Note: The multiple controller integration
on the display using the FC bus cannot
support applications where BACnet
IP connection on the Applied Smart
Equipment controller is utilized. For this
application, FC bus does not support
BACnet IP, Modbus
4. Refer to Table 14 for detailed information on
kit components.
5. Use the RJ-12 modular jack for FC bus
provided on the controller to connect to the
MAP. Terminate the RJ-45 cable on the display
from the MAP in any of the available (ETH0/
ETH1/ETH2) ports. This guide shows the RJ-45
cable connected to the ETH2 port on the
display.
Note: Refer to
MAP application
6. For SA and FC bus cable recommendations
and controller terminal block information,
refer to the BACnet Integration Setup section
in the Johnson Controls Premier Rooftop Units
Start-Up and Operation Guide (5881375-JSG-A).
16 Advanced Graphic Touchscreen Display on 25 Ton to 80 Ton Johnson Controls Premier Rooftop Units
or N2.
™
Setting up and viewing
for more details.
