Savant® 4K HDR HDBaseT Matrix Switcher [SLN-xxVLC4K]
Quick Reference Guide
Box Contents
(1)
4K HDBaseT Matrix Switcher (SLN-xxVLC4K)
(1)
AC Power Cord
(8) IR Connector Cables for the SLN-88VLC4K
(4) IR Connector Cables for the SLN-44VLC4K
(2) Mounting Brackets
(8) Mounting Bracket Screws
(1)
Product Regulatory Insert (009-1856-xx)
Accessories (sold separately)
HRX-4KVLC40-xx
HRX-4KVLC100-xx
Specifications
Environmental
Temperature
32° to 104° F (0° to 40°C)
Humidity
10% to 90% (non-condensing)
Dimensions and Weights
Height
1.71 in (4.35 cm)
Width
17.30 in (44.0 cm)
Depth
13.00 in (33.0 cm)
Net: 10.9 lbs (4.95 kg)
Weight
Shipping: 13.8 lbs (6.27 kg)
Rack Space
1U
Power
Input
100/240V AC (50/60 Hz)
Maximum
172.45W
18V 0.8A
Power over Cable
(PoC) Output
IMPORTANT! This cannot be disabled.
Video
HDR
Supported
720X576P
800x600
5
Supported
1024x768
Formats
1280x720P
1280x768
1280x800
1 = at 24 Hz | 2 = at 25 Hz | 3 = at 30 Hz | 4 = at 50 Hz | 5= at 60Hz
Audio
HDMI/HDBaseT: Pass-through of all HDMI audio
Supported
formats are supported.
Formats
Digital Audio Out: Up to Dolby 5.1, DTS 5.1
Regulatory
FCC Part 15
Safety and
Emissions
RoHS
Compliant
Minimum Supported Release
Savant OS
da Vinci 9.2
SLN-xxVLC4K | 009-1874-01 | 191220
Copyright © 2019 Savant Systems, LLC
1280x960
1600x1200
4
5
1280x1024
1680x1050
5
1360x768
1920x1080P
5
5
1366x768
1920x1200
5,6
5
1440x900
3840x2160
5
5
1600x900
4096x2160
5
5
CE
C-Tick
Front Panel
A
Reset
B
Power LED
C
Status LED
Power
D
Switch
Supported Receivers
HRX-4KVLC40
HRX-4KVLC100
HCX-4KHDR40
HCX-4KHDR100
HRX-SLN501 (does not support 4K)
HDBaseT Cable Information
Category 6 or greater twisted pair cable with RJ45 connectors
between the transmitter and the receiver is recommended.
TIA/EIA-568B straight-through wiring connections must be used.
HRX-4KVLC100
Transport Distance (4K)
Cat5e/6
Cat6a/7
Transport Distance (1080P)
Cat5e/6
Cat6a/7
HRX-4KVLC40
5
Transport Distance (4K)
5
Cat5e/6
1,3,4,5
Cat6a/7
5
Transport Distance (1080P)
1,2,3,4,5
Cat5e/6
1,2,3,4,5
Cat6a/7
Network Requirements
All Savant devices must be connected to the same local area network
(LAN) or subnet as the host. Savant recommends not implementing
any type of traffic or packet shaping in the network topology, as this
may interfere with performance.
ETL
Network Configuration
To ensure that the IP Address will not change due to a power outage,
a static IP Address or DHCP reservation should be configured. Savant
recommends using DHCP reservation within the router. By using this
method, static IP Addresses for all devices can be managed from a
single UI, avoiding the need to access devices individually.
Setting DHCP reservation varies from router to router. Refer to the
documentation for the router to configure DHCP reservation.
1
of
2
Press and Hold for 5s until the Status LED Blinks
Rapidly then release to reset the network settings.
Off: The matrix is powered off.
Green: The matrix is powered on.
Off: Does not have a valid IP address
Green: Network is connected.
Green Rapid Blinking: Reset network settings.
Green Slow Blinking: Firmware is being upgraded.
Press to power on/off the matrix.
230ft (70m)
328ft (100m)
328ft (100m)
328ft (100m)
(Gold pins facing up)
115ft (35m)
131ft (40m)
197ft (60m)
230ft (70m)
45 Perseverance Way, Hyannis, MA 02601
Savant.com | 508.683.2500
A
B
C
D
TIA/EIA-568B
RJ-45 Connector
