- Page 1 Quick Guide ASCENT 2019 Love. It’s what makes a Subaru, a Subaru.
-
Page 2: Table Of Contents
Table of Contents EyeSight EyeSight and EyeSight Functions EyeSight Operation Steering Wheel Controls Lane Departure Warning and Pre-Collision Braking System OFF Switches EyeSight Limitations Stereo Color Cameras Precautions Windshield Glass and Dashboard Other Driver Assist Technologies Rear Cross Traffic Alert (RCTA) -
Page 3: Eyesight
EyeSight EyeSight is a driving support system that uses a range of functions to assist the driver in making decisions in order to provide for more safe and comfortable driving and to reduce driver fatigue. It is designed to help assist drivers, not replace them. -
Page 4: Eyesight Operation
Conventional Cruise Control maintains a constant driver set speed. It does not mirror the speed of a vehicle traveling in the same lane ahead of the EyeSight vehicle. See the Owner’s Manual for additional information. -
Page 5: Steering Wheel Controls
Steering Wheel Controls Adaptive Cruise Control switch RES/+ switch SET/– switch Lane Keep Assist switch INFO/SET switch Following Distance Setting / Conventional Cruise Control switch... - Page 6 INFO/SET switches Use the arrows above and below to set the volume of the EyeSight warnings and to view information on other vehicle functions in the multi-function display. Adaptive Cruise Control switch Press to activate or deactivate Adaptive Cruise Control function.
-
Page 7: Lane Departure Warning And Pre-Collision Braking System Off Switches
Lane Departure Warning and Pre-Collision Braking System OFF Switches The switches are located on the overhead console. Consult the Owner’s Manual for more detailed information. Lane Departure Warning OFF switch Press and hold this switch for two seconds to turn off the Lane Departure Warning and the Lane Sway Warning functions. -
Page 8: Eyesight Limitations
EyeSight functions will be activated. Always observe the following precautions: • Do not touch or try to clean the EyeSight camera lenses inside the vehicle. Extra precaution should be used when cleaning the inside of the windshield. Over-spray from cleaners may impair or even damage the cameras’... -
Page 9: Windshield Glass And Dashboard
Windshield Glass and Dashboard There must be no oil film, dirt, scratch or fogging that obstructs the forward visibility of the stereo color cameras. Do not stick or attach aftermarket parts on the prohibited areas shown in gray on the windshield and top of the dashboard in the image in this section. - Page 10 FRONT VIEW (A) 335 mm (13.2 in) (C) 243 mm (9.6 in) (B) 139 mm (5.5 in) (D) Prohibited area (in gray) PC-10057...
-
Page 11: Other Driver Assist Technologies
Other Driver Assist Technologies Rear Cross Traffic Alert (RCTA) (if equipped) Rear Cross Traffic Alert (RCTA) notifies the driver of a collision danger if a vehicle is detected approaching from either direction, perpendicular to the reversing vehicle. The system uses radar detection sensors located in the left rear and right rear of the vehicle. -
Page 12: Reverse Automatic Braking (Rab) System
The system works in conjunction with the EyeSight system. The EyeSight system detects a vehicle ahead, or oncoming vehicles, and switches the headlights automatically from high beam to low beam. See the Owner’s Manual for complete details on system operation and limitations. - Page 13 Notes...
- Page 14 Your Subaru Retailer is the best source for the most current information. For detailed operating and safety information, always consult the Owner’s Manual.
