QUICK REFERENCE GUIDE
SKU
NANO-BP-P5
Box Contents
(1) Backpack P5 Source Control (Nano-BP-P5)
(1) AC Cord
(2) Mounting Brackets
(1) IR Sensor
(1) IR Remote
(1) 10 Position screw down connector
(1) Pair of White Gloves
(4) M4 x 10 mm screws with washers and star lock nuts
(1) Regulatory and Product Documentation Insert (009-1730-xx)
Optional Accessories
Universal Mounting Bracket for Flat Panel TV - (CMP-XL)
HDMI 2.0 cable (CBL-HDMI2xxx)
Specifications
Environmental
Temperature
32° to 104° F (0° to 40° C)
Humidity
10% to 80% Relative Humidity (non-condensing)
Dimensions and Weights
Height
Width
1.19 inch
11.75 inch
Backpack
(3.02 cm)
(29.84 cm)
5.25 inch
15 inch
Shipping
(13.34 cm)
(38.1 cm)
Power Requirements
Power - Input
120 - 240V AC, 50/60 Hz
Current (Max)
2A
Standards
Wireless
Wi-Fi (802.11 b/g/n) | (2.4 | 5.8 Ghz)
Security
WPA™, WPA2™, WPA/WPA2, WEP
Bluetooth
Bluetooth v4.0 (A2DP, AVRCP, SBC)
Regulatory
FCC Part 15
Safety and
Emissions
Contains FCC ID:
2ADBM-LS9AD-AC11DBT
Contains IC:
7756A-LS9ADBT
RoHS
Compliant
Audio
– Stereo and Multi Channel PCM
– Dolby Digital 2.0
– Dolby Digital 5.1
– DTS Digital Surround (5.1 ch)
Video (Supports pass-through of the following):
HDR (Dolby Vision)
640x480
720x480
720x576
Supported Formats
800x600
1024x768
1280x720
1 = at 24Hz
2= at 25 Hz
Minimum Supported Release
Savant OS
Copyright 2019 Savant Systems, LLC | 190212
NANO BACKPACK P5
PART #
009-1647-00
Depth
Weight
11.625 in
4.40 lbs
(29.53 cm)
(2.00 kg)
16.14 inch
7.10 lbs
(41.0 cm)
(3.22 kg)
CE Mark
C-Tick
Note: For Neo 6, Cinema and Mu-
sic will not support sample
rate at 88.2 kHz and 96 kHz
input, it can only support
44.1 kHz and 48 kHz input.
Supported
5
1280x720
5
1920x1200
5
1280x1024
5
3840x2160
4
1920x1080
1
3840x2160
1920x1080
3840x2160
5
3
5
1920x1080
4
3840x2160
1920x1080
3840x2160
4
5
3 = at 30 Hz
5 = at 60Hz
4 = at 50 Hz
da Vinci 8.7
Front and Rear Panel Descriptions
A
B
VOLUME
SOURCE
DLNA
C
Multi-function switch selector button. Pressing button will:
Press and release - Cycle between the volume and source.
A
Press and hold (10 secs) - Puts Backpack in to standby. Press
then release to take out of standby.
B
Twist button clockwise or counterclockwise to
Volume
increase or decrease volume.
Twist button clockwise or counterclockwise to scroll
C
Source
through each port. Fuscia indicates the port that is
selected.
A
B
AC 100-120V~60Hz.
POWER
220-240V~50Hz 200W
+
ON
I
0
OFF
AC power input. The AC power input accepts the following:
– 100 - 120V AC @ 60Hz
– 220 - 240V AC @ 50Hz
A
Use only the power cord included with the Nano Backpack.
Not using an Artison approved power cord can void the
warranty.
B
Power switch to toggle the Backpack On and Off.
Five separate speaker level outputs. Wires from speakers are
inserted into a screw-down plug in connector. Speaker out-
C
puts are as follows (4-8
– (3) 50W outputs @ .02% THD - 4Ω (Left, Right, Center)
– (2) 25W outputs @ .015% THD - 4Ω (Sur Left, Sur Right)
Single Low Frequency Effects (LFE) output. Connect a single
D
ETL
RCA-to-RCA cable from the LFE output port on the Backpack
to the LFE input port on a subwoofer.
10/100 Base-T auto negotiating LAN port with activity LEDs.
Link
E
Activity
F
USB Power - 5V DC , 1A
(3) HDMI 2.0b compliant
G
– HDCP 2.2
(1) HDMI 2.0b compliant
H
– HDCP 2.2
– CEC
5
1
IR Sensor - Connect the included IR Sensor for control when
2
Backpack is located in a remote location. See
I
3
AUX - 1 x 3.5mm mini-jack stereo input. Allows for the input of
4
an analog device using an analog patch cable (3.5mm stereo
mini-jack to RCA patch cable not included).
5
Optical (digital optical input) - Input for a digital source de-
J
vice. When multichannel audio is input (digital bit stream), the
Backpack decodes the audio to playback surround sound.
1
of
2
HDMI 1
HDMI 2
HDMI 3
TV(ARC)
OPTICAL
C
D
E
F
L
R
C
SL
SR
ETHERNET
USB POWER
HDMI IN
_
_
_
_
_
LFE
+
+
+
+
1
OUTPUT
5V
1A
):
Ω
Off - Link not established or in Blackout Mode
Green Solid - Ethernet link established
Green Blinking - Ethernet Activity occurring
Off - 10 Mbps data rate traffic or in Blackout Mode
Amber - 100 Mbps data rate
– Up to 4K@60Hz/4:4:4
– Up to 4K@60Hz/4:4:4
– ARC
45 Perseverance Way, Hyannis MA 02601
www.savant.com/artisonspeakers
AUX
BT
G
H
I
J
HDMI OUT IR SENSOR
(ARC)
2
3
OPTICAL
AUX IN
– 3D
– 3D
IR sensor
below.
