Subaru E5610CC150 Installation Manual

This manual describes how to install the rear under diffuser.
Request
Before installing this product, please ensure to read this manual and carry out proper installation.
Precautions
！
1. When installing this product on a car, park the car on a fla t surface and securely apply
the parking brake before carrying out the work.
2. Before starting the installation work, use a neutral detergent (or cleaning detergent) and
waste cloth to remove dirt adhering to the car's surfaces to which the rear under diffuser are
to be attached, and completely dry the surfaces. Moreover, if sand or mud adheres to the
back of the clip insertion holes, etc., then clean the contaminated sections.
3. Install the rear under diffuser before applying a car body coating treatment. When installing
them on a coated car, remove the coating in the areas where the double-sided tape is to
be applied before carrying out the installation work.
4. During the installation work, pay careful attention not to damage the car with tools, etc.
5. The purpose of this document is to illustrate explanations common to installation work
on the left and right sides. Check the shape of the components to be installed before
carrying out the work.
6. When the air temperature is 15℃ or lower, use a dryer to warm up this product and the
surfaces of the car where the double-sided tape is to be applied to 30℃ to 50℃ or
thereabouts. Avoid using an industrial dryer.
7. The double-sided tape attached to this product does not adhere to the surfaces unless it
is adequately pressed. Moreover, reattaching the product significantly reduces the
adhesive strength of the tape; therefore, properly position the product before attaching it
to the car.
8. The adhesive strength of the double-sided tape gradually increases after it is applied to
the car. Avoid washing the car within 24 hours after attachment . When washing and
waxing the car are necessary on the day of the attachment, leave the car as is for at
least one hour and subsequently cover the rear under diffuser with tape, etc. to prevent
water from penetrating into areas where the double-sided tape is applied. Further, be
careful not to apply an excessive force to the guards.
9. When blowing air on this product after it is attached to the car, maintain a distance of
at least 300 mm between the exhaust port of the blower and the product. Insufficient
distance may cause this product to peel.
10. When a car has undergone a body coating treatment including glass coating, this
product cannot exhibit its original adhesive performance. Please confirm whether or not
a body coating treatment is applied to the car. Moreover, ensur e to remove dirt, oil,
grease, etc. adhering to the surface on which the product is to be attached, and also
ensure to adequately pressure bond it to the car.
<<How to remove a body coating film and confirm the removal>>
- Use a fine-grained compound agent (so as not to affect the ca r's paint) to rub the coating
film off the area on which the product is to be attached.
- After polishing the area, spray water on it. You can confirm that the coating film has been
removed when there is no repelling of water on the area.
REAR UNDER DIFFUSER
