SharpStreamer™ Pro PCIE-7210/7211
Installation and Use
P/N: 6806800V01A
March 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SharpStreamer Pro PCIE-7210 and is the answer not in the manual?

Questions and answers

Related Manuals for Artesyn Embedded Technology SharpStreamer Pro PCIE-7210

Summary of Contents for Artesyn Embedded Technology SharpStreamer Pro PCIE-7210

  • Page 1 SharpStreamer™ Pro PCIE-7210/7211 Installation and Use P/N: 6806800V01A March 2018...
  • Page 2 © Copyright 2018 Artesyn Embedded Technologies, Inc. All rights reserved. Trademarks Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other names and logos referred to are trade names, trademarks, or registered trademarks ©...

  • Page 3: Table Of Contents

    Contents About this Manual ............... 11 Safety Notes .
  • Page 4 Contents Power ................40 Interface Mechanism .
  • Page 5 Contents 5.2.1 Main Menu ..............77 5.2.2 Advanced Menu .
  • Page 6 Contents SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)
  • Page 7 List of Tables Table 1-1 Standard Compliances ............26 Table 1-2 Ordering Information .
  • Page 8 List of Tables SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)
  • Page 9 List of Figures Figure 1-1 Mechanical Layout ............25 Figure 3-1 SharpStreamer™...
  • Page 10 List of Figures SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 11: About This Manual

    About this Manual Overview of Contents This manual is divided into the following chapters and appendices. Safety Notes on page 15 provides information about the safety regulations that should be  observed while operating the product. Sicherheitshinweise on page 19 provides information about German translation of the ...
  • Page 12 About this Manual About this Manual Abbreviations This document uses the following abbreviations: Abbreviation Definition CPLD Complex Programmable Logic Device DHCP Dynamic Host Configuration Protocol DIMM Per Channel Field Replaceable Unit GPIO General Purpose Input Output HEVC High Efficiency Video Coding Internet Service Provider JTAG Joint Test Action Group...
  • Page 13 About this Manual Conventions The following table describes the conventions used throughout this manual. Notation Description 0x00000000 Typical notation for hexadecimal numbers (digits are 0 through F), for example used for addresses and offsets 0b0000 Same for binary numbers (digits are 0 and 1) bold Used to emphasize a word Used for on-screen output and code related elements...
  • Page 14 About this Manual About this Manual Notation Description Indicates a hazardous situation which, if not avoided, could result in death or serious injury. Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury Indicates a property damage message. No danger encountered.

  • Page 15: Safety Notes

    Safety Notes This section provides warnings that precede potentially dangerous procedures throughout this manual. Instructions contained in the warnings must be followed during all phases of operation, service, and repair of this equipment. You should also employ all other safety precautions necessary for the operation of the equipment in your operating environment.
  • Page 16 Safety Notes Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to correct the interference at his own expense. Changes or modifications not expressly approved by Artesyn Embedded Technologies could void the user's authority to operate the equipment.
  • Page 17 Safety Notes Installation Damage of Circuits Electrostatic discharge and incorrect installation and removal of the product can damage circuits or shorten their life. Before touching the product or electronic components, make sure that your are working in an ESD-safe environment. Product Damage Incorrect installation of the product can cause damage of the product.
  • Page 18 Safety Notes SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 19: Sicherheitshinweise

    Sicherheitshinweise Dieses Kapitel enthält Hinweise, die potentiell gefährlichen Prozeduren innerhalb dieses Handbuchs vorrangestellt sind. Beachten Sie unbedingt in allen Phasen des Betriebs, der Wartung und der Reparatur des Systems die Anweisungen, die diesen Hinweisen enthalten sind. Sie sollten außerdem alle anderen Vorsichtsmaßnahmen treffen, die für den Betrieb des Produktes innerhalb Ihrer Betriebsumgebung notwendig sind.
  • Page 20 Sicherheitshinweise Das Produkt wurde in einem Artesyn Standardsystem getestet. Es erfüllt die für digitale Geräte der Klasse A gültigen Grenzwerte in einem solchen System gemäß den FCC-Richtlinien Abschnitt 15 bzw. EN 55022 Klasse A. Diese Grenzwerte sollen einen angemessenen Schutz vor Störstrahlung beim Betrieb des Produktes in Gewerbe- sowie Industriegebieten gewährleisten.
  • Page 21 Sicherheitshinweise Überhitzung und Beschädigung des Produktes Betreiben Sie das Produkt ohne Zwangsbelüftung, kann das Produkt überhitzt und schließlich beschädigt werden. Bevor Sie das Produkt betreiben, müssen Sie sicher stellen, dass das Gerät über eine Zwangskühlung verfügt. Fehlerhafter Datenbestand Wenn sie die Spannungsversorgung des Produkts abschalten, während Programmdaten im Flashspeicher aktualisiert, werden, können diese Daten nicht korrekt gespeichert werden.
  • Page 22 Sicherheitshinweise SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 23: Introduction

    PCI Express card footprints that are easily deployable in off-the-shelf platforms. Each SharpStreamer Pro PCIE-7210/7211 CPU is capable of up to eight (8) streams of 1080p30 H.265/High Efficiency Video Coding (HEVC) transcodes, or four (4) streams of 1080p60 H.265/HEVC transcodes.

  • Page 24: Hardware Overview

    Introduction Two DDR4 SODIMM modules connected to each Intel® Xeon® ProcessorE3-1578L v5 / E3-  1585L v5 each with 8GB memory. Two uSD card slots supporting up to 32GB, one for each processor.  Two USB 2.0 ports on faceplate one from each processor. ...

  • Page 25: Software Overview

    Introduction In the MaxCore implementation, each CPU communicates with the host server through a direct-attached PCI Express x8 Gen 3 link. The PCI Express version utilizes a non-transparent PCI Express x16 Gen 3 (128Gbps) bridge to connect to the host’s PCI Express interface. Each CPU supports up to 32GB of removable DDR4 dual channel memory.

  • Page 26: Standard Compliances

    Introduction Standard Compliances The PCIE-7210/7211 card meets the following standards. Table 1-1 Standard Compliances Standard Description 47CFR15 (FCC) Class A ANSI C63.4 Radiated Emissions EN 55032,CISPR 32 Class A ICES-003 Class A 47CFR15 (FCC) ANSI C63.4 Conducted Emissions EN 55032, CISPR 32 Class A ICES-003 Class A EN 300 386 v1.6.1: 2012 EN 61000-4-2: 2009 EN 300 386 v1.6.1: 2012 EN 61000-4-3: 2010...

  • Page 27: Table 1-3 Ordering Information

    Introduction Table 1-2 Ordering Information Part Number Description ® ® PCIE-7210-2-32GB PCIE card with two 2GHz Intel Xeon E3-1578L v5 CPUs, 32GB SSD per CPU, 16GB RAM per CPU. variants are EOL now, do not support I210 and SSD. PCIE-7210-2 (EOL) and PCIE-7210-2-3GHZ(EOL) Table 1-3 Ordering Information Part Number Description...
  • Page 28 Introduction SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 29: Hardware Preparation And Installation

    Chapter 2 Hardware Preparation and Installation This chapter provides information on unpacking and inspecting the card procedures and safety precautions to be followed while handling the card. The environmental, thermal, and power requirements, and the installation and removal procedures of the card are also explained in this chapter.

  • Page 30: Environmental, Thermal, And Power Requirements

    Hardware Preparation and Installation 3. Remove the desiccant bag shipped with the card and dispose it according to your country’s legislation. Make sure the card is thoroughly inspected before shipment. If any damage has occurred during transportation please contact our Contact Center immediately. Environmental, Thermal, and Power Requirements This section contains the environmental, thermal, and power requirements of the PCIE-...

  • Page 31: Power Requirements

    Hardware Preparation and Installation The following table provides the environmental and the thermal requirements for the PCIE- 7210/7211 card. Table 2-1 Environmental and Thermal Requirements Requirement Operating Non-Operating Temperature 0°C to 35°C -40°C to 70°C Minimum Airflow 500 LFM (2.5 m/sec) (Reference to sea level) 400 LFM (2 m/sec) for 35°C Operation...

  • Page 32: Precautions

    Hardware Preparation and Installation Precautions To reduce the risk of personal injury, fire, or damage to the equipment, do not  overload the AC supply circuit that provides power to the chassis. The card must be powered and connected only to a controlled voltage source. ...

  • Page 33: Esd Prevention

    Hardware Preparation and Installation 2.3.1 ESD Prevention Static electricity may hurt you or damage the device. To minimize the damage, pay attention to the following points: Before touching the card or electronic components, make sure that you are working in an ...

  • Page 34: Pcie-7210/7211 Card Installation And Removal

    Hardware Preparation and Installation PCIE-7210/7211 Card Installation and Removal This section contains the PCIE-7210/7211 card installation and removal procedures. Shipping the card along with a server is not recommended. If you still need to ship the card along with the server, ensure the card is properly secured in the server.

  • Page 35: Pcie-7210/7211 Card Removal

    Hardware Preparation and Installation 4. Insert the PCIE-7210/7211 card into the PCIe slot, secure it, and ensure that the card is properly fitted in the PCIe slot. 5. Lock the slot ejectors, close the system cover and then power on the system. Make sure that the card has enough air flow after closing the system with the cover.
  • Page 36 Hardware Preparation and Installation 4. Remove the screw holding the front panel bracket and gently pull the PCIE-7210/7211 card from the slot. Place the PCIE-7210/7211 card into an ESD-protective bag and seal it appropriately. 5. Close the cover of the system. SharpStreamer™...

  • Page 37: Functional Description

    Chapter 3 Functional Description This chapter describes the functional blocks of the SharpStreamer™ Pro PCIE-7210/7211 card. The PCIE-7210/7211 server accelerator card provides the processor subsystem for the Artesyn MaxCore system. The PCIE-7210/7211 comes in a PCI Express like form factor with MaxCore- specific modifications and extensions.

  • Page 38: Cpu Complex

    Functional Description CPU Complex The CPU complex of PCIE-7210/7211 card comprises an Intel E3-1578L v5 / E3-1585L v5 processor and a PCH. 3.1.1 Intel Skylake Processor Skylake is an Intel core-2015 platform. It is 64 bit, multi core processor built on 14nm process technology.

  • Page 39: Ddr4 2133 Memory

    Functional Description Interrupt controller  Timer functions  DDR4 2133 Memory The PCIE-7210/7211 card comes with four DDR4 SODIMM channels, two on each E3-1578L v5 / E3-1585L v5 processor. Each DIMM is populated with 8GB of memory. That means, each processor has an 16GB DDR4 memory (8GB on each channel) running at DDR4-2133 speed, resulting a total 32GB of memory on each PCIE-7210/7211 card.

  • Page 40: I210

    Functional Description 3.4.2 I210 The 1 G Ethernet Interface (PCIE port2) of each PCH is connected to 2nd Edge connector through I210 interface. Note: PCIE-7210-2(EOL) and PCIE-7210-2-3GHZ(EOL) variants do not have the I210 1GbE Ethernet interface. Power A 12 V power supply is provided to the card through two PCIe Gold Finger edge connectors (Edge connector 1 and Edge connector 2).

  • Page 41: Low Speed Serial Interface

    Functional Description Two 10 Gigabit Ethernet controllers are used between E3-1578L v5 / E3-1585L v5 processors for Inter CPU communication. Each device operates at 10 Gb speed. SATA  – Two SATA ports are connected between each PCH and the Edge connector 2. Each port operates at 6 GB speed.

  • Page 42: Svid

    Functional Description 3.6.2.2 SVID The System V interface Definition (SVID) is a 3-wire digital interface used to transfer power management information between the Master and Slave. In PCIE-7210/7211, the processor acts as a Master and the voltage regulators act as slaves for this SVID interface. 3.6.3 Boot Controller The boot controller is responsible for managing the boot process.

  • Page 43: Microsd As Firmware Recovery Option

    Functional Description The following figure shows the location of the microSD card slots on the PCIE-7210/7211 card. Figure 3-2 microSD Card Location CPU1- Micro SD card slot CPU2- Micro SD card slot 3.7.1 MicroSD as Firmware Recovery Option The microSD can be used as a BIOS recovery option. For this you need to perform the following steps: 1.

  • Page 44: Microsd As Non-Volatile Storage

    Functional Description 3.7.2 MicroSD as Non-Volatile Storage The microSD slots can accommodate up to 32GB of flash storage that can be used as storage, similar to a flash thumb drive. 3.7.3 MicroSD as Boot Device By default, during the card boot operation, the BIOS will first look for a boot record on the microSD storage device.

  • Page 45: Clock Distribution

    Functional Description Figure 3-3 shows the location of the temperature sensors on the card. Figure 3-3 Location of Temperature Sensors - Secondary Side U68 Temperature Sensor U91 Temperature Sensor Clock Distribution Clocking for each CPU complex consists of two input crystals. One 24 Mhz crystal to drive all the main buses and a 32.768 Khz crystal to drive the real time clock.

  • Page 46: 3.11 Jtag

    Functional Description 3.11 JTAG The PCIe slot JTAG pins are mapped to the CPLD JTAG programming pins. CPLD programming port at connector P2 (Independent connector for CPLD)  E3-1578L v5 / E3-1585L v5 and PCH JTAG pins are connected to XDP connector ...

  • Page 47: Controls, Indicators, And Connectors

    Chapter 4 Controls, Indicators, and Connectors This chapter contains information about the controls, indicators, and connectors associated with the PCIE-7210/7211 card. Connectors 4.1.1 PCIE-7210/7211 Faceplate View The following figure shows the faceplate view of PCIE-7210/7211 card. Figure 4-1 PCIE-7210/7211 Faceplate Push Button Reset CPU1 Push Button...

  • Page 48: Edge Connector 1

    Controls, Indicators, and Connectors The PCIE-7210/7211 card comes with two gold finger edge connectors referred as Edge Connector 1 and Edge Connector 2. 4.1.2 Edge Connector 1 This section provides information about the PCIE-7210/7211 card Edge Connector 1 (Gold Finger) pinout. Table 4-1 Edge Connector 1 Pinout Pin # Name...
  • Page 49 Controls, Indicators, and Connectors Table 4-1 Edge Connector 1 Pinout (continued) Pin # Name Side B Description Name Side A Description Tx_N(0) Differential pair Ground Ground Rx_P(0) Receiver Lane 0 PRSNT2# Hot-Plug presence detect Rx_N(0) Differential pair Ground Ground Tx_P(1) Transmitter Lane 1 RSVD Reserved...
  • Page 50 Controls, Indicators, and Connectors Table 4-1 Edge Connector 1 Pinout (continued) Pin # Name Side B Description Name Side A Description Tx_P(6) Transmitter Lane 6 Ground Tx_N(6) Differential pair Ground Ground Rx_P(6) Receiver Lane 6 Ground Rx_N(6) Differential pair Tx_P(7) Transmitter Lane 7 Ground Tx_N(7)

  • Page 51: Edge Connector 2

    Controls, Indicators, and Connectors Table 4-1 Edge Connector 1 Pinout (continued) Pin # Name Side B Description Name Side A Description Tx_N(12) Differential pair Ground Ground Rx_P(12) Receiver Lane 12 Ground Rx_N(12) Differential pair Tx_P(13) Transmitter Lane 13 Ground Tx_N(13) Differential pair Ground Ground...
  • Page 52 Controls, Indicators, and Connectors Table 4-2 PCIE-7210/7211 Card Edge Connector 2 Pinout (continued) Pin # Name Side B Description Name Side A Description +12V +12 Volt power +12V +12 Volt power +12V +12 Volt power +12V +12 Volt power +12V +12 Volt power +12V +12 Volt power...
  • Page 53 Controls, Indicators, and Connectors Table 4-2 PCIE-7210/7211 Card Edge Connector 2 Pinout (continued) Pin # Name Side B Description Name Side A Description Ground PCH1_USB Differential pair 2_BMC_D PCH2_GE Gigabit Ethernet port Ground 0_EXT_R receiver of PCH2 (Diff pair) X_D_P PCH2_GE Ground 0_EXT_R...
  • Page 54 Controls, Indicators, and Connectors Table 4-2 PCIE-7210/7211 Card Edge Connector 2 Pinout (continued) Pin # Name Side B Description Name Side A Description Ground PCH1_100 Reference Clock of PCH1 M_REFCLK_ Ground PCH1_100 Differential pair M_REFCLK_ CON_EX PCIe edge present input Ground T_PRSNT Not connected...
  • Page 55 Controls, Indicators, and Connectors Table 4-2 PCIE-7210/7211 Card Edge Connector 2 Pinout (continued) Pin # Name Side B Description Name Side A Description PCH1_LP LPC Port of PCH1 bus Ground C_LAD0 PCH1_LP PCH1_LPC_ LPC Frame of PCH1 C_LAD1 LFRAME_N PCH1_LP PCH1_SERI LPC Interrupt signal C_LAD2...
  • Page 56 Controls, Indicators, and Connectors Table 4-2 PCIE-7210/7211 Card Edge Connector 2 Pinout (continued) Pin # Name Side B Description Name Side A Description PCH2_SA SATA1receiver Port of PCH2 Ground TA1_RX_ (Diff pair) PCH2_SA Ground TA1_RX_ Ground PCH2_SATA SATA1 transmitter port of 1_TX_D_P PCH2 (Diff pair) Ground...
  • Page 57 Controls, Indicators, and Connectors Table 4-2 PCIE-7210/7211 Card Edge Connector 2 Pinout (continued) Pin # Name Side B Description Name Side A Description PCH1_SA SATA1 receiver port of Ground TA1_RX_ PCH1 (Diff pair) PCH1_SA Ground TA1_RX_ Ground PCH1_SATA SATA1 transmitter port of 1_TX_D_P PCH1 (Diff pair) Ground...

  • Page 58: Micro Usb Uart Port

    Controls, Indicators, and Connectors 4.1.4 Micro USB UART Port The micro USB-UART port is the UART0 port of the PCH through CP2105-F01-GMR silabs device. Table 4-3 Micro USB-UART port pinout Name VBUS Data- Data+ Identification 4.1.5 MicroUSB Port The micro USB port is the USB 1 port of the PCH. Table 4-4 Micro USB port pinout Name VCC 5V...

  • Page 59: Leds

    Controls, Indicators, and Connectors LEDs The following figure shows the general usage LEDs D17, D15, D13, D14, D16, D14, D12, and D10. Figure 4-2 General Usage LEDs 5 1 D 3 1 D 1 1 D 6 1 D 4 1 D 2 1 D 0 1 D Table 4-5 Sleep Signal Status...

  • Page 60: Faceplate Leds

    Controls, Indicators, and Connectors Table 4-5 Sleep Signal Status (continued) Representation Value Status By default, the LEDs D17 and D15 will be glowing. The following figure shows the faceplate LEDs D22 and D21. Figure 4-3 Faceplate LEDs Table 4-6 Faceplate LEDs Processor Value Status...

  • Page 61: Table 4-7 Cpu1 And Cpu2 Nic 82599 Leds

    Controls, Indicators, and Connectors The following figure shows the CPU1 and CPU2 NIC 82599 LEDs D40, D44, D36, and D32. Figure 4-4 Location of CPU1 and CPU2 NIC 82599 LEDs Table 4-7 CPU1 and CPU2 NIC 82599 LEDs Label # Color Status Description Debug LEDs...

  • Page 62: Figure 4-5 Location Of Cpu1 I210 Leds

    Controls, Indicators, and Connectors Table 4-7 CPU1 and CPU2 NIC 82599 LEDs (continued) Label # Color Status Description Green Port 1 CPU2 - LINK/ACTIVITY (Asserted steady when link is established and there is no transmit or receive activity. Blinking when there is link and receive or Transmit activity.) The following figure shows the CPU1 i210 LEDs D30, D31, and D33.

  • Page 63: Figure 4-6 Location Of Cpu2 I210 Led Top

    Controls, Indicators, and Connectors The following figure shows the CPU2 i210 LEDs D27, D28, and D29. Figure 4-6 Location of CPU2 I210 LED Top Figure 4-7 Location of CPU2 i210 LEDs Bottom SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 64: Figure 4-8 Location Of Cpu1 Usb2240 Leds

    Controls, Indicators, and Connectors Table 4-9 CPU2 i210 LEDs Label # Color Status Description Debug LEDs Green I210 Default - Link Up/Activity (200 ms on/200 ms off) Green I210 Default - Link 1000 Green I210 Default - Link 100 The following figure shows the CPU1 USB2240 LED D3. Figure 4-8 Location of CPU1 USB2240 LEDs SharpStreamer™...

  • Page 65: Table 4-10 Cpu1 And Cpu2 Usb2240 Leds

    Controls, Indicators, and Connectors The following figure shows the CPU2 USB2240 LED D18. Figure 4-9 Location of CPU2 USB2240 LEDs Table 4-10 CPU1 and CPU2 USB2240 LEDs Label # Color Status Description Debug LEDs Green CPU1 USB2240 – GPIO1 Green CPU2 USB2240 –...

  • Page 66: Controls

    Controls, Indicators, and Connectors Controls A reset button is available at the rear side of the PCIE-7210/7211 card. By pressing the reset button (labeled as S1), CPLD on the card get reset. The following figure shows the reset button location on the PCIE-7210/7211 card. Figure 4-10 Reset Button S1 Location CPLD Reset Button S1...

  • Page 67: Figure

    Controls, Indicators, and Connectors Figure 4-11 Reset Button S2 and S3 Location CPU2 Reset button S2 CPU1 Reset button S3 Table 4-11 Switch S6 Settings Switch Description Default S6.1 OFF: CPU power control CPU Power control from from MaxCore MaxCore ON: CPU power control from onboard CPLD S6.2...

  • Page 68: Switch Settings For Mc1000 And Micro Platforms

    Controls, Indicators, and Connectors Switch Settings for MC1000 and Micro Platforms Following are the switch settings for power up of PCIE-7210/7211 card under MC1000/Micro platforms. Figure 4-12 Switch Settings S6 Location Figure 4-13 Switch Settings for MaxCore MC1000/Micro SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 69: Table 4-12 Switch Settings For Maxcore Mc1000/Micro

    Controls, Indicators, and Connectors Table 4-12 Switch Settings for MaxCore MC1000/Micro Switch MaxCore 1000 MaxCore Micro S6.1 OFF (left side position) ON (right side position) S6.2 OFF (left side position) OFF (left side position) S6.3 OFF (left side position) OFF (left side position) S6.4 OFF (left side position) OFF (left side position)
  • Page 70 Controls, Indicators, and Connectors SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 71: Bios

    Chapter 5 BIOS This chapter describes about BIOS setup, serial port configuration parameters, steps to access the BIOS setup screen, and configuring the BIOS settings. The Basic Input Output System (BIOS) acts as an interface between the operating system and the hardware of the card.
  • Page 72 BIOS To access BIOS Setup screen, press <F2> when the message Press <F2> to enter BIOS setup appears on the screen. The following figure depicts a sample BIOS Setup screen. Figure 5-1 BIOS Setup Screen BIOS Setup screen Menu Bar Legend Bar Select Save and Exit after making a selection in the setup menus.
  • Page 73 BIOS In order to navigate setup, use the arrow keys on the key to highlight items on the menu. All other navigation possibilities are shown at the bottom of the menu. Additionally, an item- specific help is displayed on the right hand side of the menu window. It displays the help text for the currently selected field.

  • Page 74: Menu Bar

    BIOS 5.1.1 Menu Bar Table 5-1 provides information about the BIOS Setup screen menu bar options. Table 5-1 BIOS Setup Menu Bar Menu Description Main Configuring the basic system. Advanced Setting the advanced features available on the system chipset. Security Setting the security password.

  • Page 75: Field Help

    BIOS To display a submenu, use the arrow keys to move the cursor to the desired submenu and then press <Enter>. Table 5-2 Legend Keys Function Displays general help window. Exits the menu or the BIOS Setup program without saving any changes.

  • Page 76: General Help

    BIOS 5.1.4 General Help You can press <F1>on the key in any menu context to invoke the general help window. The general help window describes the legend keys and their alternates as shown in the following figure. The scroll bar on the right side of any window indicates that there is more than one page of information in the window.

  • Page 77: Main Menu

    BIOS 5.2.1 Main Menu To view the Main menu, select the Main tab from the menu bar. By default, the Main tab is selected on the BIOS Setup screen. To modify menu screen items, scroll down the Main screen. The following screen appears. Figure 5-3 Main Menu The following table provides the list of features that can be configured in Main menu.

  • Page 78: Advanced Menu

    BIOS Table 5-3 Main Menu Selection Options/Format Description System Time HH:MM:SS Set the system time System Date MM/DD/YYYY Set the system date 5.2.2 Advanced Menu To view Advanced menu, select Advanced tab from the menu bar. Figure 5-4 Advanced Menu Use the legend keys to make a selection or exit in/from the Advanced menu.

  • Page 79: Boot Configuration

    BIOS The following table provides the frequently configurable settings in the Advanced menu. The other configurations shown in the Advanced menu are default values and need not be configured. Table 5-4 Advanced Menu Feature Description Boot Configuration To select the boot configuration. Console Redirection To change console redirection parameter.

  • Page 80: Console Redirection Setup

    BIOS The following table provides information about options in the Boot Configuration submenu and their default values. The values shown in the tables enclosed within brackets [...] indicate the default settings. Table 5-5 Boot Configuration Feature Options Description Numlock [On] Enables or disables Numlock.

  • Page 81: Table 5-6 Console Redirection Setup

    BIOS The following table provides information about the feature options in the Console Redirection Setup submenu and their defaults values. Table 5-6 Console Redirection Setup Feature Option Description Console Serial [Enabled] Enables or disables the Console Redirection Redirection. Disabled Terminal Type [VT_100] Selects the terminal type.
  • Page 82 BIOS Table 5-6 Console Redirection Setup (continued) Feature Option Description Information Wait Time 0 Second Selects the information screen display time. 2 Second [5 Second] 10 Second 30 Second C.R. After Post [Yes] Selects if the Console Redirections is enabled after Post. Text Mode Resolution AUTO Selects the text mode resolution.

  • Page 83: Security Menu

    BIOS 5.2.3 Security Menu To view the Security menu, select Security tab from the menu bar. Use the legend keys to make a selection and exit from the Security menu. The Security menu appears as shown in the following figure. Figure 5-7 Security Menu The following table provides other options in the Security menu and their defaults.

  • Page 84: Power Menu

    BIOS Table 5-7 Security Menu Feature Option Description Set Supervisor Password Sets the password 5.2.4 Power Menu To view the Power menu, select the Power tab from the menu bar. The Power menu is displayed which looks similar to the following figure. Figure 5-8 Power Menu SharpStreamer™...

  • Page 85: Boot Menu

    BIOS 5.2.5 Boot Menu To view the Boot menu, select Boot tab on the menu bar. The Boot menu screen is displayed as shown below. Figure 5-9 Boot Menu The following table provides options in the Boot menu and their default settings. Table 5-8 Boot Menu Feature Option...
  • Page 86 BIOS Table 5-8 Boot Menu (continued) Feature Option Description Network Stack [Disabled] Enables or disables UEFI and Legacy network support Enabled PXE Boot capability [Disabled] Enables or disables the alternate PXE boot modes UEFI:IPv4 UEFI:IPv6 UEFI:IPv4/IPv6 Legacy Power Up In Standby [Disabled] Support Add Boot Options...

  • Page 87: Exit Menu

    BIOS The values shown in the tables enclosed within brackets [...] indicate the default settings. 5.2.6 Exit Menu To view the Exit menu, select Exit tab from the menu bar. Use the legend keys to make a selection or exit to the main menu. The Exit menu screen looks similar to the figure below. Figure 5-10 Exit Menu The following table provides Exit menu features and their description.

  • Page 88: Bios Boot Parameter

    BIOS Table 5-9 Exit Menu (continued) Feature Description Save Changes Without Exit Saves the changes without exiting Exit Discarding Changes Exits the setup and discards the changes Load Setup Defaults Loads the default setup parameter Discard Changes Discards all changes performed BIOS Boot Parameter The BIOS reads the boot parameters from CPLD's shared memory and interprets the parameters for various purposes.
  • Page 89 BIOS fw_usb1=off/on # BIOS Setup > Advanced > PCH-IO Configuration > USB Configuration > USB HS Physical Connector #1 /* Front Panel USB */ fw_usb2=off/on # BIOS Setup > Advanced > PCH-IO Configuration > USB Configuration > USB HS Physical Connector #2 /* backplane USB */ fw_usb3=off/on # BIOS Setup >...
  • Page 90 BIOS fw_cpu_hp=off/on # BIOS Setup > power > CPU Configuration > Hardware Prefetcher fw_cpu_acp=off/on # BIOS Setup > power > CPU Configuration > Adjacent Cache Line Prefetch fw_cpu_vt=off/on # BIOS Setup > power > CPU Configuration > Intel (VMX) Virtualization Technology fw_cpu_ht=off/on # BIOS Setup >...
  • Page 91 BIOS or one of the following predefined selfspeaking names efisdcard # EFI on board microSD sdcard # legacy option - on board SD card efiobsata # EFI On board SATA efiiomsata0 efiiomsata1 obsata # legacy option - on board SATA efishell efinet4 (MAC) # MAC - MAC address in the form XX-XX-XX-XX-XX-XX efinet6 (MAC) # MAC - MAC address in the form XX-XX-XX-XX-XX-XX...
  • Page 92 BIOS SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 93: Software Information

    Chapter 6 Software Information This chapter provides references to software installation and use manuals related to OS, Basic Blade Services (BBS) software installation, and firmware upgrades of PCIE-721x card. OS and BBS Information For more information about the OS and Basic Blade Services (BBS) software installation and booting procedure of a PCIE-721x card installed in MaxCore MC3000 Platform, refer to MaxCore™...
  • Page 94 Software Information SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 95: Maxcore Firmware Upgrade

    Appendix A MaxCore Firmware Upgrade MaxCore Firmware Upgrade There are several firmware elements in a MaxCore system that may need upgrades throughout the product’s life cycle. Some firmware elements are part of the system itself and some reside on PCIe cards. This section provides information on how to upgrade the firmware elements that are part of the system only.

  • Page 96: Upgrade Procedure

    MaxCore Firmware Upgrade You can manage the system firmware elements as HPM.1 components. You can determine the revision of the HPM.1 firmware components using the tool called ipmitool. You can download it from http://ipmitool.sourceforge.net. There are different versions of ipmitool available, each using different command sets to the BMC.
  • Page 97 MaxCore Firmware Upgrade You can upgrade the BMC firmware through the BMC’s web browser accessed from the remote machine (network connection from remote machine to BMC required) through the IP address 192.168.201.9 with Username admin and Password admin Firmware upgrades via web browser are only supported by firmware revisions higher than v1.0.10 (the BMC firmware revision can be retrieved with ipmitool, refer to Obtaining Revisions of Firmware Components on page 95).

  • Page 98: Figure A-1 Dual Image Configuration

    MaxCore Firmware Upgrade To view more details, open the Dual Image Configuration screen by clicking Firmware Update > Dual Image Configuration. Figure A-1 Dual Image Configuration In the Dual Image Configuration screen, choose the required Image (that need to be booted after firmware option upgrade) and click Save. SharpStreamer™...

  • Page 99: Figure A-2 Firmware Update - Upgrade

    MaxCore Firmware Upgrade To open Firmware Update screen, click Firmware Update > Firmware Update from menu bar. Figure A-2 Firmware Update - Upgrade Do not modify the image to be updated. Never update the image you have booted successfully from. SharpStreamer™...
  • Page 100 MaxCore Firmware Upgrade Select Preserve Configuration to preserve the network configuration (IP,  username, password, DHCP, VLAN). Click Enter Update Mode and follow the wizard through the upgrade. Select  Full Flash check box to perform a complete firmware upgrade always. 2.
  • Page 101 MaxCore Firmware Upgrade ./ipmitool –I lan –H 192.168.201.9 –U admin –P admin hpm upgrade mc3000-cpld-glue-0.3.0.hpm component 2 force If you observe that the firmware upgrade fails, repeat the firmware upgrade  procedure again Firmware upgrade progress is not seen immediately. As the first step, the ipmitool ...

  • Page 102: Troubleshooting

    MaxCore Firmware Upgrade In any case, if you observe that the firmware upgrade fails, repeat the firmware  upgrade procedure again You cannot see the Firmware upgrade progress immediately. As the first step, the  ipmitool loads the firmware image into the BMC. This may take some time (~2min).

  • Page 103: Bmc Fw Upgrade Failed

    MaxCore Firmware Upgrade In case when ipmitool reports “Firmware upgrade procedure failed” message, power cycle the system, and evaluate the firmware revision of the firmware component just programmed (for more details refer to Obtaining Revisions of Firmware Components on page 95, and if the revision programmed is not performed before, repeat the firmware upgrade procedure.
  • Page 104 MaxCore Firmware Upgrade SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)

  • Page 105: Related Documentation

    3. In the Search text box, type product or manual name and click Filter. Table B-1 Artesyn Embedded Technologies - Embedded Computing Publications Document Title Publication Number SharpStreamer Pro PCIE-7210/7211 Quick Start Guide 6806800V06 SharpStreamer Pro PCIE-7210/7211 Safety Notes Summary 6806800V07...
  • Page 106 Related Documentation SharpStreamer™ Pro PCIE-7210/7211 Installation and Use (6806800V01A)
