NOTICE TO INSTALLER: Instructions must remain with installation.
Product information presented
here reflects conditions at time
of publication. Consult factory
regarding discrepancies or
inconsistencies.
Register your
Zoeller Pump Company Product
on our website:
http://reg.zoellerpumps.com/
1. Inspect your Zoeller Pump Company Tru-Flow
unit. Occasionally products are damaged during shipment. If unit is
damaged, contact your dealer before starting the installation.
2. Carefully read the literature and installation instructions to familiarize
Note: The TRU-FLOW
before backfilling.
1. Zoeller Pump Company Tru-Flow
has been purchased, all the components will be included except the trench pipes, fittings, and any necessary risers (See Figure Below).
2. If the Zoeller Pump Company Tru-Flow
clean out the septic tank before attempting to install the splitter system.
3. The septic tank outlet pipe and all trench pipes should be exposed or accessible for connections or insertion to the splitter system.
ZOELLER 24 OR 30 INCH ACCESS RISER & LID
SCUM LAYER
STANDARD 4" INLET
TEE OR BAFFLE
CLEAR EFFLUENT
SLUDGE LAYER
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
TEL: (502) 778-2731 • 1 (800) 928-PUMP • FAX: (502) 774-3624
OWNER'S MANUAL
Splitter System
®
HELPFUL INFORMATION FOR EASY INSTALLATION
Splitter System must sit level on undisturbed ground or on packed sand or gravel
®
Splitter Systems are designed for installation on the outlet pipe of the septic tank. If a complete system
®
Splitter System is being retrofitted into an existing septic system, it may be necessary to pump and
®
© Copyright 2021. All rights reserved.
Splitter System
®
yourself with specific details regarding installation. These materials
should be retained for future reference.
3. The use of an effluent filter is strongly recommended in order to
protect components downstream from the septic tank.
4" PIPE & CAP (SUPPLIED BY OTHERS)
OR OPTIONAL ZOELLER 6" RISER (SHOWN) P/N 173-0007
FILTERED
EFFLUENT
COUPLING, RUBBER
(SHOWN) OR PVC
(SUPPLIED BY OTHERS)
ZOELLER
FILTER
SECTION: C4.00.003
CL0075
Supersedes
Visit our website:
zoellerpumps.com
ZOELLER SPLITTER SYSTEM
OUTLETS TO
DRAIN FIELD
SK1975
0421
0321
