Install Trays and Bin Holder

Place all the parts for the trays and bin holder on a level surface.
Make sure the pieces are in the correct positions before assembling.
!
Carefully follow the order of assembly to ensure an easy installation.
Wear proper safety gear including work shoes, gloves and goggles.
16.1
From the inside of the greenhouse, place the trays on the
shelves. The trays interlock together and rest on the
16.2A
Slide long side of
connector S37 into
G04G, lining up the
last hole on the
connector with the
hole in the channel.
Secure each S37 connector
16.2B
with one S02 screw.
S37
IMPORTANT: S36 are self tapping screws used to screw into areas that do not have predrilled holes. When you
16.3A
Secure each connector with
16.3B
one S36 screw.
S36
www.stcny.com
S02
NOTE: A cordless drill with a phillips head bit is recommended.
QTY
#G04G
G04G
Connector
2 #S37
56 of 56
Trays
#J05
G04G
Screw
QTY
#S02
4
#S36
QTY
30
QTY
4
4
