R OOM AIR C ONDITIONE R

US E & C AR E MANUAL

P OR TAB L E TY P E R OOM AIR C ONDITIONE R

DOC-091R

MODE L #:

DOC-091R H

UL and

C UL listed

LIS TE D

P lease read carefully and thoroughly this manual before

operating the unit.

If you still have any difficulties or problems, consult your

dealer for help or

P lease keep this manual well.

E LE C TR ONIC S .

Table of Contents

Need help?

Do you have a question about the DOC-091RH and is the answer not in the manual?

Questions and answers

Summary of Contents for Daewoo DOC-091RH

Page 1 R OOM AIR C ONDITIONE R US E & C AR E MANUAL P OR TAB L E TY P E R OOM AIR C ONDITIONE R DOC-091R MODE L #: DOC-091R H UL and C UL listed LIS TE D P lease read carefully and thoroughly this manual before operating the unit.
Page 2: Table Of Contents
1.SAFETY RULES... 2.NAMES OF PARTS... 3.ACCESSORIES... 4.OPERATION PANEL OF THE AIR CONDITIONER... 5.OPERATING INSTRUCTION FOR THE AIR CONDITIONER ... 6.INSTALLATION... 7.MAINTENANCE... 8.TROUBLE SHOOTING... CONTENTS...
Page 3: Safety Rules
SAFETY RULES 1. DO NOT CONNECT UNIT TO ANY AC SOCKET IN DISREPAIR OR WITH CONNECTIONS. 2. DO NOT USE IN THE FOLLOWING LOCATIONS: NEXT TO SOURCE OF FIRE. AN AREA WHERE OIL IS LIKELY TO SPLASH. AN AREA EXPOSED TO DIRECT SUNLIGHT. AN AREA WHERE WATER IS LIKELY TO SPLASH .
Page 4: Names Of Parts
OPRATION PANEL AIR OUTLET REMOTE CONTROLLER CASTER FRONT VIEW PARTS : Check all the accessories are included in the package and please refer to the installation instructions for their usage. NAMES OF PARTS REAR COVER FRONT COVER WATER PUMP DRAIN HOSE AIR INLET OUTDOOR POWER CORD...
Page 5: Operation Panel Of The Air Conditioner
OPERATION PANEL OF THE AIR CONDITIONER(COOLING AND HEATING) DIGITAL DISPLAY FAN SPEED INDICATOR TEMP SETTING BUTTON Press your desired room temperature setting by pressing the button (up) or button (down) INFRARED SIGNAL RECEIVER TIMER ON/OFF INDICATOR TIMER ON/OFF BUTTON Program the on/off timer function...
Page 6: Operating Instruction For The Air Conditioner
Power supply: Insert the AC Power Plug to a AC socket. Do not connect the air conditioner to a multiple socket outlet which is also being used for other electrical appliance. Be sure the power supply is AC 115V~ 60Hz.
Page 7 Do not put the duct to window. 6 TIMER OPERATION Setting the on timer: Press the "TIMER ON" button when the air conditioner is off. Select the time you need the unit start to operate. The Operation Paned Window will display "ON"...
Page 8: Installation
B) PERMANENT- 1. Attach one end of the duct to the exhaust air outlet of the mobile air conditioner. According to the arrow direction, first fit the left side of the duct on the exhaust air panel, then the right side duct. Push it downwards, be sure to fix thoroughly.
Page 9: Maintenance
Window Kit Installation Your window kit has been designed to fit most standard Vertical and horizontal window applications, However, it may be necessary for you to improvise/modify some aspects of the installation procedures for certain types of window. Please refer to Fig. 11 & Fig. 11a for minimum and maximum window openings.
Page 10: Trouble Shooting
TROUBLES POSSIBLE CAUSES 1. UNIT DOES NOT - Water full indicator blinks, water tank START WHEN is full. PRESSING 1/0 BUTTON - Room temperature is higher than the set temperature.(Heating mode) - Room temperature is lower than the set temperature.(Cooling mode) 2.
Page 11 Daewoo authorized s ervice center. T o es tablis h and receive warranty s ervice at our s tore, dealer or our authorized s ervice center, a s ales receipt or bill of s ales is required for proof of purchas e.
