ASSEMBLY INSTRUCTION
Thank you forpurchasing this quality product. Be sure tocheck all packing material carefully for
small parts whichmay have come loose inside the carton during shipment. Separate,identify and
count all parts and hardware. Compare with the partslist tobesureall
"DO NOT TIGHTEN SCREWS UNTILCOMPLETELYASSEMBLED"
PLEASE READ INSTRUCTION BEFORESTARTINGTHEASSEMBLY
DESCRIPTION
1
2
3
4
5
6
7
ITEM NO.: 90805R
IMPORTANT:
PART NAME
BASE
BASE
TOP
MIRROR
BOLT 8X35MM
90806L
90807GL
DIMENSIONS
19.70"*15.75"*31.50"
19.70"*15.75"*31.50"
23.20*12.80"*0.50"
63.00"*46.50"*0.80"
0.30"*1.40"
1
parts arepresent.
Q'TY(PCS)
1PC
1PC
1PC
1PC
4PCS
1PC
1PC
