NOTICE TO INSTALLER: Instructions must remain with installation.
Product information presented
of publication. Consult factory
regarding discrepancies or
inconsistencies.
1. Inspect all materials. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before using. DO NOT remove the test/
2.
1. To help reduce the risk of electrical shock, a properly grounded receptacle
or control box of grounding type must be installed and protected by a ground
fault circuit interrupter (GFCI) in accordance with the National Electrical Code
and applicable local codes. Never remove ground pin from plug. If pump
is wired direct, a GFCI must be installed in the control box (SEE WARNING
BELOW).
2. Make certain that the receptacle is within the reach of the pump's power
supply cord. DO NOT USE AN EXTENSION CORD. Extension cords that
and they could present a safety hazard if the insulation were to become
damaged or the connection end were to fall into a wet or damp area.
3. Make sure the pump electrical supply circuit is equipped with fuses or circuit
breakers of proper capacity. A separate branch circuit, sized according to
the National Electrical Code for the current shown on the pump name plate
is recommended (see Note 3 on page 2).
4. Testing for ground. As a safety measure, each electrical outlet should be
checked for ground using a circuit analyzer which will indicate if the power,
neutral and ground wires are correctly connected to your outlet. If they are
5. For added safety. Use of a residual current device with an operating current
not higher than 30 mA is recommended.
6. FOR YOUR PROTECTION ALWAYS DISCONNECT PUMP FROM ITS
POWER SOURCE BEFORE HANDLING. If pump is wired direct, de-energize
the circuit at the control box. Grounded pumps are supplied with a 3-prong
grounded plug to help protect you against the possibility of electrical shock.
DO NOT, UNDER ANY CIRCUMSTANCES, REMOVE THE GROUND PIN.
To reduce the risk of electrical shock, a properly grounded receptacle or
control box of grounding type must be installed and protected by a ground
fault circuit interrupter (GFCI) in accordance with National Electrical Code
and applicable local codes.
7. Risk of electrical shock. Do not remove power supply cord and strain relief
or connect conduit directly to the pump.
8. Installation and servicing of electrical circuits and hardware should be
9.
10. Risk of electrical shock. These pumps have not been investigated for use
in swimming pools and marine areas.
11. If the supply cable is damaged, it must be replaced by the manufacturer or
QWIK JON
INSTALLATION INSTRUCTIONS
PREINSTALLATION CHECKLIST - ALL INSTALLATIONS
SEE BELOW FOR
LIST OF WARNINGS
© Copyright 2018 Zoeller
ULTIMA 204 SYSTEMS
®
TO AVOID SERIOUS OR FATAL PERSONAL INJURY OR MAJOR
PROPERTY DAMAGE, READ AND FOLLOW ALL SAFETY
INSTRUCTIONS IN THIS MANUAL AND ON THE PUMP.
THIS MANUAL IS INTENDED TO ASSIST IN THE INSTALLATION AND
OPERATION OF THIS UNIT AND MUST BE KEPT WITH THE PUMP.
CAUTION
THOROUGHLY REVIEW ALL INSTRUCTIONS AND WARNINGS PRIOR
TO PERFORMING ANY WORK ON THIS PUMP.
MAINTAIN ALL SAFETY DECALS.
REFER TO CAUTIONS AND WARRANTY ON PAGE 2.
Co. All rights reserved.
®
Visit our web site:
zoellerpumps.com
SAFETY INSTRUCTIONS
This is a SAFETY ALERT SYMBOL. When you see this
symbol on the pump or in the manual, look for one of the
following signal words and be alert to the potential for
personal injury or property damage.
Warns of hazards that CAN cause serious personal injury,
death or major property damage.
Warns of hazards that CAN cause personal injury or
property damage.
Warns of electrical shock hazards that can cause serious
personal injury, death or major property damage.
to and external conductor for protection against electrical
shock in case of a fault, or the terminal of a protective
earth (ground) electrode.
Read operator's manual.
ZT0299_ECb
0118
Supersedes
0513
P/N 083941
