IF THERE IS ANY QUESTION ABOUT A CONDITION BEING SAFE OR UNSAFE,
DO NOT OPERATE THE TOOL!
Grounding Instructions
This machine has a three-prong plug, the third prong is the ground. Plug this cord
only into a three-prong receptacle. Do not attempt to defeat the protection the ground wire
provides by cutting off the round prong. Cutting off the ground will result in a safety hazard
and void the warranty.
DO NOT MODIFY THE PLUG IN ANY WAY. IF YOU HAVE ANY DOUBT, CALL A
QUALIFIED ELECTRICIAN.
Specification：
Max. drilling capacity:
End mill capacity
Face mill capacity
Distance between spindle center to column
Max. distance spindle to table
Spindle taper
Spindle speed
Table effective size
T-slot size
Longitudinal travel
Cross travel
Headstock travel
Mains
Motor power
Distance between spindle end and worktable surface
Overall dimension (L*W*H)
Packing size (L*W*H)
Weight
Unpacking & Preparing for Use
Before unpacking you must check the package carefully, to find whether it is damaged
and any may have effect on the machine, please connect with the distributor in advance.
Unpacking carefully, check the species of standard accessories and the quantity to find
whether it is as same as the packing list in the package.
2
20 mm
16 mm
50 mm
190 mm
340 mm
MT-3
100-2000 rpm ±10%
595x140 mm
12 mm x 3
394 mm
185 mm
260 mm
230V 1/N/PE 50Hz
750 W
75 – 340 mm
725x620x880 mm
820x720x890 mm
110kg (NW) / 125 kg (GW)
