ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM7986Q
DIFFICULT
Page 1 of 6
Tools Required for Assembly:
Allen Wrench
Phillips Screwdriver
(Included)
(Not Included)
Rev.14-03-25
Advertisement
Related Manuals for Furniture of America Mandeville CM7986Q
Summary of Contents for Furniture of America Mandeville CM7986Q
- Page 1 Assembly Instructions CM7986Q ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 2 Page 2 of 6...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 6 pcs Headboard Screw #B x 10 pcs #2 x 1 pc Bolt 5/16”x2”...
- Page 4 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling of the product and to avoid any potential injury and/or damage.
- Page 5 Align the bottom rail (#4) with the pre-drilled holes on the back of the headboard (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#E) and then the flat washer (#D) onto the SAME bolt (#E), in that order.
- Page 6 Align the threaded end of the slat support leg (#8) with the pre-drilled hole of the slat (#7) and tighten by hand until secured. Repeat the process for attaching the remaining two slat support legs (#8) onto the two slats (#7). Enlarged Turn right (clockwise) to tighten Adjust the leveler according to the ground...
- Page 7 Assembly Instructions CM7986CK CM7986EK ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Phillips Screwdriver products, two persons are recommended.
- Page 8 Page 2 of 6...
- Page 9 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Parts List Hardware List #1 x 1 pc #A x 8 pcs Headboard Screw #B x 10 pcs #2 x 1 pc Bolt 5/16”x2”...
- Page 10 Due to the size and/or weight of this product, it is highly recommended that the assembly should be done near the area of its intended location. Make sure you have enough space to move around during the assembly. ALWAYS have at least two people to help with transporting and assembling of the product and to avoid any potential injury and/or damage.
- Page 11 Align the bottom rail (#4) with the pre-drilled holes on the back of the headboard (#1). Prepare 4 bolt assemblies by inserting FIRST the lock washer (#C) onto the bolt (#E) and then the flat washer (#D) onto the SAME bolt (#E), in that order.
- Page 12 Each slat (#7) has two slat support legs (#8). Align the threaded end of the slat support legs (#8) with the pre-drilled holes of the slat (#7) and tighten by hand until secured. Repeat the process for attaching the remaining 6 slat support legs (#8) onto the 3 slats (#7).
