LSI Wireless
Gateway System
(Applies to: LSI Gateway series GS220 to GS224 and GS series sensors)
INSTALLER AND USER'S MANUAL
!
WARNING! The LSI Wireless Gateway system is designed to aid in the collection
of information and is in no way a substitute for safe operating practice.
WARNING! Carefully read and understand this manual before proceeding.
!
lifting.trimble.com
Advertisement
Table of Contents
Related Manuals for LSI GC Series
Summary of Contents for LSI GC Series
- Page 1 (Applies to: LSI Gateway series GS220 to GS224 and GS series sensors) INSTALLER AND USER’S MANUAL WARNING! The LSI Wireless Gateway system is designed to aid in the collection of information and is in no way a substitute for safe operating practice.
- Page 2 BEFORE PROCEEDING Read and understand the following: For your safety and that of the people that come into contact with products, understand the significance of the instructions included in this guide, respect all laws and regulations and comply with applicable standards. Pay particular attention to items bearing the alert symbol and the following words:...
-
Page 3: Table Of Contents
PROCEDURES ......12 2.2 ANTENNA POSITION ..... 5 5.3 EXCLUSION OF OTHER WARRANTIES ....... 12 2.3 LSI GATEWAY POWER SUPPLY ..5 5.4 EXCLUSION ........13 2.3a Wiring ..........5 2.4 LSI WM CONFIGURATOR ....6 5.5 LIMITATION OF LIABILITY ... 13 2.5 PC INSTALLATION ...... -
Page 4: Introduction
1. INTRODUCTION 1.1 Overview Network Controller Mode Gateway controls a wireless network Wireless Gateway system consists of up to 32 sensors. The Gateway wakes of one or more Wireless Gateway and and initiates communication with all sensors in one or more GS series sensors. -
Page 5: Installation
Gateway behind metal plates. A clear Blue or Brown ........ CAN-Ground Gateway signal between a sensor and the improves communication and increases sensor battery life. 5.85 5.44 4.72 2.33 5.57 4.73 Figure: GS22X-XX LSI Gateway dimensions. Not to scale. Dimensions are in inches. INSTALLATION... -
Page 6: Lsi Wm Configurator
2.5 PC Installation 2.5a System Requirements Windows 2000, XP, Vista (32/64bit) or Windows 7 (32/64bit). 2.5b LSI WM Configurator and USB Driver Installation Figure: Device Manager, Windows Vista / Windows 7 Before starting installation, make sure that no Gateway is connected to the computer. -
Page 7: Operation
3.1c Communication Port This section displays the communication port in use, the port type and status. The Open status indicates that the communication port is in use and that the Figure: LSI Gateway Internal Ports. Gateway is communicating information. OPERATION... -
Page 8: Firmware Update
Update Firmware Now. • Communication timeout before sleep mode: When the base station stops communicating IMPORTANT! A firmware update will reset the LSI information to the sensors, the sensors become Gateway to the factory default configuration. inactive (sleep mode). The value indicated is the time (in seconds) before the sensors switch to the sleep mode. -
Page 9: Certification Notes
If this equipment does Antenna List cause harmful interference to radio or television LSI P/N: TA011 reception, which can be determined by turning the Description: 1/4 wave monopole... -
Page 10: Declaration Of Conformity
4.2 CE 4.2a Declaration of conformity 4.2b CE Safety WARNING! When captors are used, the WARNING! The protection will be impaired ambient temperature should not be higher if the material and equipment are used in a than 84°C and the display should not be used manner not specified by the manufacturer. -
Page 11: Notes
NOTES NOTES... -
Page 12: Lsi Product Limited Warranty - April 1St, 2013
5.1 Limited Warranty repair or replace the defective Product or part. LOAD SYSTEMS INTERNATIONAL INC. (hereafter The Product or part shall be returned to LSI or its “LSI”) warrants its products (the “Products”) will be designated service representative, accompanied free from defects in materials and workmanship for... -
Page 13: Exclusion
To the maximum extent permitted by applicable law, The United Nations Convention on Contracts for the in no event will LSI be liable to the purchaser or any International Sale of Goods does not apply to this third party for any indirect, special, consequential, Limited Warranty. - Page 14 Technical support is available 24 hours a day, 7 days a week TLS_TechSupport@trimble.com © 2013, Load Systems International Inc. GM22X-XX_ENG_ 20130717 lifting.trimble.com...
