Altronix DC Outdoor Power Supply/Chargers provide 12VDC or 24VDC and are designed to be conveniently located
where power is required.
Altronix
Model Number
Current
WayPoint3
WayPoint5
WayPoint7
WayPoint7V
WayPoint1012V
Input:
• Input: 115VAC, 60Hz or 230VAC, 50Hz.
Output:
• 12VDC or 24VDC selectable output
(12VDC only for WayPoint1012V).
• Filtered and electronically regulated output.
• Thermal overload and short circuit protection.
Battery Backup:
• Built-in charger for sealed lead acid or
gel type batteries.
• Maximum charge current:
WayPoint3/5/7/7V: 500mA
WayPoint1012V: 700mA.
• Automatic switch over to stand-by battery.
Wiring methods should be in accordance with the National Electrical Code/NFPA 70/NFPA 72/ANSI, and with all
local codes and authorities having jurisdiction.
1. Remove backplane from the enclosure prior to mounting (do not discard hardware).
2. Mark and drill desired inlets on the enclosure to facilitate wiring (Fig. 1, pg. 3).
3. Mount unit in the desired location. For wall mounting refer to Fig. 4, pg. 7.
For pole mounting installation refer to pg. 7 - (Using Optional Altronix Pole Mount Kit PMK1 - not included).
4. Install backplane inside the enclosure with hardware.
5. Set power switch, if applicable, to the OFF position (Fig. 2c, pg. 4).
Ground
6. Connect AC power (115VAC or 230 VAC) as follows: Green branch wire connects to earth (safety)
ground lug . (Fig. 2-3, pgs. 4-5).
Wire gauge range of connectors is 14 AWG to 11 AWG (1.6mm to 2.5mm diameter).
7. Select the desired DC output voltage by setting SW1 to the appropriate position for models WayPoint3,
WayPoint5, WayPoint7, and WayPoint7V (Reference Chart above) (Fig. 2a, pg. 4).
WayPoint1012V provides 12VDC only.
8. Set power switch to the ON position (Fig. 2b, pg. 4).
9. Measure output voltage at the terminals marked [– DC +] before connecting devices
(Fig. 2b, pg. 4, Fig. 3a, pg. 5). This helps avoiding potential damage.
Note: Power supplies mounted in weatherproof enclosures should be derated by approximately 50%
due to the harsh environmental conditions.
10. Set power switch to the OFF position (Fig. 2b, pg. 4).
- 2 -
WayPoint DC Reference Chart:
Output Output
Voltage
2.5A 12VDC or 24VDC
3.5A 12VDC or 24VDC
6A 12VDC or 24VDC
6A 12VDC or 24VDC
10A 12VDC

Installation Instructions:

5A 250V
L G N
CAUTION
HIGH VOLTAGE
Lug
Overview:
SW1
12VDC
ON
ON
ON
ON
N/A

Specifications:

Features:
• AC and DC power LED indicators.
• Ease of installation saves time and eliminates
costly labor.
• Includes battery leads.
Accessories:
• Optional PMK1 Pole Mount Kit simplifies
installation of outdoor units.
Enclosure:
OFF - 24V
• NEMA 4/4X, IP66-11 Rated enclosure for
ON - 12V
outdoor use.
• Enclosure Dimensions (H x W x D approx.):
13.31" x 11.31" x 5.59"
(338.1mm x 287.3mm x 142mm)
• Enclosure accommodates up to two (2)
12VDC/7AH batteries.
AC DC
115VAC/60Hz
Input
24VDC
Current Draw
OFF 0.95A
OFF 0.95A
OFF 1.9A
OFF N/A
N/A
OFF - 24V
ON - 12V
--- BAT + --- DC +
--- BAT + --- DC +
230VAC/50Hz
Input
Current Draw
0.6A
0.6A
N/A
0.95A
3.0A
