Subaru E5510SL200 Installation Manual

Rear bumper trim forester 2025my-

Download this manual

Genuine SUBARU part numbers: E5510SL200 (Turquoise blue)

Vehicle model:

To installation worker

This manual describes how to install and handle REAR BUMPER

TRIM.

1. Before installation, be sure to read this manual for proper work.

2. The caution mark ⚠ in this manual indicates important instructions.

Strictly follow them.

3. SUBARU may not be held responsible for problems that occur due to

your failure to follow this installation manual.

⚠ Important instructions

1. Before starting installation work, move the vehicle to a safe location.

2. To work safely, make sure that the vehicle does not move.

（Make sure to apply parking brake.）

3. After turning the ignition off, disconnect the battery ground terminal.

4. Handle this product with care not to damage it or the vehicle.

Rev. No.

New establishment

REAR BUMPER TRIM

E5510SL220 (Silver)

FORESTER 2025MY～

Revision content

Distributor: SUBARU Co., Ltd.

Δ00

Installation manual

Date

2023/8/9

Need help?

Do you have a question about the E5510SL200 and is the answer not in the manual?

Page 1 1. Before installation, be sure to read this manual for proper work. 2. The caution mark ⚠ in this manual indicates important instructions. Strictly follow them. 3. SUBARU may not be held responsible for problems that occur due to your failure to follow this installation manual. ⚠ Important instructions 1.
Page 2 Completed installation sketch Rear Bumper Trim Component parts ■E5510SL200 (turquoise blue) / E5510SL220 (silver) Item name Rear Bumper Trim　RH ① Rear Bumper Trim　LH ② ② ① Tools required for work Protective Cleaner Plastic Gloves Phillips head tape remover (Nonane is screwdriver recommended.)
Page 3 Work procedures 1. Remove the rear bumper. (1) To replace the molding with this product, remove the rear bumper from the vehicle. ・Read the service manual to do this work. ・The removed parts are reused. Be careful not to lose or damage them during work. ・Be careful of harness connectors including sensors.
Page 4 3. Replace the molding with this product. (1) Remove the screw (one side: 1 place) that fastens the molding to the bumper guard. (2) While widening the claw fitting portion (on bumper guard), remove the claws (one side: 6 places) on the molding. (A plastic remover helps remove claws easily.) (3) After removing all the claws, install this product to the bumper guard.
