Assembly - Procom PCTT360 Owner's Manual

Check for the following items:
Burner Head/Element
Check all heater parts for damage. If
any heater part is damaged, promptly
inform dealer where you bought
heater.
the propane tank
1. Align bolt holes in tank collar
bracket with bolt holes in mount-
ing plate on heater.
2. Drive-in two machine screws
(supplied) into the bolt holes
attaching tank collar bracket to
mounting plate
Machine Screw
Tank Collar Bracket
Mounting Bolt Knob
Figure 1 - Attaching Burner Assembly to
3. Read and follow all of the safety and
operating precautions.
4. Check the "O" ring on the POL before
each use. Replace "O" ring if there is any
sign of wear or damage.
5. Make sure heater regulator knob is in
the OFF position. If not, turn the heater
Control Knob counterclockwise to the OFF
position.
6. Attach the heater to the guard on the
propane cylinder as shown in Figure 1.
Tighten knob on tank bracket to secure
heater.
7. Insert regulator's connector into the
tank valve connection and turn counter-
clockwise until tight.
6
ASSEM BLY
Tank Bracket
8. Securely tighten all gas connections.
9. Open the cylinder's gas valve and
check all connections for leaks. Apply
gas joints. Bubbles forming show a leak
that must be corrected. DO NOT USE A
FLAME.
w w w.usa proc om .c om
Thermocouple
Tip Switch
Mounting Plate
Control Knob
Hand Nut
160220-03A
