  • Page 1 COTTON MODULE BUILDER OWNER'S MANUAL 00081000-02-08...
  • Page 2: Table Of Contents

    WARRANTY PROCEDURE: Should any part fail to conform with this warranty, CrustBuster/Speed King will repair or replace the part or parts which do not conform. If a part is defective, take it to your authorized CrustBuster Farm Equipment Dealer immediately, along with your warranty registration, and complete the proper forms requesting a warranty adjustment.
  • Page 3: Identification

    Identification Record your model and serial number in the space provided below. Your dealer needs this information to give you prompt, efficient service when you order parts. DATE PURCHASED _________________ MODEL NO. _______________________ SERIAL NO. _________________ Warnings!!! Read this manual carefully. It will instruct you on how to operate and service your machine safely and correctly.
  • Page 4 Module Builder Owner's And User's Statement Of Responsibility I have had explained to me and accept responsibility for the following: I understand this module builder is a heavy, powerful, and bulky unit of equipment capable of causing injury or death when used improperly. I accept the responsibility associated therewith. I understand the danger of high voltage power lines in relation to high profile module builder equipment and accept responsibility for its safe use in dangerous surroundings.
  • Page 5: Specifications

    Specifications Intermediate Stripper Model Model DUMP HEIGHT 9'- 6" (114.000") 11'- 0" (132.000") (Ground To Top Rail) OPERATING HEIGHT 19'-10.188" (238.188") 21'- 4.188" (256.188") (Wheels Retracted, Tamper Extended) ROAD HEIGHT 13'-10.625" (166.625") 15'- 4.625" (184.625") (Wheels Extended, Tamper Retracted) MAXIMUM HEIGHT 21'- 1.188"...
  • Page 6: Operation & Set-Up Procedures

    Operating the Module Builder IMPORTANT: PLEASE READ! INITIAL PREPARATION UPON RECEIPT Prior to shipment, the module builder has been carefully checked for defects, filled with oil, and operated under unloaded conditions. The hydraulic pressure has been set and the entire unit made "field ready". The initial preparation required of the operator consists only of reinstating the changes required for shipment.
  • Page 7 Set-Up Procedures Manual Tamper IMPORTANT: The following procedures have been set in the factory. They should be used only as a reference if it is necessary to make adjustments following replacements, and only with the guidance of a qualified service person. 1.
  • Page 8 Operating Procedures Manual Operation Figure #1 Operating tamper. a. Pull tamping lever to raise tamper. See Figure #1. b. Push tamping lever to lower tamper. See Figure #1. c. Tamper can be used to level dumped cotton by lowering tamper until slightly lower than highest dump and transversing bridge from front to rear.
  • Page 9 Operating Procedures Manual Operation After clearance from module is obtained, or new site located, lower 3-point until front of builder is firmly on ground. g. Move to operator platform on builder. h. Lower builder to ground by pushing axle lever and retracting axle cylinder until builder is firmly on ground.
  • Page 10: Module Builder Guidelines

    Module Builder Guidelines LONG DISTANCE MOVING Depending upon whether you have a Stripper model(tall) module builder, or a Intermediate model module builder, you will be from 15'-4.625" to 13'-10.625" high, and overwidth, as well, while in transport position. This is a "permit load" and requires a planned route to avoid construction, low underpasses, and other special situations.
  • Page 11 Module Builder Guidelines Leave modules on a well-drained turnrow or move them to a storage area immediately after completion. The storage area should be accessible to transport equipment within 48 hours after a heavy rain; it should be located adjacent to an all-weather road. Modules should not be left on turnrows which may become inaccessible following heavy rains.
  • Page 12: Storage

    Module Builder Guidelines LOADING AND UNLOADING MODULES WITHOUT PALLETS Modules built on the ground, without pallets, are transported on a bed-mounted truck or tractor-type trailer with a multibeam tiltbed using mechanically powered conveyor chains for self-loading and unloading. It is very important that palletless modules be tamped extremely well on both ends to prevent sloughing while transported.
  • Page 13: Lubrication And Maintenance

    CrustBuster/Speed King cannot be responsible for such exceptions. In this respect, the customer is encouraged to consult his CrustBuster/Speed King representative when selecting an oil.
  • Page 14 Lubrication and Maintenance SUITABLE TYPES OF OIL Crankcase oil having letter designation SC, SD, SE, or SF per SAE J183 JUN86. Note that one oil may meet one or more of these designations. ANTIWEAR HYDRAULIC OIL - These are produced by all major oil suppliers and should consist of good quality base stocks compounded with antiwear, antioxidation, and antirust additives.
  • Page 15: Management Guidelines

    Management Guidelines USING THE SYSTEM The Cotton Module Builder will be an asset to the grower and ginner if properly used. Following a few common sense rules will aid greatly in the successful operation of the equipment and handling operation.
  • Page 16 Management Guidelines Cotton should be tarped immediately. Thunderstorms occur suddenly, and once the cotton is wet, it is difficult to gin and cannot be safely stored. Canvas tarps should not be tied too tightly as cotton will expand and tarps will shrink following rains, thus damaging tarps at grommet locations. Module temperature should be monitored at least daily for the first four days or until the temperature reaches its peak and is receding to outside temperature.
  • Page 17 Management Guidelines Prevent damage from rainfall collecting around the bottom of the module by placing it on a well- drained site. A high well-drained turnrow or central storage area enables the producer or ginner to move modules whenever he wants. Both lint and seed damage can result from heating;...
  • Page 18: Bridge Adjustment

    Bridge Adjustment IMPORTANT: Bridge adjustments should be checked after building two or three modules and weekly after that. Proper adjustments are critical to trouble free operation. Chain Drive NOTES: Chain adjustments that are too tight will result in broken drive shafts, worn or broken sprockets and bearings, and result in shorter chain life.
  • Page 19: Trouble Shooting

    Trouble Shooting Guide - General The following trouble shooting guide is for general problems that will arise in hydraulic systems. This guide can be used to narrow problems down to a specific item in the system. After that specific item is found, the specific guide that follows should be used. I.
  • Page 20 Trouble Shooting Guide - General VII. Excessive Heat A. Pump Heat 1. Cavitation a. Check proper RPM of tractor. Minimum - 1000 RPM to maximum - 1300 RPM. DO NOT EXCEED 1300 RPM. 2. Air in fluid. a. Check for leaky fitting. Repair if necessary. b.
  • Page 21: Specific

    Trouble Shooting Guide - Specific As with all hydraulic systems, each specific component will have unique problems occur. The following is a guide for trouble shooting each specific component. Although this list may not include every problem that arises, it will cover most. I.
  • Page 22 Trouble Shooting Guide - Specific III. Bridge - Chainless Drive - (cont’d) 3. Bridge is fast and jerky. a. Check tractor RPM. Make sure it is not over 1300 RPM. If not, RPM can be slowed down to a minimum 1000 RPM to smooth operation of bridge.
  • Page 23: Front End

    Front End Components Item Qty Part No. Description 967877 Hitch 80175300 Platform Support (Intermediate) 80058100 Platform Support (Stripper) 80064900 Ladder (Intermediate) 80063100 Ladder (Stripper) 80069800 Platform 62595400 Dash Enclosure 11682200 Dash Plate 80250400 Platform Guard 80099500 Seat Pedestal 00234500 Contour Seat 80762800 T-bolt Weldment 80067200 Ladder Rail 80026800 Front Ext Channel...
  • Page 24: Cab

    Platform Cab Option Item Qty Part No. Description 60571700 Cab Top Assembly w/glass 80249600 Cab Top Only 60573300 Door Assy -LH w/ glass 80725500 Door -LH 60572500 Door Assy-RH w/glass 80724800 Door - RH 00203000 Inside Door Latch - LH 00205500 Inside Door Latch - RH 01213800 Screw #14 x 3/4"...
  • Page 25: Directional Valve & Hoses

    Directional Valve Manual Tamper Item Qty Part No. Description 62579800 Directional Valve Assy w/fittings 03356300 Directional Valve 2-Spool 00563700 Adpt 90° 3/8" NPTM-9/16" JICM 00600700 Adpt 45° 1 1/16" MOR-7/8" JICM 00601500 Adpt 45° 1 1/16" MOR-1 1/16" JICM 00603100 Adpt 45° 1 1/16" MOR-1 5/16" JICM 00607200 Adpt 90°...
  • Page 26: Cross Port Relief Valve & Hoses

    Cross Port Relief Valve Item Qty Part No. Description 60731700 Cross Port Relief Valve Assembly 00582700 Cross Port Relief Valve 00590000 Adapter Straight 1 1/16 MOR-1 1/16 JICM Hydraulic Hoses and Routings Item Qty Part No. Description From 00553800 Hose 3/4" x 36 Port A-1st spool Port A on cross port on 2-spool 00550400 Hose 3/4"...
  • Page 27: Oil Reservoir

    Oil Reservoir Item Qty Part No. Description Item Qty Part No. Description 62685300 Oil Reservoir Assembly 00566000 Ball Valve 1½" NPTF 00130500 Pipe Street Ell 1 1/4" 00866400 Adapter Cap 9/16"-18 JIC 00140400 Pipe Close Nipple 1 1/4" 82413600 Oil Reservoir 00145300 Sight Level &...
  • Page 28: Bridge Assembly

    Bridge Assembly Chain Drive...
  • Page 29 Bridge Assembly Chain Drive Item Qty Part No. Description Item Qty Part No. Description 00167700 Decal No Smoking 3 x 12 61212700 Roller 5" OD x 1" ID x 3 1/4" 00190900 Roller Plastic 3 x 1 x 5 7/8" 330357 HHCS 1"...
  • Page 30 Bridge Assembly Chainless...
  • Page 31: Chainless

    Bridge Assembly Chainless Item Qty Part No. Description Item Part No. Description 60767100 Handle Assy Manual Latch 00167700 Decal No Smoking 3 x 12 80107600 Latch 00190900 Roller Plastic 3 x 1 x 5 7/8" 335240 HHCS ½" x 1 3/4" 00504100 Nut 3/8"...
  • Page 32: Bridge Front & Rear Drive

    Front Drive Components Item Qty Part No. Description Item Qty Part No. Description 10903300 Chain #80 x 31Pitches 11864600 Front Hopper Chain Drive 20072500 Key 3/8" x 2" (Intermediate Only) 255224 Motor Spacer Plate 11488400 Front Hopper Chainless 80348600 Drive Mount (Intermediate Only) 00683300 Set Screw 3/8"...
  • Page 33 Rear Drive Components Item Qty Part No. Description Item Qty Part No. Description 00683300 Set Screw 3/8"-16 x 1/2" 80093800 Rear Shaft Cone point 10746600 Bumper 00688200 Set Collar 1½" ID 80007800 Rear Hopper w/3/8"-16 SS (Intermediate Only) 12911400 Bearing 1½"2B -3/8-16 hole 60995800 Rear Chain Guard Assembly 331363 Nut ½"...
  • Page 34: Chain Drive

    Hydraulic Lines Chain Drive...
  • Page 35 Hydraulic Lines Chain Drive Item Qty Part No. Description Item Qty Part No. Description 12541900 Hyd Tube 5/8" x 117" 00540500 Adapter 90° 02090900 Hyd Tube 5/8" x 240" 1 5/8" JICM/ 1 5/16" JICM 11655800 Hyd Tube 5/8" x 169" 00614800 Adapter Tee 7/8"...
  • Page 36: Chainless

    Hydraulic Lines Chainless...
  • Page 37 Hydraulic Lines Chainless Item Qty Part No. Description Item Qty Part No. Description 12541900 Hyd Tube 5/8" x 117" 00614800 Adapter Tee 7/8" JICM 02090900 Hyd Tube 5/8" x 240" 00723700 Hose Clamp 7/8" 11655800 Hyd Tube 5/8" x 169" 00722900 Hose Clamp 3/4"...
  • Page 38: Hydraulic Pipes - Hydraulic Pipes - Axle

    Single Axle Assembly Item Qty Part No. Description 60722600 Single Axle Assembly w/hub only 80029200 Single Axle 02710200 Complete Hub 03659000 Lug Bolt 02726800 Inner Cup 400846 Outer Cup 02728400 Inner Cone 400853 Outer Cone Item Qty Part No. Description 02730000 Hub Cap 02731800 Grease Seal 02732600 Spindle Washer...
  • Page 39: Tamper

    Cylinder Tower and Tamper Item Qty Part No. Description Item Qty Part No. Description 80106800 Tamper 00634600 Adapter 90D 82414400 Cylinder Lock Plate 1 5/16 MOR/1 5/16 JICM 18394700 Tamper Cushion 600213 Bushing 1" x 1 1/4" x 1" 03565900 Cylinder 2½" x 89" 00590000 Adapter Straight 10785400 Tower Pads 1 1/16 MOR / 1 1/16 JICM...
  • Page 40: Cylinders

    Cylinders Gate Cylinder #02858900 - 3" x 30" Item Part No. Description 461483 Clevis 470443 Rod M 460824 Rod C 469726 Head 470344 Piston M 460964 Piston C 461004 Tube 469718 Base 461053 Tie Rod 461079 Seal Kit Wheel Cylinder - (Stripper Models) Wheel Cylinder - (Intermediate Models) #02706000 - 3"...
  • Page 41: Lights

    Lights Item Qty Part No. Description 03450400 Light 62608500 Wire 14 ga x 69" 03449600 Light Switch On-Off 03446200 Wiring Harness 03452000 Wire Clips 605535 Tail Lights / Turn Signals 00613000 Hose Clamp 570192 Cable Tie 605709 Light Grommet 330654 Carriage Bolt 3/8"...
