Advantech PCA-6742 Series Startup Manual
  1. Manuals
  2. Brands
  3. Advantech Manuals
  4. Computer Hardware
  5. PCA-6742 Series
  6. Startup manual
Advantech PCA-6742 Series Startup Manual

Advantech PCA-6742 Series Startup Manual

Eva-x4300 half-size cpu card
Hide thumbs Also See for PCA-6742 Series:
1
2
3
4
5
6

Advertisement

Table of Contents

• FAST SHIPPING AND
DELIVERY
• TENS OF THOUSANDS OF
IN-STOCK ITEMS
• EQUIPMENT DEMOS
• HUNDREDS OF
MANUFACTURERS
SUPPORTED
• LEASING/MONTHLY
RENTALS
• ITAR CERTIFIED
SECURE ASSET SOLUTIONS
All manuals and user guides at all-guides.com
Artisan Technology Group
new and certified-used/pre-owned equipment
SERVICE CENTER REPAIRS
Experienced engineers and technicians on staff
at our full-service, in-house repair center
View
REMOTE INSPECTION
Instra
SM
Remotely inspect equipment before purchasing with
our interactive website at
www.instraview.com
Contact us:
(888) 88-SOURCE | sales@artisantg.com | www.artisantg.com
is your source for quality
WE BUY USED EQUIPMENT
Sell your excess, underutilized, and idle used equipment
We also offer credit for buy-backs and trade-ins
www.artisantg.com/WeBuyEquipment
LOOKING FOR MORE INFORMATION?
Visit us on the web at
information on price quotations, drivers, technical
specifications, manuals, and documentation
www.artisantg.com
for more

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCA-6742 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Advantech PCA-6742 Series

Summary of Contents for Advantech PCA-6742 Series

  • Page 1 All manuals and user guides at all-guides.com Artisan Technology Group is your source for quality new and certified-used/pre-owned equipment • FAST SHIPPING AND SERVICE CENTER REPAIRS WE BUY USED EQUIPMENT DELIVERY Experienced engineers and technicians on staff Sell your excess, underutilized, and idle used equipment at our full-service, in-house repair center We also offer credit for buy-backs and trade-ins •...

  • Page 2: Packing List

    PCA-6742 EVA-X4300 Half-Size CPU Card Startup Manual Packing List Specifications • BIOS: Award integrated 256KB ROM in Advantech EVA- Before you begin installing your system, please make sure X4300 that the following materials have been shipped: • System memory: Onboard 64 MB DDR2 and optionally •...

  • Page 3: Jumpers And Connectors

    All manuals and user guides at all-guides.com Mechanical and Environmental Front Panel Connectors (JFP1) • Dimensions (L x W): 185 mm x 122 mm Signal • Power supply voltage: +5 V (4.75 V ~ 5.25 V) HDD LED+ • Power requirements: 1.6 A @ 5 V •...
  • Page 4 All manuals and user guides at all-guides.com VGASW1 Locating Connectors and Jumpers Setting Function (Switch) 9-bit TFT JFP1 12-bit TFT FDD1 IDE1 LPT1 JFP2 18-bit TFT GPIO1 COM34 USB34 USB12 24-bit TFT LVDS1 LCD1 JCASE1 16-bit DSTN JWDT1 INV1 VGA1 JIR1 JOBS1 24-bit DSTN...

  • Page 5: Mechanical Drawings

    All manuals and user guides at all-guides.com Mechanical Drawings Installation The CD disc contains a driver installer program that will lead you through the installation of various device drivers needed to take full advantage of your CPU card. Caution The computer is provided with a battery-powered real-time 122.00 JFP1 IDE1...
