- Page 1 FAAC-X1K/4GA & FAAC-X1K/3GA End User Instructions For Service and Support, call your dealer/installer on: Company Name Phone Number Email / Web...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Overview of system Receiving a call, opening gate/door Access control by calling the intercom Installing the APP Summary of the APP home screen Keypad codes Permanent keypad codes Time restricted keypad codes Temporary codes Delete codes Proximity cards (selected models only) 24/7 cards (selected models only) Time restricted cards (selected models only) Temporary cards (selected models only) -
Page 3: Overview Of System
Overview of System Thank you for purchasing a FAAC Cell Access System. This product is a cellular Intercom system, which operates on GSM networks AT&T or T-Mobile depending on model and area. You will need to ensure you have adequate cellular coverage at your location before using this product. -
Page 4: Access Control By Calling The Intercom
Installing the FAAC Cell Access App You can use the free FAAC Cell Access App. Take care not to install the Pro version of this app as it is only for installer configuration of your intercom. - Page 5 Enter the phone number of the INTERCOM Enter 9999 (unless changed by engineer on the intercom) and press SAVE Enter 1234 (unless changed by engineer on the intercom) and press SAVE Need help? Call your installer / dealer! IMPORTANT: Android users, if you receive an error message “Command Failed”, go to Phone Settings/Application Manager/Permissions, and turn on all permissions for the app.
-
Page 6: Summary Of The App Home Screen
Summary of the App Home Screen RELAY1 TRIGGER RELAY2 TRIGGER Speed dials the Sends SMS to intercom to open gates momentary trigger relay by callerID (phone 2, perhaps for number must be stored pedestrian gate. in the intercom by installer first). RELAY2 LATCH Sends SMS to latch or hold on relay 2. - Page 7 Permanent Keypad Code Stores up to 200 codes, all of which can be used to gain access 24/7. Enter a 4-digit code Choose relay 1 or relay 2 (pedestrian option) 1 second for gate systems or strike lock. 3-10 seconds for magnetic locks. Can also enter longer time for holding gates open for a pre- defined period.
-
Page 8: Delete Codes
Temporary Code Stores up to 30 codes which will auto expire after the pre-set time has elapsed. Enter a 4-digit code Enter time in hrs (1-168) Need help? Call your installer / dealer! Delete Codes Quick delete for last stored Temp code Quick delete for last stored time restricted code Enter known code you wish to delete here Delete all keypad codes and start over... -
Page 9: Proximity Cards (Selected Models Only)
Proximity Cards (Optional) Cards can be added by serial number printed on the card. There are 3 types of card stored. Ensure to select your correct intercom model. 4G models can store a name against each card for reference. Check with your dealer! Time restricted Prox cards (cards that will only work during pre-set times and days of the week Temporary Prox cards which auto expire in a... - Page 10 Time Restricted Prox Cards Store up to 20 cards which only work during pre-set days and times of the week. (Relay 1 only). Enter card ID (10 digits) xxxxxxxx Enter start time in 24hr format (military style) with no colon. E.g. 8.30am = 0830 Enter end time in 24hr format (military style) with no colon.
- Page 11 Deleting cards This screen allows any known card ID to be deleted (by serial number), and it will also show the last stored cards for each type of card. Enter known card ID (10 digits) xxxxxxxx Delete all stored cards and start again. Need help? Call your installer / dealer!
-
Page 12: Volumes
Volumes Adjust microphone and speaker volumes (1-9, default = 5). If you experience high levels of echo on your phone when speaking to the gate, try reducing the microphone sensitivity on the intercom as much as possible and also reduce the intercom speaker volume if possible. -
Page 13: Troubleshooting
Troubleshooting Problems installing the APP Ensure that the full phone number of the intercom is entered in the settings screen, and that the pass codes used are correct. Your installer can inform you of what the pass codes are for using this app. - Page 16 Cell Access System...
