CONTENTS LOCATION OF CONTROLS............................2 MAIN CONTROL & REMOTE SENSOR ........................3 REMOTE CONTROLLER ...............................4 REMOTE DISPLAY.................................4 BASIC OPERATION METHOD ............................6 CHECK AGAIN BEFORE USING ..........................6 REMOVE OUTDOOR UNIT COVER........................6 ON/OFF ..................................7 TO SET TEMPERATURE ............................7 TO SELECT THE FAN SPEED..........................8 TO SELECT THE FAN DIRECTION.........................9 TO SET THE TIMER MODE ............................9 TO SET THE FUNCTION MODE ..........................11 AUTO MODE................................11... -
Page 2: Location Of Controls
LOCATION OF CONTROLS INDOOR UNIT AIR OUT - According to the operation mode, it is opened/closed automatically. MAIN CONTROLS/ AIR IN - It is to suck warm air. REMOTE SENSOR - There is an air filter inside this grille. * The method to open the air suc- tion grille Pull the upper side of grille with both hands. -
Page 3: Main Control & Remote Sensor
MAIN CONTROLS & REMOTE SENSOR ROOM TEMPERATURE / DESIRED TEMPERATURE INDICATOR - It displays current room temperature and desired room temperature. FAN MODE INDICATOR AUTO FAN SPEED INDICATOR AUTO MODE INDICATOR FAN SPEED INDICATOR COOL MODE INDICATOR TIMER/SLEEP INDICATOR QUICK MODE INDICATOR ECONOMY MODE INDICATOR HEAT MODE... -
Page 4: Remote Controller
REMOTE CONTROLLER Display AUTO Displays information pertaining to unit. ON/OFF Button Press to turn the unit on or off. TEMPERATURE Buttons Press to raise or lower FAN SPEED Button the desired temperature. Press to select the fan speed FAN DIR. Button (Auto, High "... -
Page 5: How To Install Batteries
HOW TO INSTALL BATTERIES To install the batteries, follow the procedures below: TIMER 2. Insert two “AAA” size 1. Slide down the cover to access Alkaline batteries fol- most of the remote buttons. Slide ON/OFF ENTER/ TURBO/MILD CANCEL lowing the polarity dia- down further to access the bat- –... -
Page 6: Basic Operation Method
BASIC OPERATION METHOD CHECK AGAIN BEFORE USING Turn on the main power supply switch setted exclusively. The main power supply switch should be located near the indoor unit. 220V • Check the status of main switch for safety. • Turn off the switch when cleaning the unit or not using for a long time. The main power supplying switch is not included to the unit, so, it is neces- sary to buy separately when installing the unit. -
Page 7: On/Off
ON/OFF METHOD BY USING MAIN CONTROL 1. PRESS THE ON/OFF BUTTON • The mode display on indoor unit will light with "beep, beep" sound. And the unit starts "auto" operation. • Repeat ON -> OFF -> ON mode by pressing ON/OFF button. -
Page 8: To Select The Fan Speed
METHOD BY USING REMOTE CONTROLLER 1. SELECT OPERATION MODE BY PRESSING MODE AUTO BUTTON 2. SET DESIRED TEMPERATURE(22˚C) BY USING AUTO TEMPERATURE BUTTON If room temperature reach desired temperature, the unit repeats cool and fan mode automatically to keep desired temperature. TO SELECT THE FAN SPEED METHOD BY USING MAIN CONTROL 1. -
Page 9: To Select The Fan Direction
TO SELECT THE FAN DIRECTION - Remote controller is only available. 1. Press fan direction button to select fan 2. "UP • DOWN" direction Up • down louver moves FAN DIR. • Press desired fan direction button, "LEFT • RIGHT" "UP •... -
Page 10: To Set On Timer Mode
TO SET ON TIMER MODE This unit can be set to automatically turn on after a predetermined amount of hours (up to 24) in the order of 0.5, 1, 1.5, 2, 2.5, 3, 4, 5, 6, 8, 10, 12, 16, 20, 24. 1. -
Page 11: To Set The Function Mode
TO SET THE FUNCTION MODE AUTO MODE METHOD BY USING MAIN CONTROL 1. SELECT AUTO MODE BY PRESSING MODE BUTTON • AUTO -> QUICK -> COOL -> FAN -> DEHUMIDIFI- ER -> HEAT is sequently selected by pressing "MODE" button •... -
Page 12: Cool Mode
COOL MODE MOTHOD BY USING MAIN CONTROL 1. SELECT COOL MODE BY PRESSING MODE BUTTON Desired temperature is available from 18˚C to 32˚C To make room cool and comfortable, adjust desired room temperature by using temperature button. METHOD BY USING REMOTE CONTROLLER 1. -
Page 13: Dehumidifier Mode
DEHUMIDIFIER MODE METHOD BY USING MAIN CONTROL 1. SELECT DEHUMIDIFIER MODE BY PRESSING MODE BUTTON This mode can be selected in case you feel uncom- fortable due to high humidity even though room tem- perature is not high. METHOD BY USING REMOTE CONTROLLER 1. -
Page 14: Economy Mode
ECONOMY MODE - MAIN CONTROL IS ONLY AVAILABLE Select by pressing "economy" button 1. Economy mode can be selected on auto mode, cool, mode, dehumidifier mode Press "economy" button to use economy mode while the unit turn on 2. Economy mode is to avoid excessive cooling and ac- cordingly save electricity by adjusting temperature ir- recognizably during operation If you press "economy"... -
Page 15: Cleaning The Air Filter
CLEANING THE AIR FILTER PLEASE FOLLOW THE INSTRUCTION BELOW 1. Pull forward the insert grille 2. Remove upward the air filter 3. Clean off dust by vacuum cleaner or soft brush 4. If the air filter is dirty, clean that with water below 40˚C melted neutral detergent. -
Page 16: Care And Maintenance
CARE AND MAINTENANCE warning • Make sure the AC cord is unplugged and the unit is off before cleaning. • Do not use water on the unit to clean it. This is a shock hazard and the unit can be damaged. Clean the casing and front of the indoor unit with a vacuum brush or wipe with a clean damp cloth. -
Page 17: Troubleshooting Guide
TROUBLESHOOTING GUIDE Before requesting service, please refer to the chart below for possible solutions: SYMPTOMS POSSIBLE CAUSE POSSIBLE SOLUTIONS No power Power failure. Restore the power Line voltage too low. Contact electrician to install new outlet. Unit is unplugged or not completely Insert plug all the way. -
Page 18: Specifications
SPECIFICATIONS MODEL DPB-280L DPB-280LH Function Cooling only Cooling/Heating (Heat pump) Power Supply AC 220-240V, 50Hz Cooling Capacity (Heating Mode) 28,000 BTU/h 28,000 BTU/h (28,000 BTU/h) Operating Current (Heating Mode) 14A (14A) Power Consumption (Heating Mode) 2,800W 2,800W (2,800W) Indoor Unit Dimensions... - Page 19 S/N : 3103908200...
- Page 20 OWNER'S MANUAL FLOOR STANDING AIRCONDITIONER MODEL #: DPB-280L/DPB-280LH...
