  • Page 1 ATCA-MF106 Installation and Use P/N: 6806800M62C July 2015...
  • Page 2 © Copyright 2015 Artesyn Embedded Technologies, Inc. All rights reserved. Trademarks Artesyn Embedded Technologies, Artesyn and the Artesyn Embedded Technologies logo are trademarks and service marks of © Artesyn Embedded Technologies, Inc. 2015 Artesyn Embedded Technologies, Inc. All other product or service names are the property of their respective owners.

  • Page 3: Table Of Contents

    ATCA-MF106 Hardware ........
  • Page 4 Log Files ................69 ATCA-MF106 Installation and Use (6806800M62C)
  • Page 5 Related Specifications ............. . . 85 ATCA-MF106 Installation and Use (6806800M62C)
  • Page 6 Contents Contents Contents ATCA-MF106 Installation and Use (6806800M62C)
  • Page 7 ATCA-MF106 Specific Sensors ........
  • Page 8 List of Tables ATCA-MF106 Installation and Use (6806800M62C)
  • Page 9 FacePlate ............. . . 53 ATCA-MF106 Installation and Use (6806800M62C)
  • Page 10 List of Figures ATCA-MF106 Installation and Use (6806800M62C)

  • Page 11: About This Manual

    AdvancedTCA and telecommunications. This manual provides the information you need to install, access and operate the shelf manager and hub board ATCA-MF106. Additionally you need the System Management Interface Based on HPI-B (Centellis CO 31kX/4100/2000) User’s Guide to adopt the hardware platform interface.
  • Page 12 Hardware Platform Interface International Electric Code Intelligent Platform Management IPMB Intelligent Platform Management Bus IPMC Intelligent Platform Management Controller IPMI Intelligent Platform Management Interface NEBS Network Equipment Building System Out-Of-Service Printed Circuit Board Power Entry Module ATCA-MF106 Installation and Use (6806800M62C)
  • Page 13 Used to characterize user input and to separate it Courier + Bold from system output Reference Used for references and for table and figure descriptions File > Exit Notation for selecting a submenu ATCA-MF106 Installation and Use (6806800M62C)
  • Page 14 Indicates a hazardous situation which, if not avoided, may result in minor or moderate injury Indicates a property damage message No danger encountered. Pay attention to important information ATCA-MF106 Installation and Use (6806800M62C)
  • Page 15 This manual has been revised and replaces all prior editions. Order No. Publication Date Description 6806800M62A July 2011 Initial version 6806800M62B September 2014 Re-branded to Artesyn template. 6806800M62C July 2015 Added GR-1089 warning criteria related text in safety notes section. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 16 About this Manual About this Manual ATCA-MF106 Installation and Use (6806800M62C)

  • Page 17: Safety Notes

    This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 18 1 power pins. Damage of the Product Incorrect installation of the product can cause damage of the product, Only use handles when installing/removing the product to avoid damage/deformation to the faceplate and/or PCB. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 19 Board Overheating and Board Damage Operating the board without forced air cooling may lead to board overheating and thus board damage. Injuries or Short Circuits Board or power supply ATCA-MF106 Installation and Use (6806800M62C)
  • Page 20 Check the total power consumption of all components installed (see the technical specification of the respective components). Ensure that any individual output current of any source stays within its acceptable limits (see the technical specification of the respective source). ATCA-MF106 Installation and Use (6806800M62C)
  • Page 21 Safety Notes Environment Always dispose of used products according to your country’s legislation and manufacturer’s instructions. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 22 Safety Notes ATCA-MF106 Installation and Use (6806800M62C)

  • Page 23: Sicherheitshinweise

    Installieren Sie keine Ersatzteile oder führen Sie keine unerlaubten Veränderungen am Produkt durch, sonst verfällt die Garantie. Wenden Sie sich für Wartung oder Reparatur bitte an die für Sie zuständige Geschäftsstelle von Artesyn. So stellen Sie sicher, dass alle sicherheitsrelevanten Aspekte beachtet werden. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 24 Bevor Sie das Board in einem System installieren, überprüfen Sie, ob die im Kapitel "Board Exchange" aufgeführten Anforderungen erfüllt werden. Bereich mit eingeschränktem Zugang - Installieren Sie das Board in ein System nur in Bereichen mit eingeschränktem Zugang. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 25 Warnung! Die Gebäude-internen Schnittstellen ("intra-building ports" per GR-1089-CORE) der Geräte oder Baugruppen sind nur für gebäudeinterne Verkabelung vorgesehen. Die Schnittstellen sind als Typ 2 oder Typ 4 definiert (wie in GR-1089-Core beschrieben) und erfordern eine Isolation zu Leitungen außerhalb des Gebäudes. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 26 Eingangsleitungen A und B verursachen. In diesem Fall ist Leitung A immer noch unter Spannung, auch wenn sie vom Versorgungskreislauf getrennt ist (und umgekehrt). Prüfen Sie deshalb immer, ob die Leitung spannungsfrei ist, bevor Sie Ihre Arbeit fortsetzen, um Schäden oder Verletzungen zu vermeiden. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 27 Stromaufnahme jedes Verbrauchers innerhalb der zulässigen Grenzwerte liegt (siehe die technischen Daten des entsprechenden Verbrauchers). Umweltschutz Entsorgen Sie alte Batterien und/oder Produkte stets gemäß der in Ihrem Land gültigen Gesetzgebung und den Empfehlungen des Herstellers. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 28 Sicherheitshinweise ATCA-MF106 Installation and Use (6806800M62C)

  • Page 29: Introduction

    Chapter 1 Introduction Overview The Artesyn Embedded Technologies ATCA-MF106 is a shelf manager & hub board intended to be used in AdvancedTCA systems. The ATCA-MF106 combines a shelf management controller and a GBE hub in a single FRU. This document details the hardware features and exchange procedures of the ATCA-MF106.

  • Page 30: Figure 1-1 Shelf Management Architecture

    Introduction The following figure shows the shelf management architecture. Figure 1-1 Shelf Management Architecture ATCA-MF106 Installation and Use (6806800M62C)
  • Page 31 The IPMI infrastructure is fully compliant to the IPMI V.1.5 and AdvancedTCA specifications. The shelf manager consists of hardware (payload and shelf management controller) and software. For a description of the software, see the System Management Interface Based on HPI-B (Centellis CO 31kX/4100/2000) User’s Guide. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 32: Hardware

    The following figure gives an overview about the main parts of the board. Figure 1-2 Overview Alignment Pin Backplane Connector Fuses Temperature Sensor DC/DC Converter Backplane Connector Alignment Pin Handle Switch Activator Ethernet Connector Extraction Handle Ethernet Connector Extraction Handle ATCA-MF106 Installation and Use (6806800M62C)

  • Page 33: Shelf Manager Hardware

    CPU with the shelf management software  Network connection to the system manager  Redundancy interface to a second shelf manager instance  Block transfer interface to the ShMC  Hardware platform interface (HPI) to the system manager  ATCA-MF106 Installation and Use (6806800M62C)

  • Page 34: Block Diagram

    The ShMC consists of two coupled microcontrollers: IPMC Master Controller (IMC) based on an Atmega 128  IPMC Slave Controller (ISC), based on an Atmega 8.  The following block diagram outlines the major hardware components. Figure 1-4 Block Diagram ATCA-MF106 Installation and Use (6806800M62C)
  • Page 35 Introduction The ATCA-MF106 consists of the dual ATmega IPMC as a front-end to the IPMB in the shelf, and the "Service Processor" based on a PowerQUICC, which provides the management functions. The ATCA-MF106 is designed for redundant operation in AdvancedTCA shelves. Usually, two ATCA-MF106 shelf managers are deployed in one shelf, one of which takes the role of active ATCA-MF106, the other acting as standby ready to take over in case of failure of the active one.

  • Page 36: Hub Hardware

    Introduction 1.2.2 Hub Hardware The ATCA-MF106 hub supports the following interfaces: One 10/100/1000 Mbps Ethernet uplink on the faceplate  Two 10/100 Mbps Ethernet ports, one to each shelf manager, routed via the backplane  Two 10/100/1000 Mbps Ethernet ports, one to each blade’s base interface, routed via the ...

  • Page 37: Hpi Based Shelf Management

    It consists of the manufacturer name, manufacturing date, the product name, the product serial number, and the product part number. – Multi record area It describes AdvancedTCA inventory data like point-to-point connectivity and the user info area. Hot swap states  ATCA-MF106 Installation and Use (6806800M62C)

  • Page 38: Remote Access

    1.3.2.1 Remote HPI ATCA-MF106 provides HPI based utilities for remote accessing and remote management. HPI based utilities allows to retrieve, monitor and modify the attributes of the system. 'hpiipmi' is one of such utility in which the IPMI commands can be sent to a particular HPI resource.

  • Page 39: Rmcp

    It is recommended that the RMCP interface shall be used only for the Monitoring purposes. Below RMCP server is available for ATCA-MF106: Standard RMCP server included in the HPI daemon running on the active ATCA-MF106  In order to access the RMCP server you have to specify on the RMCP client side: IP address ...

  • Page 40: Software Upgrade Management

    The redundancy is provided by the shelf managers. The implemented redundancy mechanism is cold standby. In case of a failure, a failover is performed from the active to the standby shelf manager. This takes two seconds. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 41: Network Management

    Network Management The main tasks of the network management are the assignments of backplane and out-of-band IP addresses by the shelf manager and the switchover of IP addresses from the active to the backup device. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 42: Standard Compliances

    The product has been designed to meet the directive on the restriction of the use of  certain hazardous substances in electrical and electronic equipment (RoHS) Directive 2002/95/EC. The ATCA-MF106 can be operated from -5 ºC up to +55 ºC without forced cooling.  ATCA-MF106 Installation and Use (6806800M62C)

  • Page 43: Figure 1-5 Declaration Of Conformity

    Introduction The following figure contains the Declaration of Conformity for ATCA-MF106. Figure 1-5 Declaration of Conformity C Declaration of Conformity According to EN 17050-1:2004 Manufacturer’s Name: Artesyn Embedded Technologies Embedded Computing Manufacturer’s Address: Zhongshan General Carton Box Factory Co. Ltd. No 62, Qi...

  • Page 44: Ordering Information

    For further details please contact your local Artesyn Embedded Technologies representative. Table 1-2 Ordering Information Order No. Name Description CENT-2000-MF106 MF106 shelf manager & hub board Shelf manager & hub board used in assembly Centellis 2000 systems ATCA-MF106 Installation and Use (6806800M62C)

  • Page 45: Atca-Mf106 Hardware

    Chapter 2 ATCA-MF106 Hardware Overview The ATCA-MF106 is compliant to PICMG 3.0 R3.0 (AdvancedTCA). The shelf manager and hub board is equipped with two backplane connectors. Figure 2-1 Hardware To prevent connector damage the alignment pin offers a guide rail to the slot and a coding mechanism to ensure the installation of the board in the matching slot.

  • Page 46: Payload Hardware

    Two 10/100 BaseT interfaces are connected to the backplane connector at the pins Eth1-Hub Tx/Rx and Eth2-Hub Tx/Rx. They route the base interface to the hubs of both the ATCA-MF106 which in turn are connected to the node blades in dual star topology. They are compliant with the PICMG 3.0 R3.0 specification (AdvancedTCA) for the base interface.

  • Page 47: Redundancy Interfaces

    ATCA-MF106 Hardware 2.2.2 Redundancy Interfaces The ATCA-MF106 uses a private, redundant, high-speed, full duplex serial connection for heart beating and data replication between the two shelf managers. The redundancy interface is routed to the backplane via differential line LVDS transceivers. The physical interface of both channels is compliant with the PICMG 3.0 R3.0 (AdvancedTCA)

  • Page 48: Ipmc Standard Functions

    The board satisfies the standby power limit of 10 W for AdvancedTCA FRUs, even when supplying 4 W to external loads. Typical power consumption of the ATCA-MF106 board is 5 W. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 49: Power Supply Holdup

    2.4.2 Power Supply Holdup The ATCA-MF106 complies with the requirements for board level voltage transients as described in chapter 4.1.4.3. of PICMG 3.0 (AdvancedTCA) specification. It satisfies the requirement of uninterrupted operation during a power failure of 5 ms, while supplying 4 W to external circuits.

  • Page 50: Gigabit Ethernet Hub

    ATCA-MF106 Hardware Gigabit Ethernet Hub The hub of the ATCA-MF106 is a managed Layer 2 Gigabit Ethernet switch which provides the following ports: One 10/100/1000 Mbps Ethernet uplink on the faceplate  Two 10/100 Mbps Ethernet ports, one to each shelf manager ...

  • Page 51: Frame Ground And Esd

    The faceplate mounting holes of the board are connected to frame ground. An ESD strip according to the AdvancedTCA specification PICMG 3.0 R3.0 for rear transition modules (RTMs) is provided at one edge of the PCB. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 52 ATCA-MF106 Hardware ATCA-MF106 Installation and Use (6806800M62C)

  • Page 53: Controls, Indicators And Connectors

    LEDs The following LEDs can be found on the faceplate of the board. OOS, OK and ACT are ATCA LEDs and can be controlled via IPMI. For more information, see the ATCA-MF106: Control via IPMI Programmer’s Reference manual. Table 3-1 FacePlate LEDs...

  • Page 54: Ethernet Connectors

    The RS-232D signals are driven by a Maxim MAX3232 transceiver for isolation and signal qualify. The Front Panel connector type is RJ-45. Front Panel Pin-out is shown in below table. Table 3-2 COM 0 Front Panel Serial Port Pin-out Listing SIGNAL ATCA-MF106 Installation and Use (6806800M62C)

  • Page 55: Sensors

    Ground Sensors The IPMC functionality is based on the IPMI specification V1.5. The IPMI sensors on the ATCA-MF106 are shown in the table below. For further information, see the ATCA-MF106: Control via IPMI Programmer’s Reference. Table 3-3 ATCA-MF106 Specific Sensors...
  • Page 56 Controls, Indicators and Connectors Table 3-3 ATCA-MF106 Specific Sensors (continued) Sensor/ Type of Reading Type Sensor Name Measurement What Does It Measure? Class Availability IPMB0 State IPMB 0xF1 Status of IPMB0 Bus Discrete Always Ejector State Button Switch Ejector Handle State...

  • Page 57: Board Exchange

    Chapter 4 Board Exchange Introduction This chapter describes how to install the ATCA-MF106 board and includes the following information: Before installation  Installing the board in a shelf  Starting up the board  Removing the board  Operation ...

  • Page 58: Environmental Requirements

    0.1 g from 5 to 100 Hz and back to 5 Hz 5-20 Hz at 0.01 g in target at a rate of 0.1 octave/minute. 20-200 Hz at -3.0 dB/octave platform) Random 5-20 Hz at 1 m /Sec Random 20-200 Hz at -3 dB/octave ATCA-MF106 Installation and Use (6806800M62C)

  • Page 59: Power Requirements

    US and Canada: -48 VDC Operating Voltage -39 VDC to -72 VDC US and Canada: -39 VDC to -60 VDC Input current 0.2 A ATCA-MF106 power dissipation 10 W (max.) including external load of 4 W maximum ATCA-MF106 Installation and Use (6806800M62C)

  • Page 60: Required Equipment

    ESD-safe environment or wear ESD wrist straps. Shipment Inspection To inspect the shipment, perform the following steps: 1. Verify that you have received all items of your shipment: Printed user manual  ATCA-MF106  Any optional items ordered  ATCA-MF106 Installation and Use (6806800M62C)

  • Page 61: Installing The Board

    Never exchange more than one of these FRUs (boards) at the same time to guarantee  that the shelf information stays consistent and up to date. The board must only be operated in a shelf that is properly grounded.  ATCA-MF106 Installation and Use (6806800M62C)

  • Page 62: Installing The Board

    The switched off blue LED indicates that the board is activated. 8. Attach cables to the front panel connectors as necessary. 4.3.2 Removing the Board This section describes how to remove the board from an AdvancedTCA system. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 63 The handle switch activator triggers the blinking of the blue LED. The hotswap state remains in the state "extraction pending", so that the blue LED is still blinking. 6. Wait until the blue LED is illuminated. 7. Remove the board from the shelf using the extraction handles. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 64 Board Exchange ATCA-MF106 Installation and Use (6806800M62C)

  • Page 65: Shelf Manager File System

    # points to the file in the second row. If the file in the second row # does not exist it is copied first. # Copyright (c) 2011 Emerson Network Power - Embedded Computing, Inc. ATCA-MF106 Installation and Use (6806800M62C)
  • Page 66 RAM disk file system to the persistent file system first. The persistent map itself is also symlinked at startup from the RAM disk file system to the persistent file system. A default map is copied, if it does not exists. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 67: Use Cases

    RAM disk file system is copied automatically during system startup. 5. Reboot your system After system reboot the file on the persistent media is used instead of the file on the RAM disk. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 68: How To Remove A File From The Persistent File System

    /usr/local/var/log. Upon reboot of the Shelf Manager, all files stored in /usr/local/var/log are moved to /usr/local/var/log.PREVIOUS. This allows two separate set of log files to be saved - the current logs in /usr/local/var/log and the logs from the previous boot in /usr/local/var/log.PREVIOUS. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 69: Log Files

    The IP addresses in the log file are dynamic. Only change the elements listed in the table above. Here is an example of what the configuration file might look like: <SupervisorConfiguration> <Logging> <!-- possible severity values: ATCA-MF106 Installation and Use (6806800M62C)
  • Page 70 <!-- for file transfer using ppp interface fileInterface="@srcIpAddr1@" --> <HeartBeater id="1" port="5567" type="UDP"> <HeartBeaterGroup name="shmgr" id="1" > <HeartBeaterNode id="1" ipAddr="192.168.101.9" port="5567" interval="400" warning="3" inaccessible="5" /> <HeartBeaterNode id="2" ipAddr="192.168.102.9" port="5567" interval="400" warning="3" inaccessible="5" /> </HeartBeaterGroup> </HeartBeater> </SupervisorConfiguration> ATCA-MF106 Installation and Use (6806800M62C)

  • Page 71: Firmware Upgrade Facility

    AMC modules. It consists of a Firmware Upgrade Command-line Utility (FCU), flash device drivers, and specially prepared firmware recovery image files. The ATCA-MF106 ramdisk is upgraded using the flashcp utility instead of fcu. Firmware Recovery Image Files FCU supports specially prepared firmware recovery image (FRI) files as well as firmware images in the HPM.1 format.

  • Page 72: Firmware Upgrade Command-Line Utility

    -v -f <filename> [-t<slave address>] fcu -u -f <filename> [-t<slave address>] fcu -a -f <filename> fcu -m -b <bank-letter> -d <device-id> [-t<slave address>] fcu -s -f <filename> fcu --activate -b <bank-letter> -d <device-id> Parameters --full-upgrade ATCA-MF106 Installation and Use (6806800M62C)
  • Page 73 --help. Currently supported values are listed in the following table. Device ID Description U-Boot firmware device for ATCA-MF106 atca-mf106-cpu Device Tree Binary device for ATCA-MF106 atca-mf106-dtb Kernel device of ATCA-MF106 atca-mf106-kernel Root filesystem (ramdisk) device for ATCA-MF106 atca-mf106-rootfs...
  • Page 74 Otherwise, you must specify a bank and a device. Note that on the ATCA-MF106 the U-Boot, DTB, Kernel, and Ramdisk are coupled, this means when you mark a U-Boot image for the next reboot, the other corresponding images are automatically marked as well.
  • Page 75 Some FCU options can be combined. Some options are exclusive. The following list describes the valid option combinations: --full-upgrade --file=<filename>  --full-upgrade --file=<filename> --target=xxxxxx  --help  --mark --bank=<bank-letter> --device=<device-id>  --query  --query --device=<device-id>  --show --file=<filename>  ATCA-MF106 Installation and Use (6806800M62C)
  • Page 76 When upgrading firmware, it is strongly recommended that you upgrade only one device at a time. While FCU performs many checks during upgrade to ensure success, if something goes wrong and both firmware banks become corrupted, the blade will be inoperable. ATCA-MF106 Installation and Use (6806800M62C)

  • Page 77: Upgrading Firmware

    Upgrading CPU Firmware Upgrading CPU Firmware Follow these steps to upgrade the CPU firmware (U-Boot): 1. Query the current and backup U-Boot firmware on the ATCA-MF106: # fcu -qd atca-mf106-cpu 2. Show the version of the new U-Boot image: # fcu -s -f /opt/bladeservices/rom/atca-mf106-cpu.fri 3.

  • Page 78: Upgrading The Kernel

    The flashcp utility does not upgrade the backup bank, but it upgrades the currently selected bank. Also, the ramdisk must be copied to the ATCA-MF106 and placed into /usr/local/ directory in order to upgrade due to the size of the ramdisk image.
  • Page 79 Marked for next use : yes Firmware was booted from this bank BANK Firmware Name : U-Boot Firmware Version : U-Boot 2010.06.2 (Mar 01 2011 - 10:06:53) MPC83XX Marked for next use : no ********************[[[[[ REPORT END ]]]]]******************** ATCA-MF106 Installation and Use (6806800M62C)

  • Page 80: Activating The Backup Boot Bank

    2. Mark the backup boot bank for next use after the next reboot. If Bank A is "Marked for next use", mark Bank 'B' for the next reboot. # fcu -mb B -d atca-mf106-cpu If Bank B is "Marked for next use", mark Bank 'A' for the next reboot.

  • Page 81: Upgrading Ipmc Firmware

    Follow these steps to upgrade the IPMC firmware. The IPMC firmware becomes active immediately after the successful upgrade. 1. Copy the IPMC firmware file to the ATCA-MF106 in the /root directory. The firmware file is not stored within the ramdisk.

  • Page 82: Example Upgrade Procedure

    7. There may be changes to files normally stored in the persistent file area when upgrading. Refer to the ATCA-MF106 Release Notes for more information. If there are no files in the persistent file area that need to be saved across a reboot (i.e. user specific files or changes to configuration files), the persistent file area can be cleared later (before rebooting the Shelf Manager).
  • Page 83 /usr/local/atca-mf106-kernel.fri rm /usr/local/ramdisk.image.gz 13. Clear the persistent file area or verify that necessary changes are made according to the ATCA-MF106 Release Notes. Reboot both Shelf Managers by issuing the below command from the Linux command line: reboot ATCA-MF106 Installation and Use (6806800M62C)
  • Page 84 Firmware Upgrade Facility ATCA-MF106 Installation and Use (6806800M62C)

  • Page 85: Related Documentation

    Document Title Publication Number Centellis 2000 Shelf-DC Installation and Use 6806800G45 Centellis 2000 Release 3.0 Installation and Use 6806800L99 ATCA-MF106: Control via IPMI Programmer’s Reference 6806800M33 System Management Interface Based on HPI-B (Centellis 6806800D84 CO 31kX/4100/2000) User’s Guide Related Specifications For additional information, refer to the following table for related specifications.
  • Page 86 Related Documentation Table A-2 Related Specifications (continued) Organization Document Title PICMG PICMG 3.0 Revision 3.0 Advanced TCA Base Specification http://www.picmg.org Service Availability Forum Service Availability Forum Hardware Platform Interface http://www.saforum.org SAI-HPI-A01.01 ATCA-MF106 Installation and Use (6806800M62C)
