1-2 Introduction

Dimensions

The exterior dimensions of the M5212 ACD set are:
Table 1-1xxx
Physical Dimensions
Dimension
length
width
height (front)
height (rear)

External Connectors

The modular jacks for the line cord, handset cord and headset cord are
located on the bottom of the set. Figure 4-2 on page 4-5 shows the
underside of the telephone base with handset and line cord channels, and a
connecting cord channel for installations where the telephone is equipped
with add-on modules. Figure 3-1 on page 3-2 shows and labels the user
accessible main components of the M5212 ACD set.
297-2041-900 Standard 02.01 October 1991
MM
226.5
208.0
27.5
73.5
Inches
8.8
8
1.1
2.88
