BEFORE ASSEMBLY, PLEASE MAKE SURE ALL COMPONENTS ARE INCLUDED
A
(2) LEGS
B
(2) SUPPORT POLES
C
(4) BULL NOSE SLATS
D
(5) SEAT SLATS
E
(2) CENTER SUPPORT
D
B
F
G
H
F
(22) M10X45 BOLTS
G
(22) M10 WASHERS
H
(4) SELF TAPPING SCREWS
J
(4) EXPAND ANCHOR BOLTS
www.belson.com
627 Amersale Drive
Naperville, IL 60563
Phone: (800) 323-5664
Fax: (630) 897-0573
sales@belson.com
Instructions Sheet
C
J
2018-07-11 – Page 1
Advertisement
Table of Contents
Related Manuals for Belson Outdoors CBPB-6A1B-WG
Summary of Contents for Belson Outdoors CBPB-6A1B-WG
- Page 1 627 Amersale Drive Naperville, IL 60563 Phone: (800) 323-5664 Fax: (630) 897-0573 sales@belson.com CBPB-6A1B-WG Model # Instructions Sheet BEFORE ASSEMBLY, PLEASE MAKE SURE ALL COMPONENTS ARE INCLUDED (2) LEGS (22) M10X45 BOLTS (2) SUPPORT POLES (22) M10 WASHERS (4) BULL NOSE SLATS...
- Page 2 2018-07-11 – Page 2 www.belson.com...
- Page 3 Make sure to assemble the bench on a soft mat to prevent scratching of the product’s surface. Assemble on a at surface to ensure that the bench is level when completed. DURING ASSEMBLY, DO NOT TIGHTEN BOLTS COMPLETELY. Bench Assembly Step 1 Starting with the Legs (A) and Support Poles (B) fasten together with M10X45 Bolts (F:1-4) and M10 Washers (G:1-4).
