RTM-ATCA-7350
Installation and Use
P/N: 6806800H30G
September 2014

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RTM-ATCA-7350 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Artesyn Embedded Technology RTM-ATCA-7350

Summary of Contents for Artesyn Embedded Technology RTM-ATCA-7350

  • Page 1 RTM-ATCA-7350 Installation and Use P/N: 6806800H30G September 2014...
  • Page 2 © Copyright 2014 Artesyn Embedded Technologies, Inc. All rights reserved. Trademarks Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of © Artesyn Embedded Technologies, Inc. 2014 Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners.

  • Page 3: Table Of Contents

    Unpacking and Inspecting RTM-ATCA-7350 ........
  • Page 4 RTM-ATCA-7350 Face Plate ........
  • Page 5 Mechanical Specifications of RTM-ATCA-7350 ........
  • Page 6 List of Tables RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 7 Figure 3-5 RTM-ATCA-7350 Front Plate VGA Port Pinout ....... 55 Figure 4-1 Block Diagram of RTM-ATCA-7350 .
  • Page 8 List of Figures RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 9: About This Manual

    About this Manual Overview of Contents This manual is intended for the users who install and configure the RTM-ATCA-7350 of the server blade. The user must be a professional engineer in the server device field, who has been trained and is able to identify danger levels when operating the device.
  • Page 10 Intelligent Platform Management Interface Keyboard, Video, and Mouse Out of Service Peripheral Component Interconnect Rear Transition Module SCSI Small Computer System Window Sensor Data Record System Event Log ShMC Shelf Management Controller Serial Over LAN RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 11 Repeated item for example node 1, node 2, ..., node 12 Omission of information from example/command that is not necessary at the time being Ranges, for example: 0..4 means one of the integers 0,1,2,3, and 4 (used in registers) Logical OR RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 12 Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury Indicates a property damage message No danger encountered. Pay attention to important information RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 13 Third edition 6806800H30D November 2009 Updated Section Installing RTM-ATCA-7350 on page 6806800H30E November 2009 Updated Section Installing RTM-ATCA-7350 on page 6806800H30F February 2010 Updated Standard Compliances on page 16 6806800H30G September 2014 Re-branded to Artesyn template. RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 14 About this Manual About this Manual RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 15: Introduction

    – Fiber Channel (FC) daughter card The daughter cards provide external interfaces for the server blade. As a manageable module of the server blade, RTM-ATCA-7350 is managed by the  Intelligent Platform Management Controller (IPMC) of the server blade. The IPMC monitors the working status of RTM-ATCA-7350. In addition, the Field ...

  • Page 16: Standard Compliances

    Defines mechanics, blade dimensions, power distribution, power and data connectors, and system management 1. Some PICMG requirements are not fully met. Refer ATCA-7350/RTM-ATCA-7350 Release Notes for more information. Ordering Information When ordering board variants or board accessories, use the order numbers given on the following pages.

  • Page 17: Supported Board Models

    Board Accessories Order Number Gigabit Ethernet (GE) daughter card MEZC-RTM-7150-GE Fiber Channel (FC) daughter card MEZC-RTM-7150-FC 1. Optical modules for the FC daughter card must be obtained separately. Recommended modules are: FINISAR FTRJ8519P1BNL-HW FINISAR FTRJ8519P2BNL-HW RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 18 Introduction RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 19: Hardware Preparation And Installation

    To inspect the shipment, perform the following steps. 1. Verify that you have received all items of your shipment: Printed Quick Start Guide RTM-ATCA-7350 Any optional items ordered 2. Check for damage and report any damage or differences to the customer service. RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 20: Environmental And Power Requirements

    +/- 0.25ºC/min or 15ºC/h NEBS Standard GR-63-CORE (59ºF/h) Rel. Humidity 5% to 85% non-condensing according to Artesyn - 5% to 85% non-condensing internal environmental requirements according to Artesyn - internal environmental requirements Altitude <= 4000m RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 21: Power Requirements

    1.0m (Packaged) per ETSI 300 019-2-2 (Blade level packaging) 25mm (unpackaged) per GR-63-CORE 2.3.2 Power Requirements Table 2-2 Power Requirements Requirement Operating Power supply Provided by the server blade Maximum power consumption 14.2 W RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 22: Module Installation And Removal

    Make sure that you wear an electrostatic discharge (ESD)-preventive wrist strap to prevent  the static electricity from hurting you or damaging the device. Keep your personal objects such as your clothes away from RTM-ATCA-7350. To prevent  the static electricity on clothing, you need to put on antistatic clothing.

  • Page 23: Ejector Handles

    Hardware Preparation and Installation RTM-ATCA-7350 is installed in the slot paired with the server blade slot at the back side of  the shelf. RTM-ATCA-7350 is powered from the payload power of the front board. You should install RTM-ATCA-7350 before payload power of the front board is turned on. Hot swap of the RTM-ATCA-7350 while under power is not supported.

  • Page 24: Installation Preparations

     wear the ESD-preventive wrist strap  remove the blank filler panels  unpack and check the RTM-ATCA-7350 suite  2.5.1 Wearing the ESD-Preventive Wrist Strap Module Damage Electrostatic discharge can damage circuits or shorten their life.

  • Page 25: Figure 2-1 Wearing The Esd-Preventive Wrist Strap

    2. Fasten the latch. Make sure that the ESD-preventive wrist strap well touches your bare wrist. 3. Insert the grounding terminal of the ESD-preventive wrist strap in the jack of the cabinet or shelf. Figure 2-1 Wearing the ESD-Preventive Wrist Strap RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 26: Removing Filler Blades

    If you want to install multiple blades in the shelf that is powered on, you can remove a filler blade and then install a blade one by one. If the slot is occupied with a filler blade you have to remove it first. RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 27: Installing And Replacing Daughter Cards

    1. As shown in step 1 of the figure below, use a screwdriver to anticlockwise loosen the two captive screws on a filler blade. 2. As shown in step 2 of the figure below, remove the filler blade. Figure 2-2 Removing the Filler Blade Installing and Replacing Daughter Cards RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 28: Precautions

    Do not exert too much force when you insert the blade. If the blade is not fully aligned with the interface in the backplane, too much force may twist the pins on the blade or backplane. RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 29: Preparations

    – Prepare the component to be installed or replaced. When you hold or transport the component, use the special antistatic package. In addition, you need to tidy, record, and repair the component during routine maintenance. RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 30: Ge Daughter Card

    The supplier provides a list of tools and negotiates with you to decide the tool provider. Confirming installation or changing positions  Confirm the positions of the cabinet, the shelf, and the slot where RTM-ATCA-7350 is installed. Then, stick a label on the face plate of RTM-ATCA-7350 to avoid wrong operation. Others ...

  • Page 31: Installation Positions

    Hardware Preparation and Installation 2.6.3.1 Installation Positions When the GE daughter card is used with the RTM-ATCA-7350 it can be installed on the daughter card connector J1, J2. The default position as used on the RTM-ATCA-7350-GE is position J2. Figure 2-3...

  • Page 32: Installing The Ge Daughter Card

    3. As shown in step 1 of the figure below, insert two plastic supports vertically in the holes used to fasten the GE daughter card. 4. As shown in step 2 of the figure below, at the back side of RTM-ATCA-7350, use a screwdriver to clockwise fasten the two screws used to fix the plastic supports.

  • Page 33: Figure 2-4 Installing The Ge Daughter Card

    Hardware Preparation and Installation 6. Insert the GE daughter card in RTM-ATCA-7350 by facing the daughter card at an angle of 45° to the RTM. Align the daughter card connector with the connector on RTM-ATCA-7350, and the daughter card positioning holes with the plastic supports on RTM-ATCA-7350.

  • Page 34: Replacing The Ge Daughter Card

    6. Take the new GE daughter card out of the antistatic package. 7. Insert the GE daughter card in RTM-ATCA-7350 by facing the daughter card at an angle of 45° to the RTM. Align the daughter card connector with the connector on RTM-ATCA-7350, and the daughter card positioning holes with the plastic supports on RTM-ATCA-7350.

  • Page 35: Fc Daughter Card

    2.6.4.1 Installation Positions When the FC daughter card is used with the RTM-ATCA-7350 it can be installed on the daughter card connector J1. The RTM-ATCA-7350 provides space for one FC daughter card. Use of the FC daughter card excludes use of the GE daughter card.

  • Page 36: Replacing The Fc Daughter Card

    Hardware Preparation and Installation 6. Insert the FC daughter card in RTM-ATCA-7350 by facing the daughter card at an angle of 45° to the RTM. Align the daughter card connector with the connector on RTM-ATCA-7350, and the daughter card positioning holes with the plastic supports on RTM-ATCA-7350.

  • Page 37: Installing And Removing The Rtm-Atca-7350

    Installing RTM-ATCA-7350 Product Damage You can install RTM-ATCA-7350 into a system if the front blade is already installed or if it is not installed. In case the front blade is already installed, its payload has to be powered down first.
  • Page 38 Hardware Preparation and Installation Installation Procedure with Installed Front Blade The following procedure describes the installation of RTM-ATCA-7350. It assumes that your system is powered on. If your system is powered off, you can disregard the blue LED and thus skip the respective step.

  • Page 39: Figure 2-5 Installing Rtm-Atca-7350

    Hardware Preparation and Installation 7. Align the upper and lower sides of RTM-ATCA-7350 with the guide rails (the edges of the slot). Slide RTM-ATCA-7350 along the guide rails until the positioning pins of RTM-ATCA-7350 are inserted in the positioning holes in the shelf.

  • Page 40: Removing Rtm-Atca-7350

    A switched off blue LED indicates that the payload of the RTM has become active. 2.7.2 Removing RTM-ATCA-7350 Product Damage You should power off the front blade before removing RTM-ATCA-7350. To remove RTM-ATCA-7350, proceed as follows: 1. Wear the ESD-preventive wrist strap. For more information refer, Wearing the ESD- Preventive Wrist Strap on page 2.

  • Page 41: Connecting External Cables

    Hardware Preparation and Installation 6. As shown in step 3 of the figure below, remove RTM-ATCA-7350 along the guide rails. 7. Place RTM-ATCA-7350 in the antistatic package. Figure 2-6 Removing RTM-ATCA-7350 Connecting External Cables After RTM-ATCA-7350 is installed in the shelf, you can connect the keyboard, video, and mouse (KVM) cables.

  • Page 42: Connecting Kvm Cables

    Hardware Preparation and Installation If RTM-ATCA-7350 is configured with the GE daughter card or FC daughter card, it provides the external GE network ports or external FC interfaces. Network cables or optical fibers can be connected to RTM-ATCA-7350. You can choose to use one or more daughter cards according to actual applications.

  • Page 43: Connecting Network Cables

    It is recommended that the network cable is grounded through the metal cover of the network port connector. When RTM-ATCA-7350 is configured with the GE daughter card, it provides two external Ethernet interfaces with 10/100/1000M Base-T auto-negotiation. Network cables are used to connect RTM-ATCA-7350 to the external network.

  • Page 44: Connecting Optical Fibers

    2.8.3 Connecting Optical Fibers When RTM-ATCA-7350 is configured with the FC daughter card, it provides two external 2G FC interfaces. Optical fibers are used to connect RTM-ATCA-7350 to the external Storage Area Network (SAN) storage system. Optical modules for the FC daughter cards must be obtained separately.

  • Page 45: Figure 2-9 Connecting The Optical Fibers To Rtm-Atca-7350

    As shown in steps 1 and 2 in the figure below, insert the optical module in the FC interface and then insert the optical fibers in the optical module. Figure 2-9 Connecting the Optical Fibers to RTM-ATCA-7350 RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 46 Hardware Preparation and Installation RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 47: Controls, Leds And Connectors

    Chapter 3 Controls, LEDs and Connectors Overview This chapter describes: Face plate connectors  Face plate LEDs  Rear panel connectors  RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 48: Face Plate Connectors And Leds

    Controls, LEDs and Connectors Face Plate Connectors and LEDs The following figure shows the face plate of RTM-ATCA-7350 without daughter cards installed. Figure 3-1 Face Plate of RTM-ATCA-7350 You need to install a filler blade in the position that is not occupied by the face plate of the daughter card.

  • Page 49: Leds

    The GE daughter card provides the network port indicators and the FC daughter card provides the FC status indicators. You can monitor these indicators to diagnose the current status of RTM-ATCA-7350. The following table lists the indicators on the RTM-ATCA-7350 face plate. Table 3-1 Indicators on the RTM-ATCA-7350 Face Plate Indicator...
  • Page 50 Controls, LEDs and Connectors Table 3-1 Indicators on the RTM-ATCA-7350 Face Plate (continued) Indicator Color Meaning Description Amber Attention indicator The ATN LED is set to off when the payload processor starts running. Payload Management software is responsible for controlling the ATN LED.

  • Page 51: Connectors

    Controls, LEDs and Connectors 3.2.2 Connectors RTM-ATCA-7350 provides two daughter card connectors, as shown in the following figure. Figure 3-2 Structure of RTM-ATCA-7350 RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 52: Rtm-Atca-7350 Face Plate

    Controls, LEDs and Connectors In the above figure: Label Description Daughter card connector J2 Daughter card connector J1 3.2.2.1 RTM-ATCA-7350 Face Plate Face plate of the RTM-ATCA-7350 provides: One USB interface  One VGA DB15 Port  OOS indicator  IS indicator ...

  • Page 53: Figure 3-3 Connectors And Indicators Of Rtm-Atca-7350

    Controls, LEDs and Connectors ATN indicator  H/S indicator  Figure 3-3 Connectors and Indicators of RTM-ATCA-7350 RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 54: Table 3-2 Usb Port Pin Assignment

    Controls, LEDs and Connectors 3.2.2.1.1 USB Port RTM-ATCA-7350 provides a single port USB connector on the face plate. The USB port is compliant to the USB 1.1 specification. The following USB Port Pin Assignment table describes the pinout information. Figure 3-4...

  • Page 55: Table 3-3 Vga Port Pin Assignment

    Controls, LEDs and Connectors 3.2.2.1.2 VGA Port ATCA-7350 provides its VGA output port through RTM-ATCA-7350. The VGA port on RTM- ATCA-7350 use a DB15 female connector with a signal definition compatible to the standard VGA plug. Figure 3-5 RTM-ATCA-7350 Front Plate VGA Port Pinout...

  • Page 56: Zone 3 Connectors

    The following table shows the P30 pinout. PinA1 on the server blade side is on the top of the connector while the server blade is placed top side upwards and the face plate is left. RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 57: P31 Pinout

    Table 3-5 PIN 31 Pinout RTM_SYSLED_ RESERVED RTM_SYSLED_R RESERVED RTM_FC2_TX2 RTM_FC2_TX2_L RTM_FC1_TX2 RTM_FC1_TX2_L RTM_FC2_RX2 RTM_FC2_RX2_L RTM_FC1_RX2 RTM_FC1_RX2_L RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 58: P32 Pinout

    Table 3-6 PIN 32 Pinout RTM_PE RTM_PE MCH_E MCH_E RTM_EX RTM_EX MCH_E MCH_E _SDA _SCL XP6_RX XP6_RX P6_RXP P6_RXN XP6_RX XP6_RX RTM_EX RTM_EX MCH_E MCH_E RTM_EX RTM_EX MCH_E MCH_E P6_RXP P6_RXN XP6_RX XP6_RX P6_RXP P6_RXN XP6_RX XP6_RX RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 59: Table

    4_WAKE T_R_ T_R_ RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC 2_TX3_ 2_TX3_ 1_TX3_ 1_TX3_ 2_TX0_ 2_TX0_ 1_TX0_ 1_TX0_ RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC RTM_FC 2_RX3_ 2_RX3_ 1_RX3_ 1_RX3_ 2_RX0_ 2_RX0_ 1_RX0_ 1_RX0_ RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 60 Controls, LEDs and Connectors RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 61: Functional Description

    Chapter 4 Functional Description Overview This chapter describes: Block diagram  Daughter cards  Block Diagram The following block diagram shows the main components of RTM-ATCA-7350 and how they interact/connect. Figure 4-1 Block Diagram of RTM-ATCA-7350 RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 62: Daughter Cards

    GE Daughter Card The GE daughter card provides two external Ethernet interfaces; 10/100/1000M Base-T auto- negotiation and RJ-45 interface. The RTM-ATCA-7350 can host one or two GE daughter cards, thus providing up to four external Ethernet interfaces. The following figure shows the GE daughter card.

  • Page 63: Fc Daughter Card

    FC Daughter Card The FC daughter card provides two 2G FC interfaces; FC-AL, FC-SW, point to point, and 1G/2G auto-negotiation. The RTM-ATCA-7350 can host one FC daughter card. Use of the FC daughter card excludes use of the GE daughter card.
  • Page 64 The following figure shows the FC daughter card. Figure 4-3 FC Daughter Card Indicators The FC daughter card provides the RUN and ALM indicators. You can monitor these indicators to diagnose the current status of the external FC interfaces. RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 65: Table 4-2 Indicators Provided By The Fc Daughter Card

    Table 4-2 Indicators Provided by the FC Daughter Card Indicator Color Meaning Description Amber FC interface working  Green on and amber on: RTM-ATCA-7350 is in state the power-on process.  Green off and amber blinking: Signal Green synchronization is lost. ...
  • Page 66 Functional Description RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 67: Related Documentation

    Document Title and Source Publication Number ATCA-7350 Installation and Use 6806800G59 ATCA-7350: Control via IPMI, Programmer's Reference 6806800H29 MESC-RTM-7150-FC Installation Information 6806800F90 MESC-RTM-7150-GE Installation Information 6806800F89 ATCA-7X50-HDDx-SAS/SATA Installation Information 6806800E28 ATCA-7x50-MEM Installation Information 6806800E27 ATCA-7350/RTM-ATCA-7350 Release Notes 6806800H69 RTM-ATCA-7350 Installation and Use (6806800H30G)

  • Page 68: Related Specifications

    Table A-2 Related Specifications Organization Document Title Intel Platform Management FRU Information Storage Definition v1.0 developer.intel.com/design/servers/ipmi IPMI Specification v1.5 PICMG PICMG 3.0 Revision 2.0 Advanced TCA Base Specification picmg.org/specifications.stm RTM-ATCA-7350 Installation and Use (6806800H30G)
  • Page 70 Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners. © 2014 Artesyn Embedded Technologies, Inc.
