(11) Now that you have reached the GUI, you are ready to modify the settings for the encode that you
want to do. Verify "Video Source" is "SDI" and "Output Interface" is "ASI+Ethernet(CBR)." Change
"Output Format" to "MPEG-2 TS", and confirm "Dest IP Address" is "225.1.2.3" and "Dest Port" is
8888:
(1) Verify "Video Source"
is "SDI"

Figure 9 Changes to Encoding Parameters for TS Encode

____________________________________________________________________________________
Z3 Technology, LLC ♦ 100 N. 8th St. STE 250 ♦ Lincoln, NE 68508-1369 USA ♦ +1.402.323.0702
CONFIDENTIAL
12
DOC-USR-0018-09
(2) Confirm "Output
Interface" is set to
"ASI+Ethernet"
(3) Verify
"Output
Format" is
"MPEG-2 TS"
(4) Confirm "Dest IP
Address" is 225.1.2.3
(5) Set "Dest Port" to 8888
