STOOL BOTTOM STRETCHER STOOL SIDE PANEL CUSHION TABLE SIDE PANEL 2PCS 2PCS 2PCS ⑤ ⑥ ⑦ ⑧ TABLE FRONT FRAME TABLE BACK FRAME MIRROR STRETCHER MIRROR 2PCS ⑨ ⑩ ⑪ TABLE BOTTOM GLASS STRETCHER STOOL TOP STRETCHER 2PCS 2PCS...
- Page 3 STEP 1 Attach stool side panels (2) to stool top stretchers (11) and stool bottom stretchers (1) together using bolt (A) as shown. Attach cushion (3) to the assembled metal base using bolt (G) as shown. Then, cover the bolts (A) by bolt caps (C), and insert foot caps (B) into the bottom of stool...
- Page 4 STEP 3 Attach mirror stretchers (7) to the table frames using bolts (A) as shown. Align mirror stretchers (7) to the holes of the mirror (8). Make sure to place the nuts (F) in-between the holes of the mirror (8) and mirror stretchers (7), then screw the bolt (E) tightly.
