HIstory

Button: MENU/<Histories>
The Mini-MOD provides users with a graphical history of the System and Outdoor temperatures
for the previous 24 hours. The temperatures are sampled every 12 minutes. That is, readings
of both System and Outdoor temperatures are recorded and stored every 12 minutes for the last
24 hours.
• To view the values of specific time period, use the two middle buttons to scroll to that time
and read the upper left temperature.
• The first screen will be the System Temperature History. By clicking on the Next button,
you'll be able to view the Outdoor Temperature History.
o
-SYS=91 F, 10:57Am-
▲ ▼
BACK
o
-OD=54 F, 10:57Am-
▲ ▼
BACK
NEXT
EXIT
