6/32 About this documentation
Bosch Rexroth AG, ActiveShuttle: Lithium-ion battery, 3 842 560 864/2021-10
Safety instructions are set out as follows:
Type and source of danger!
Consequences of non-compliance

Measures to prevent danger

...
• Safety sign: Points out the danger
• Signal word: Indicates the severity of the danger
• Type and source of danger: Indicates the type and source of the danger
• Consequences: describes the consequences of non-compliance
• Prevention: States how the danger can be avoided
Table 2: Risk classes according to ANSI Z535.6-2006
Warning sign, signal word
DANGER
WARNING
CAUTION
NOTICE
1.1.2

Symbols

The following symbols indicate important information that is not safety-relevant but
increases the comprehensibility of the documentation.
Table 3: Meaning of the symbols
Symbol Meaning
If this information is not observed, the product cannot be used and/or
operated as designed.

Single, independent action
1. Numbered steps:
2. The numbers indicate that the action steps are subsequent.
3.
1.1.3

Designations

This document uses the following designations:
Table 4: Designations
Designation Meaning
AMS ActiveShuttle Management System
SIGNAL WORD
Meaning
Indicates a hazardous situation that will result in serious
injury or death if not avoided.
Indicates a hazardous situation that may result in serious
injury or death if not avoided.
Indicates a hazardous situation that may result in minor
to moderate injury if not avoided.
Property damage: The product or the surrounding area
could get damaged.
