Figure 2-1xxx
Wiring scheme for alternate power supply arrangements
M5212
ACD
set
M5212 ACD Set General Description, Installation, and Maintenance BCS33 and up
**
AC
T
R
**
AC
T-adapter or I-adapter
NE267QA
Wall plug-in
Transformer
Wall-mounted
connecting
box equipped with
Teladapt connector
* Leads wired only if remote dc supply exists
** Leads used only if local plug-in ac power
supply present
Specifications 2-7
DC*
T
R
*
DC
