INSTALLATION INSTRUCTIONS
(English)
614391-F
WWW.BRINKAIRFORLIFE.NL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Elan 10 2.0 and is the answer not in the manual?

Questions and answers

Related Manuals for Brink Elan 10 2.0

Summary of Contents for Brink Elan 10 2.0

  • Page 1 INSTALLATION INSTRUCTIONS (English) 614391-F WWW.BRINKAIRFORLIFE.NL...
  • Page 3 Children may not play with the appliance. If you need a new power cable, always order the replacement from Brink Climate Systems B.V. To prevent dangerous situations, a damaged mains connection must...

  • Page 4: Table Of Contents

    Putting into operation ........Switching the appliance on and o ....Setting the air owrate ........Other settings installer ........Faults ............. Trouble shooting ..........isplay codes ..........Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 5: Delivery

    Before starting installation of the Elan air heater, check that you received it complete an undamaged. The scope of delivery of the indirectly red air heater type Elan includes the following components: Indirectly red air heater type Elan Residents instructions Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 6: Accessories Elan

    B = 450 mm; Elan 16 25 B = 550 mm 007026 008026 Cooling block inverter Up ow 008020 Cooling block inverter own ow 008021 4-way switch 540262 Timer control 510498 Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 7: Application

    Up ow version. 1 = Hot air 2 = Return air ex factory 3 = Options for connection return air after Up ow version own ow version Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 8: Technical Information Elan 10 2.0

    1.29 1.24 1.18 1.12 70 50 1.05 1.00 0.95 0.90 1.05 1.00 0.95 0.90 50 35 0.64 0.58 0.52 0.47 0.64 0.59 0.55 0.50 1.000 1.500 Flowrate [m Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 9: Technical Information Elan 16 2.0

    1.24 1.18 1.13 70 50 1.05 1.00 0.96 0.90 1.05 1.00 0.95 0.90 50 35 0.63 0.57 0.52 0.46 0.62 0.57 0.52 0.46 1000 1500 2000 Flowrate [m Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 10: Technical Information Elan 25 2.1

    1.11 70 50 1.05 1.00 0.95 0.90 1.05 1.00 0.95 0.90 50 35 0.62 0.57 0.52 0.47 0.62 0.57 0.52 0.47 1000 1500 2000 2500 3000 Flowrate [m Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 11: Exploded View Appliance

    Power cable 230 Volt 13 Water connection (return Connection return water mains (Ø 22 mm 14 Heat exchanger This is where heat is exchanged with the air to be heated. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 12: Imensions Elan 10 2.0 Own Ow

    3.5 Dimensions Elan 10 2.0 Down ow 390,5 518,5 387,5 3.6 Dimensions Elan 16 2.0/ Elan 25 2.1 Up ow 625,5 491,5 Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 13: Operation

    In a own ow appliance this 9-pole connector is behind the left-hand lter door; an Up ow appliance has this connector behind the right-hand lter door. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 14: Installation

    The appliance is now an Up ow version. Unscrew the two screws (Torx T20 that hold the control panel to the front panel and rotate this control panel 180 degrees. 2x Torx T20 Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 15: Conversion To Own Ow Version

    Provide the exterior air connection with a control valve and Insulate all hot air ducts including the grill adapters and the connect it to the return duct. exterior air duct. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 16: Conversion From Right-Handed To Left-Handed Appliance

    Take the lter rail from the appliance. 8 Now the Elan appliance has the lter connection on the left- hand side instead of on the standard right-hand side. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 17: Installation Hrv On Elan Own Ow

    5.8 Placing RV on Elan Down ow The Elan own ow is prepared in such a way that a Brink heat Use the optionally available coupling kit (Brink article code recovery unit (HRV Type Renovent Elan can be placed on the 007026 for Elan 10 Brink article code 008026 for Elan 16 25 appliance.

  • Page 18: Electric Connections

    System fan runs continuously at maximum air owrate Ventilation setting o stand-by System fan runs continuously at minimum air owrate Increased fan setting high System fan runs continuously at cooling air owrate Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 19: Display View

    Activate the settings menu; to the next step in the submenu; con rm value change Scroll; modify value Scroll; modify value One step back in menu; cancel value modi cation; lter reset (press for 5 seconds , delete fault history Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 20: Operating Mode

    § 9.1. The Elan appliance is set to the outdoor air programme Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 21: Settings Menu

    To modify other set values, repeat steps 3 - 6. When you do not want to modify any more set values and return to operating mode, press the ‘R’ key. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 22: Readout Menu

    °C Current temperature water temperature sensor °C Percentage system fan setting RPM system fan Status frost protection (ON = frost protection active, OFF = frost protection not active Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 23: Service Menu

    All fault messages can be deleted by pressing the “R” key in the service menu during 5 seconds; This is only possible when there is no active fault! Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 24: Putting Into Operation

    7.3 Other settings installer More settings of the Elan appliance can be changed. How to modify these is explained in §6.3. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...

  • Page 25: Faults

    LE on the multiple switch (if applicable will be blinking. Contact the installer to remedy this fault. A locking fault cannot be remedied by taking the voltage from the appliance; rst the fault must be solved. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 26 If mode 2 of a multiple switch does not work, the modular connector of the multiple switch has been connected the wrong way round. Cut o one of the R connectors to the multiple switch and mount a new connector the other way round. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 27 Clean the lter. After the lter reset, the text FILTER disappears”; the light at the multiple switch is o and the display is back to ope- rating mode. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 28 Remove the lter. Unscrew the front panel with the two lter doors (4 screws and take it out. Take the two fan cables from the pcb. Torx T20 Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 29 10 Clean the fan blades with a dry brush; when cleaning, make sure the balance weights do not shift! Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 30 C10 = yellow Elan 10 2.0 C11 = green Elan 16 2.0 Elan 25 2.1 Water temperature sensor (12K) Output temperature sensor (10K) Service connector D1 = D2 = Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 31 Modular connector X2 for. rpm control Modular connector type R -12 Not suitable Only suitable for low voltage. for 230 V Service connector menu Laptop connection for installer. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 32 Note: For the modular cable used, the “tab” of both modular connectors must be mounted facing the mark on the modular cable. 11.2.2 Wireless remote control without lter indication menu 230V 50Hz Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 33 11.3 Connecting cooling menu See § Step no. escription Factory setting Range Percentage air owrate cooling 10% - 100% Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 34 Appliance type, serial number and year of production are stated on the identi cation plate that is mounted on the side Article code : 530901 of the appliance. uantity 12.2 Service articles Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 35 The packaging should be disposed of in a responsible manner and inaccordance with governmental regula- tions Modi cations reserved Brink Climate Systems B.V. continuously strives after improvement of products and reserves the right to change the speci cations without prior notice. Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1...
  • Page 36 - 30.0°C 0.5 °C Frost safety limit 2 -20.0 °C - 30.0 °C 0.5 °C Hysteresis frost safety 0.0 °C - 5.0 °C 0.1 °C step step step Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 37 : 2015 EN 61000-3-2 : 2014 EN 61000-3-3 : 2013 EN 60335-1 : 2012 EN 60335-2-80 : 2003 + A1: 2004 + A2: 2009 Staphorst, 03-11-21 Managing director Elan 10 2.0 / Elan 16 2.0 / Elan 25 2.1 614391-F...
  • Page 38 BRINK CLIMATE SYSTEMS B.V. Wethouder Wassebaliestraat 8 7951 SN Staphorst The Netherlands Postbus 11 NL-7950 AA Staphorst The Netherlands T. +31 (0) 522 46 99 44 F. +31 (0) 522 46 94 00 info@brinkclimatesystems.nl www.brinkclimatesystems.nl...
