D21 Drop-in Cooktop
EN
Installation and Operating Manual
Recreational Vehicle
Gas Cooking Appliance
HOT PRODUCTS
COOKTOP
D21
WARNING: If the information in this manual is not followed exactly,
a fire or explosion may result, causing property damage, personal
injury, or death.
– Do not store or use gasoline or other flammable vapors and liquids
in the vicinity of this or any other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your recreational vehicle.
• Clear the recreational vehicle of all occupants.
• Turn off the gas supply tank valve(s) or main gas supply.
• Immediately call your gas supplier for instructions.
• If you cannot reach your gas supplier, call the fire department.
– Have the gas system checked and leakage source corrected by a
qualified installer, service agency, manufacturer or dealer, or the gas
supplier.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D21 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Dometic D21

Summary of Contents for Dometic D21

  • Page 1 HOT PRODUCTS COOKTOP D21 Drop-in Cooktop Installation and Operating Manual WARNING: If the information in this manual is not followed exactly, a fire or explosion may result, causing property damage, personal injury, or death. – Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.

  • Page 2: Table Of Contents

    Dometic Corporation 1120 North Main Street Elkhart, IN 46514 REVISION B | Form No. 50269 12/17 | ©2017 Dometic Corporation Read these instructions carefully. These instructions must stay with this product. CONTENTS Explanation of symbols and safety instructions ..........3 General information .

  • Page 3: Explanation Of Symbols And Safety Instructions

    • This product must be installed by a qualified service technician. • Dometic gas-operated cooking units are for use with LP gas only and for installation in recreational vehicles only (e.g. travel trailers, motor homes, tent campers, etc.). Any other uses can lead to property damage, serious injury, or death.

  • Page 4: General Information

    Dometic cover with side windguards, portable or outdoor installations into an enclosure not made from metal or wood must be approved by Dometic prior to use. Do not store the Cooktop outdoors. This Cooktop is not designed for installation adjacent to another Cooktop.

  • Page 5: Installation

    Cooktop 4 INSTALLATION  FIRE, EXPLOSION, OR BURN HAZARD. Do not use matches, candles, or other sources of ignition to test fittings and gas lines for leaks. Doing so could result in an explosion, causing serious injury or death. The gas line material between the Cooktop and the bottom shield must be rated for a minimum of 300°F exposure.
  • Page 6 Cutout Cooktop Drilled Hole ➤ Locate and cut the opening in the countertop For outside use, the Dometic cooktop metal according to the dimensions in “4.1 Constructing cover is required. the cabinet” on page 5. Do not store the Cooktop outside.
  • Page 7 Cooktop 4.3 Connecting the propane gas 4.4 Connecting the 12 V ignition – Switch (Rear of unit) Igniter Electrode Hose Igniter Electrode (Bottom) Connection Ground ➤ Run a propane-certified hose from the propane ➤ Connect the positive and negative wires to the supply tank to the gas connection on the Cooktop.

  • Page 8: Operation

    Cooktop 5 OPERATION 5.1 Operating/safety guidelines  BURN HAZARD, FIRE, EXPLOSION, AND/OR CARBON MONOXIDE HAZARD Failure to obey the following warnings could result in damage, a burn hazard, possible explosion, carbon monoxide buildup, serious injury, or death: • Avoid negative draft or positive draft situations or the operation of this Cooktop during excessively windy conditions.
  • Page 9 Cooktop 5.1 Preparing your cooktop for use Top Cover Gas Shut-Off Cooktop Valve (Rear of unit) Gas Connection ➤ Turn the gas ON at the gas shut-off valve If your Cooktop is equipped with a top cover, (counterclockwise). lift the top cover when operating the Cooktop. 5.2 Lighting the burner All burner controls operate counterclockwise and must be pressed inward when turning to light.

  • Page 10: Maintenance, Cleaning, And Storage

    Cooktop 5.3 Extinguishing the burner 5.4 Changing the battery (battery ignition) Knob Battery Ignition Switch Cover ➤ To extinguish the burner, turn the knob to the ➤ Unscrew the ignition switch cover. “OFF” position to stop the flow of gas to the ➤...

  • Page 11: Disposal

     BURN HAZARD, FIRE, EXPLOSION, AND/OR CARBON MONOXIDE HAZARD. Use only Dometic replacement parts and components, which are specifically approved for use with the Drop-In Cooktop. Failure to obey this warning could result in damage, a burn hazard, possible explosion, carbon monoxide buildup, serious injury, or death.

  • Page 12: Warranty

    (f) failure to follow Seller’s instructions for use of this Dometic Product; (g) any accident to, or misuse of, any part of the Dometic Product and any alteration by anyone other than the Seller or its authorized representative;...
