Figure 4-2xxx
M5212 ACD Set bottom view
Connecting Cord Exit Port
to Add-on Unit, if equipped
Rubber Foot
Note: Case support screw positions:
M5212 ACD Set General Description, Installation, and Maintenance BCS33 and up
Linecord Exit Port for Linecord
when Telephone is used without
an Add-on Unit
(Label Area)
(Label Area)
Installation procedures 4-5
Handset Cord
Exit Channel
Teladapt
Connectors
Headset port
for electret (RJ)
type headset
Headset port for carbon or
equivalent (PJ) type headset
Alternate
headset
cord exit
channels
