Zoeller 1910-0009 Manual
  1. Manuals
  2. Brands
  3. Zoeller Manuals
  4. Plumbing Product
  5. 1910-0009
  6. Manual

Zoeller 1910-0009 Manual

Pre-plumbed sewage system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Zoeller
is a registered trademark
®
of Zoeller Co. All Rights Reserved.
ATTACH YOUR RECEIPT HERE
Serial Number
Questions, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-800-584-8089, 7:30 a.m. - 5:00 p.m., EST, Monday - Friday.
Purchase Date
PRE-PLUMBED
SEWAGE SYSTEM
1
MODEL #1910-0009
Español p. 13
025186 B

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1910-0009 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Zoeller 1910-0009

Summary of Contents for Zoeller 1910-0009

  • Page 1 PRE-PLUMBED SEWAGE SYSTEM MODEL #1910-0009 Zoeller is a registered trademark ® of Zoeller Co. All Rights Reserved. Español p. 13 ATTACH YOUR RECEIPT HERE Purchase Date Serial Number Questions, problems, missing parts? Before returning to your retailer, call our customer service department at 1-800-584-8089, 7:30 a.m.

  • Page 2: Safety Information

    SAFETY INFORMATION Please read and understand this entire manual before attempting to assemble, operate, or install the product. • NOTE: Pumps with the “UL” mark and pumps with the “US” mark are tested to UL Standard UL778. CSA certified pumps are certified to CSA Standard C22.2 No. 108. (CUS.) DANGER •...

  • Page 3: Package Contents

    CAUTION • PRODUCT DAMAGE MAY RESULT. Make certain that the power source conforms to the requirements of your equipment. • PRODUCT DAMAGE MAY RESULT. Maximum continuous operating water temperature for standard model pumps must not exceed 104°F (40°C). PACKAGE CONTENTS Description Quantity Pre-Plumbed Sewage System...
  • Page 4 “on” level. 3. The pump will turn off automatically when the water level in the basin reaches the “off” level. Item On Level Off Level 1910-0009 11-1/2 in. 5-1/4 in.

  • Page 5: Preparing For Installation

    PREPARING FOR INSTALLATION 1. Excavate a hole large enough to accommodate the basin, backfill material and inlet piping. 2. Add 4 to 6 inches of clean sub-base material or concrete to the bottom of the hole, and make sure it is compacted, level, and smooth.

  • Page 6: Installation Instructions

    INSTALLATION INSTRUCTIONS 1. Connect the inlet piping as required by code. All PVC Inlet and PVC fittings should be schedule 40 or schedule 80 rating. Do not use DWV PVC pipe or fittings as it is not pressure rated. Inlet piping 2.
  • Page 7 4. Set the lid on the basin. Position the lid so that the discharge slip fitting on the bottom of the lid slides onto the discharge pipe attached to the pump. NOTE: DO NOT GLUE THE DISCHARGE PIPE Basin lid Discharge TO THIS SLIP FITTING.
  • Page 8 7. Using a 2-step PVC glue system, connect a short piece of 2-in PVC to the male adapter on the discharge opening. Glue the other end of the pipe Check to the slip fitting on the sewage pump check valve Valve (included).
  • Page 9 10. Attach a 2-in male adapter to the vent opening on the top of the lid. Using 2-in. PVC and a 2-step PVC glue system, connect the vent opening to the sewer Vent pipe to sewer vent system. Use pipe tape to seal this connection. A vent system union is recommended for easy pump service.

  • Page 10: Care And Maintenance

    CARE AND MAINTENANCE WARNING: Always disconnect pump from power supply before handling. Inspect and test system for proper operation at least every three months. 1. Remove any build-up of debris from the switch or float, and check to be sure it moves freely. 2.

  • Page 11: Troubleshooting

    TROUBLESHOOTING Problem Possible Cause Corrective Action Pump will not 1. Water level too low. 1. Water must be at the appropriate level start or run. to activate switch. 2. Blown fuse or tripped circuit breaker. 2. If blown, determine cause and then either replace with properly sized fuse, or reset breaker.

  • Page 12: Replacement Parts List

    Problem Possible Cause Corrective Action Pump operates, 1. Low line voltage. 1. Contact an electrician. but delivers little 2. Inlet screen clogged. 2. Remove debris. or no water. 3. Broken impeller or debris in impeller 3. Remove screen and volute, clean cavity.
